SAR有源干扰分类识别图像数据集仿真构建

doi:10.12305/j.issn.1001-506X.2025.10.13

系统工程与电子技术 ›› 2025, Vol. 47 ›› Issue (10): 3257-3269.doi: 10.12305/j.issn.1001-506X.2025.10.13

• 传感器与信号处理 • 上一篇

SAR有源干扰分类识别图像数据集仿真构建

高飞¹^,*(), 席睿达²(), 邢相薇³(), 邢妍¹(), 张强²(), 党红杏¹()

1. 中国航天科技集团有限公司第五研究院西安分院，陕西西安 710100
2. 西安电子科技大学机电工程学院，陕西西安 710071
3. 中国人民解放军 61646部队，北京 100192

收稿日期:2024-10-08 出版日期:2025-10-25 发布日期:2025-10-23
通讯作者: 高飞 E-mail:gaofei2004630@163.com;RuidaXi@stu.xidian.edu.cn;xingxiangwei@nudt.edu.cn;1061871653@qq.com;qzhang@xidian.edu.cn;danghongx@163.com
作者简介:席睿达（1999—），男，博士研究生，主要研究方向为多模态图像处理
邢相薇（1985—），男，副研究员，博士，主要研究方向为SAR图像解译、智能解译算法评估
邢　妍（1991—），女，高级工程师，硕士，主要研究方向为星载雷达数据预处理
张　强（1979—），男，教授，博士，主要研究方向为计算机视觉与智能图像处理
党红杏（1974—），女，研究员，硕士，主要研究方向为高分辨率机载/星载雷达系统设计和信号处理
基金资助:
卫星信息智能处理与应用技术重点实验室基金项目(2022-ZZKY-JJ-09-01); 2022年度中国空间研究院CAST基金重点项目资助课题

Image dataset simulation constructing for SAR active interference classification and recognition

Fei GAO¹^,*(), Ruida XI²(), Xiangwei XING³(), Yan XING¹(), Qiang ZHANG²(), Hongxing DANG¹()

1. Xi’an Branch of the Fifth Academy of China Aerospace Science and Technology Corporation （CASC），Xi’an 710100，China
2. School of Mechano-Electronic Engineering，Xidian University，Xi’an 710071，China
3. Unit 61646 of the PLA，Beijing 100192，China

Received:2024-10-08 Online:2025-10-25 Published:2025-10-23
Contact: Fei GAO E-mail:gaofei2004630@163.com;RuidaXi@stu.xidian.edu.cn;xingxiangwei@nudt.edu.cn;1061871653@qq.com;qzhang@xidian.edu.cn;danghongx@163.com

摘要/Abstract

摘要：

合成孔径雷达（synthetic aperture radar，SAR）图像可提供丰富的场景态势信息，而逐步恶化的电磁环境使得SAR抗干扰技术备受关注。近年来，深度学习技术在图像分类识别方面展现出优越性能。针对用于训练深度模型的有源干扰SAR图像数据需求量大且缺少干扰图像数据集的现状，在对13种典型有源干扰样式及其对SAR干扰特性分析的基础上，从多场景干扰参数覆盖性角度考虑，进行基于仿真的SAR干扰图像数据集构建；搭建基于Transformer的干扰识别模型和多个典型模型，在构建数据集上进行干扰分类识别研究。实验结果表明，由于引入全局自注意力机制的同时结合了可变形注意力机制，所提基于Transformer的干扰识别模型具备更强的干扰特征全局建模能力和干扰区域鉴别能力，在所构建数据集上相对其它模型表现出更为优良的性能。

关键词: 合成孔径雷达图像, 干扰, 分类识别, 深度学习, 数据集构建

Abstract:

Synthetic aperture radar （SAR） images can provide rich scene situational information, and with the gradually deteriorating electromagnetic environment much attention has been attracted to SAR anti-interference techniques. Deep learning technologies have shown excellent performance in image classification and recognition in recent years. Considering the large demand for active interference SAR image data for training deep models and the situation of lack of interference image datasets, based on the analysis of 13 typical active interference patterns and their interference characteristics against SAR, a simulation-based SAR interference image dataset is constructed from the perspective of multi-scenario interference parameter coverage, on which the interference classification and identification research is carried out, with a constructed Transformer-based interference recognition model and multiple typical models. Experimental results show that, due to the introduction of a global self attention mechanism combined with a deformable attention mechanism, the proposed Transformer-based interference recognition model has stronger global modeling ability of interference features and identification ability of interference regions, and exhibits berrer performance compared to other models on the constructed dataset.

Key words: synthetic aperture radar （SAR） image, interference, classification and recognition, deep learning, dataset construction

中图分类号:

TP 18

高飞, 席睿达, 邢相薇, 邢妍, 张强, 党红杏. SAR有源干扰分类识别图像数据集仿真构建[J]. 系统工程与电子技术, 2025, 47(10): 3257-3269.

Fei GAO, Ruida XI, Xiangwei XING, Yan XING, Qiang ZHANG, Hongxing DANG. Image dataset simulation constructing for SAR active interference classification and recognition[J]. Systems Engineering and Electronics, 2025, 47(10): 3257-3269.

图/表 10

图1

图2

图3

表1

主要干扰参数取值说明"

干扰样式	干扰参数	取值说明
射频噪声、噪声调幅、噪声调频和噪声调相	输入干信比	$ 8.4\sim 23.4\;{\text{dB}} $均匀分布产生
	调制噪声带宽	$ 0.1\;{B_r} \sim {B_r} $均匀分布产生
	干扰机位置	场景中心方位$ \pm 20\;{\text{km}} $和距离$ \pm 180\;{\text{km}} $范围均匀分布产生
	调幅斜率$ {K_{{\text{AM}}}} $	$ 0.1 \sim 5 $均匀分布产生
	调频斜率$ {K_{{\text{FM}}}} $	$ {10^5} \sim 2 \times {10^7} $均匀分布产生
	调相斜率$ {K_{{\text{PM}}}} $	$ 0.1 \sim 100 $均匀分布产生
扫频噪声和梳状谱噪声	输入干信比	$ 8.4\sim 23.4\;{\text{dB}} $均匀分布产生
	调制噪声带宽	$ 0.1\;{B_r} \sim {B_r} $均匀分布产生
	干扰机位置	场景中心方位$ \pm 20\; {\text{km}} $和距离$ \pm 180\;{\text{km}} $范围均匀分布产生
	扫频范围$ {F_{\min }} $与$ {F_{\max }} $	$ {F_{\min }} = 0 $，$ {F_{\max }} $在$ {B_r}/3 \sim {B_r} $均匀分布产生
	扫频周期$ T $	$ 0.1\sim 20 \;{\text{μs}} $均匀分布产生
	调频斜率$ {K_{{\text{FM}}}} $	$ {10^5} \sim 2 \times {10^7} $均匀分布产生
	梳状谱噪声信号分量数	$ 3 \sim 10 $均匀分布产生
	梳状谱噪声分量幅度$ {a_i} $	$ 0.5 \sim 1.5 $均匀分布独立产生
	梳状谱噪声分量基带频点$ {f_{{\text{j,}}i}} $	$ - 0.5 \;{B_r} \sim 0.5\;{B_r} $均匀分布独立产生
	梳状谱噪声分量调频斜率$ {K_{{\text{FM,}}i}} $	$ 5 \times {10^6} \sim 50 \times {10^6} $均匀分布独立产生
脉冲卷积和噪声卷积	输入干信比	$ 8.4 \sim 23.4 \; {\text{dB}} $均匀分布产生
	调制噪声带宽	$ 0.1 \; {B_r} \sim {B_r} $均匀分布产生
	时延个数$ P $	$ 5 \sim 20 $均匀分布产生
	幅度$ {\alpha _p} $	1
	时延$ \Delta {t_p} $	场景方位中心$ \pm 3.3 \; {\text{μs}} $范围均匀分布独立产生
	噪声时长	$ 0.4 \sim 10.4 \; {\text{μs}} $均匀分布产生
间歇转发、切片转发、频谱弥散转发和移频	输入干信比	$ 8.4 \sim 23.4 \; {\text{dB}} $均匀分布产生
	干扰机位置	场景中心方位$ \pm 300 \; {\text{m}} $和距离$ \pm 300 \; {\text{m}} $范围均匀分布产生
	间歇转发次数$ N $	$ 5 \sim 10 $均匀分布产生
	间歇转发干扰参数$ L $	$ 2 \sim 3 $均匀分布产生
	采样转发间歇时间$ \Delta t $	$ 0.3 \sim 2.5 \; {\text{μs}} $均匀分布产生
	切片转发分段数$ N $	$ 3 \sim 5 $均匀分布产生
	切片转发干扰参数$ L $	$ 3 \sim 5 $均匀分布产生
	频谱弥散转发次数$ N $	$ 5 \sim 10 $均匀分布产生
	频谱弥散转发间隔时间$ \Delta t $	$ 0.3 \sim 2.5 \; {\text{μs}} $均匀分布产生
	移频次数$ N $	$ 1 \sim 5 $均匀分布产生
	移频量$ \Delta {f_n} $	$ - {B_r} \sim {B_r} $均匀分布独立产生
虚拟假目标	输入干信比	$ 8.4 \sim 23.4 \; {\text{dB}} $均匀分布产生
	干扰机位置	场景中心方位$ \pm 300 \; {\text{m}} $和距离$ \pm 300 \; {\text{m}} $范围均匀分布产生
	虚拟假目标/散射点数$ {N_c} $	$ 1 \sim 10 $均匀分布产生
	虚拟假目标/散射点位置	场景中心方位和距离均在$ \pm 0.5 $$ \sim $$ \pm 1 \; {\text{km}} $范围均匀分布独立产生

表1

图4

图5

图6

图7

表2

表3

参考文献 50

1	张庆君, 韩晓磊, 刘杰. 星载合成孔径雷达遥感技术进展及发展趋势[J]. 航天器工程, 2017, 26 (6): 1- 8. doi: 10.3969/j.issn.1673-8748.2017.06.001
	ZHANG Q J, HAN X L, LIU J. Technology progress and development trend of spaceborne synthetic aperture radar remote sensing[J]. Spacecraft Engineering, 2017, 26 (6): 1- 8. doi: 10.3969/j.issn.1673-8748.2017.06.001
2	李亚超, 王家东, 张廷豪, 等. 弹载雷达成像技术发展现状与趋势[J]. 雷达学报, 2022, 11 (6): 943- 973. doi: 10.12000/JR22119
	LI Y C, WANG J D, ZHANG T H, et al. Present situation and prospect of missile-borne radar imaging technology[J]. Journal of Radar, 2022, 11 (6): 943- 973. doi: 10.12000/JR22119
3	张健丰, 付耀文, 张文鹏, 等. 圆迹合成孔径雷达成像技术综述[J]. 系统工程与电子技术, 2020, 42 (12): 2716- 2734. doi: 10.3969/j.issn.1001-506X.2020.12.07
	ZHANG J F, FU Y W, ZHANG W P, et al. Review of CSAR imaging techniques[J]. Systems Engineering and Electronics, 2020, 42 (12): 2716- 2734. doi: 10.3969/j.issn.1001-506X.2020.12.07
4	XU G, GAO Y D, LI J W, et al. InSAR phase denoising: a review of current technologies and future directions[J]. IEEE Geoscience and Remote Sensing Magazine, 2020, 8 (2): 64- 82. doi: 10.1109/MGRS.2019.2955120
5	WANG G Y, ZHANG M, HUANG Y, et al. Robust two-dimensional spatial-variant map-drift algorithm for UAV SAR autofocusing[J]. Remote Sensing, 2019, 11 (3): 340. doi: 10.3390/rs11030340
6	CHEN Z Y, ZHOU Y, ZHANG L R, et al. Ground moving target imaging and analysis for near-space hypersonic vehicle-borne synthetic aperture radar system with squint angle[J]. Remote Sensing, 2018, 10 (12): 1966. doi: 10.3390/rs10121966
7	HUANG Y, LIAO G S, XU J W, et al. GMTI and parameter estimation for MIMO SAR system via fast interferometry RPCA method[J]. IEEE Trans. on Geoscience and Remote Sensing, 2018, 56 (3): 1774- 1787. doi: 10.1109/TGRS.2017.2768243
8	李洋. 星载SAR弹射式干扰与抗干扰技术研究[D]. 成都: 电子科技大学, 2017.
	LI Y. Research on technology of rebound jamming and anti-jamming to spaceborne SAR[D]. Chengdu: University of Electronic Science and Technology of China, 2017.
9	潘嵩. SAR欺骗式干扰关键技术研究[D]. 成都: 电子科技大学, 2016.
	PAN S. Research on SAR deception jamming key technology[D]. Chengdu: University of Electronic Science and Technology of China, 2016.
10	林晓烘. 星载合成孔径雷达干扰与抗干扰技术研究[D]. 长沙: 国防科技大学, 2014.
	LIN X H. Study on jamming and anti-jamming techniques for spaceborne synthetic aperture radar[D]. Changsha: National University of Defense Technology, 2014.
11	汪日超. 星载SAR压制式干扰与抗干扰技术研究[D]. 成都: 电子科技大学, 2017.
	WANG R C. Research on spaceborne SAR compression interference and anti-jamming technology[D]. Chengdu: University of Electronic Science and Technology of China, 2017.
12	齐兆龙. SAR散射式欺骗干扰及其对抗技术研究[D]. 秦皇岛: 燕山大学, 2016.
	QI Z L. Research on SAR scattering deception jamming and its countermeasure technology[D]. Qinhuangdao: Yanshan University, 2016.
13	黄榜. 基于频控阵的星载SAR干扰技术研究[D]. 成都: 电子科技大学, 2020.
	HUANG B. The jamming research against spaceborne SAR using FDA[D]. Chengdu: University of Electronic Science and Technology of China, 2020.
14	赵明明. 基于SAR目标特征的欺骗式干扰技术研究[D]. 成都: 电子科技大学, 2019.
	ZHAO M M. Research on deceptive jamming technology based on SAR target characteristics[D]. Chengdu: University of Electronic Science and Technology of China, 2019.
15	刘立新. 对波形捷变SAR和GMTI时频交叉乘积欺骗干扰方法研究[D]. 长沙: 国防科技大学, 2019.
	LIU L X. Study on time-frequency cross-product deceptive interference method of waveform agile SAR and GMTI[D]. Changsha: National University of Defense Technology, 2019.
16	王梦科. SAR精细欺骗式干扰技术研[D]. 成都: 电子科技大学, 2020.
	WANG M K. Research on fine deceptive jamming technology of SAR[D]. Chengdu: University of Electronic Science and Technology of China, 2020.
17	纪朋徽, 代大海, 吴昊, 等. SAR成像电子对抗技术综述[J]. 无线电工程, 2019, 49 (6): 508- 513. doi: 10.3969/j.issn.1003-3106.2019.06.012
	JI P H, DAI D H, WU H, et al. Review of SAR imaging electronic countermeasures[J]. Radio Engineering, 2019, 49 (6): 508- 513. doi: 10.3969/j.issn.1003-3106.2019.06.012
18	荣鹏帅. SAR射频干扰抑制方法[D]. 西安: 西安电子科技大学, 2019.
	RONG P S. Radio frequency interference mitigation for SAR[D]. Xi’an: Xidian University, 2019.
19	MEYER F J, NICOLL J B, DOULGERIS A P. Correction and characterization of radio frequency interference signatures in L-band synthetic aperture radar data[J]. IEEE Trans. on Geoscience and Remote Sensing, 2013, 51 (10): 4961- 4972. doi: 10.1109/TGRS.2013.2252469
20	BOLLIAN T, YOUNIS M, KRIEGER G. On-ground interference removal from SAR images with DBF-based measurements and autoregressive modelling[C]//Proc. of the 13th European Conference on Synthetic Aperture Radar, 2021: 1200−1204.
21	HUANG Y, LIU Y Y, GUAN X Y, et al. A novel space-time interference mitigation algorithm on multichannel SAR systems[J]. IEEE Trans. on Geoscience and Remote Sensing, 2023, 61, 5220316.
22	MAO Y, HUANG Y, YU X T, et al. An radio frequency interference mitigation approach for spaceborne SAR system in low SINR condition[J]. IEEE Trans. on Geoscience and Remote Sensing, 2023, 61, 5217414.
23	SHARMA G, BAZIL RAJ A A. Low complexity interference mitigation technique in IRCI-free SAR imaging algorithms[J]. IEEE Geoscience and Remote Sensing Letters, 2022, 19, 4511305.
24	LV Z S, FAN H T, CHEN Z, et al. Mitigate the LFM-PRFI in SAR data: joint down-range and cross-range filtering[J]. IEEE Trans. on Geoscience and Remote Sensing, 2023, 61, 5205918.
25	DING Y, DU J B, FAN W W, et al. RFI extraction for synthetic aperture radar in 2D domain based on low rank and sparsity property[C]//Proc. of the CIE International Conference on Radar, 2021: 1940−1944.
26	LI N, LV Z S, GUO Z W, et al. Time-domain notch filtering method for pulse RFI mitigation in synthetic aperture radar[J]. IEEE Geoscience and Remote Sensing Letters, 2022, 19, 4013805.
27	ZHANG H, HUANG Y, LI J, et al. Time-varying RFI mitigation for SAR systems via graph Laplacian clustering techniques[J]. IEEE Geoscience and Remote Sensing Letters, 2022, 19, 4010805.
28	REIGBER A, FERRO-FAMIL L. Interference suppression in synthesized SAR images[J]. IEEE Geoscience and Remote Sensing Letters, 2005, 2 (1): 45- 49. doi: 10.1109/LGRS.2004.838419
29	DOERRY A W. Apodized RFI filtering of synthetic aperture radar images[R]. Albuquerque: Sandia National Laboratories, 2014.
30	NATSUAKI R, MOTOHKA T, WATANABE M, et al. An autocorrelation-based radio frequency interference detection and removal method in azimuth-frequency domain for SAR image[J]. IEEE Journal of Selected Topics in Applied Earth Observations and Remote Sensing, 2017, 10 (12): 5736- 5751. doi: 10.1109/JSTARS.2017.2775205
31	刘建洋. 基于时频域分析的电子干扰识别方法研究[D]. 成都: 电子科技大学, 2018.
	LIU J Y. Research on electronic jamming identification method based on time frequency domain analysis[D]. Chengdu: University of Electronic Science and Technology of China, 2018.
32	姜正云, 舒汀, 何劲, 等. 基于并联深度学习网络的雷达有源干扰智能识别方法[J]. 现代雷达, 2021, 43 (10): 9- 14.
	JIANG Z Y, SHU T, HE J, et al. Intelligent recognition method of radar active jamming based on parallel deep learning network[J]. Modern Radar, 2021, 43 (10): 9- 14.
33	杨兴宇, 阮怀林. 基于栈式稀疏自编码器的新型干扰识别[J]. 现代雷达, 2018, 40 (5): 21- 27.
	YANG X Y, RUAN H L. Jamming identification algorithms of advanced jamming based on stacked sparse autoencoder[J]. Modern Radar, 2018, 40 (5): 21- 27.
34	任锴. 基于深度学习的压制式干扰环境下SAR目标识别方法研究[D]. 成都: 电子科技大学, 2019.
	REN K. Research on target recognition and classification of SAR image in suppressive jamming environment based on deep learning[D]. Chengdu: University of Electronic Science and Technology of China, 2019.
35	LI J S, TAO M L, ZHANG X, et al. A semantic cognition enhancment network for interference detection in Sentinel-1 SAR image[C]//Proc. of the CIE International Conference on Radar, 2021: 1923−1926.
36	NIE L, WEI S J, ZHANG H, et al. HPII-NET: a high-precision interference identification network for spaceborne SAR images[C]//Proc. of the IEEE International Geoscience and Remote Sensing Symposium, 2023: 7030−7033.
37	FAN W W, ZHOU F, RONG P S, et al. Interference mitigation for synthetic aperture radar using deep learning[C]//Proc. of the 6th Asia-Pacific Conference on Synthetic Aperture Radar, 2019.
38	ZHANG Z D, DING Y, FAN W W, et al. Wide-band interference mitigation for SAR based on generative adversarial network[C]//Proc. of the CIE International Conference on Radar, 2021: 1891−1900.
39	CEN X, LI Y C, HAN Z Y, et al. Self-supervised learning method for SAR multiinterference suppression[J]. IEEE Trans. on Geoscience and Remote Sensing, 2023, 61, 5220017.
40	陈思伟, 崔兴超, 李铭典, 等. 基于深度CNN模型的SAR图像有源干扰类型识别方法[J]. 雷达学报, 2022, 11 (5): 897- 908. doi: 10.12000/JR22143
	CHEN S W, CUI X C, LI M D, et al. SAR image active jamming type recognition based on deep CNN model[J]. Journal of Radars, 2022, 11 (5): 897- 908. doi: 10.12000/JR22143
41	刘强. 基于深度学习的雷达干扰识别技术[D]. 成都: 电子科技大学, 2020.
	LIU Q. Radar interference recognition based on deep learning[D]. Chengdu: University of Electronic Science and Technology of China, 2020.
42	鲍秋香. 频率随机捷变雷达抗扫频干扰性能仿真[J]. 舰船电子对抗, 2021, 44 (5): 78- 81.
	BAO Q X. Simulation of anti-sweep jamming performance of frequency random agility radar[J]. Shipboard Electronic Countermeasure, 2021, 44 (5): 78- 81.
43	吴雪松. 抗灵巧干扰雷达波形设计[D]. 成都: 电子科技大学, 2016.
	WU X S. Design of radar waveforms for anti smart jamming[D]. Chengdu: University of Electronic Science and Technology of China, 2016.
44	黄洪旭, 黄知涛, 周一宇. 对合成孔径雷达的移频干扰研究[J]. 宇航学报, 2006, 27 (3): 463- 468. doi: 10.3321/j.issn:1000-1328.2006.03.027
	HUANG H X, HUANG Z T, ZHOU Y Y. A study on the shift-frequency jamming to SAR[J]. Journal of Astronautics, 2006, 27 (3): 463- 468. doi: 10.3321/j.issn:1000-1328.2006.03.027
45	赵博. 合成孔径雷达欺骗干扰方法研究[D]. 西安: 西安电子科技大学, 2015.
	ZHAO B. Study on methods of synthetic aperture radar deception jamming[D]. Xi’an: Xidian University, 2015.
46	XIA Z F, PAN X R, SONG S J, et al. Vision transformer with deformable attention[C]//Proc. of the IEEE/CVF Conference on Computer Vision and Pattern Recognition, 2022: 4784−4793.
47	KRIZHEVSKY A, SUTSKEVER I, HINTON G E. ImageNet classification with deep convolutional neural networks[J]. Communications of the ACM, 2017, 60 (6): 84- 90. doi: 10.1145/3065386
48	SIMONYAN K, ZISSERMAN A. Very deep convolutional networks for large-scale image recognition[C]//Proc. of the 3rd International Conference on Learning Representations, 2015.
49	HE K M, ZHANG X Y, REN S Q, et al. Deep residual learning for image recognition[C]//Proc. of the IEEE Conference on Computer Vision and Pattern Recognition, 2016: 770−778.
50	DOSOVITSKIY A, BEYER L, KOLESNIKOV A, et al. An image is worth 16x16 words: transformers for image recognition at scale[C]//Proc. of the 8th International Conference on Learning Representations, 2020.

模型	指标	#1	#2	#3	#4	#5	#6	#7
AlexNet	P	90.5	95.4	58.5	50.0	54.7	60.0	63.9
AlexNet	R	69.1	85.6	71.1	68.0	66.0	43.3	73.2
VGG16	P	87.0	97.8	76.1	63.3	64.5	67.7	77.8
VGG16	R	89.7	89.7	72.1	76.3	71.1	47.4	93.9
ResNet18	P	88.8	91.0	73.8	65.1	73.7	67.5	90.0
ResNet18	R	89.7	93.9	81.4	71.1	72.2	53.6	92.8
ResNet50	P	84.0	97.8	72.3	66.3	77.0	55.2	87.3
ResNet50	R	91.8	91.8	75.3	67.0	58.8	66.0	91.8
ResNet101	P	88.0	87.5	75.5	66.1	79.2	63.3	90.5
ResNet101	R	90.7	93.8	76.3	74.2	62.9	63.9	88.7
ViT-B/16	P	93.6	96.0	77.6	74.0	82.4	69.7	93.8
ViT-B/16	R	90.7	96.9	85.6	76.3	72.2	71.1	92.8
本文模型	P	97.9	97.9	76.0	80.9	81.4	73.7	93.9
本文模型	R	95.9	97.9	74.8	74.2	72.2	72.2	95.9

模型	指标	#8	#9	#10	#11	#12	#13	平均值	Acc
AlexNet	P	85.1	100.0	98.9	96.9	100.0	100.0	81.0	@1: 79.1
AlexNet	R	76.3	90.7	87.7	96.9	100.0	100.0	79.0	@5: 96.5
VGG16	P	93.5	100.0	97.9	100.0	100.0	100.0	86.6	@1: 86.2
VGG16	R	88.7	98.0	95.9	98.0	100.0	100.0	86.2	@5: 99.2
ResNet18	P	91.8	100.0	100.0	97.9	100.0	100.0	87.7	@1: 87.7
ResNet18	R	91.2	95.9	99.0	99.0	100.0	100.0	87.7	@5: 99.5
ResNet50	P	92.7	100.0	100.0	97.9	100.0	100.0	87.0	@1: 86.4
ResNet50	R	91.8	92.8	99.0	97.9	100.0	100.0	86.4	@5: 99.4
ResNet101	P	92.7	100.0	100.0	97.0	98.9	98.9	87.5	@1: 87.4
ResNet101	R	91.8	96.9	97.9	98.9	100.0	100.0	87.4	@5: 99.6
ViT-B/16	P	92.9	99.0	100.0	99.0	100.0	100.0	90.6	@1: 90.5
ViT-B/16	R	94.9	98.9	98.9	98.9	100.0	98.9	90.5	@5: 99.7
本文模型	P	96.8	100.0	100.0	100.0	100.0	100.0	92.2	@1: 92.1
本文模型	R	73.8	100.0	100.0	100.0	100.0	100.0	92.1	@5: 100.0
