稀疏贝叶斯学习水声OFDM系统信道与脉冲噪声联合估计

doi:10.12305/j.issn.1001-506X.2025.10.31

摘要/Abstract

摘要：

水声信道中时常存在脉冲噪声（impulsive noise，IN），严重降低水声正交频分复用（orthogonal frequency division multiplexing，OFDM）系统的性能。针对这一问题，提出利用全部子载波的基于广义近似消息传递稀疏贝叶斯学习（generalized approximate message passing-based sparse Bayesian learning，GAMP-SBL）的信道与IN联合估计（joint channel and IN estimation，JCIE）算法及其改进算法。首先，基于信道与IN的联合稀疏性，将数据符号视作未知参数，利用全部子载波构建压缩感知（compressed sensing，CS）模型。然后，使用GAMP-SBL算法恢复联合稀疏向量，并将符号估计引入GAMP-SBL框架中，实现信道冲激响应、IN与数据符号的联合估计。此外，利用初始化数据符号过程中获取的信道与IN先验信息，剔除全部子载波CS模型字典矩阵中的冗余原子，进一步降低计算复杂度。仿真结果表明：所提算法与现有的基于GAMP-SBL的信道与IN估计算法相比，能够有效提高信道估计、IN估计和系统误码性能；与基于SBL的信道与IN估计算法相比，能够在低复杂度情况下保持相近的系统性能。

关键词: 水声通信, 脉冲噪声, 正交频分复用, 信道估计, 稀疏贝叶斯学习

Abstract:

Impulsive noise （IN） often occurs in underwater acoustic channels and severely degrades the performance of underwater acoustic orthogonal frequency division multiplexing （OFDM） systems. To address this issue, a joint channel and IN estimation （JCIE） algorithm based on generalized approximate message passing-based sparse Bayesian learning （GAMP-SBL） using all subcarriers and its improved version are proposed. Firstly, utilizing the joint sparsity of the channel and IN, and regarding the data symbols as unknown parameters, a compressed sensing （CS） model is conceived using all subcarriers. Subsequently, the GAMP-SBL algorithm is applied to recover the joint sparse vector, and the symbol estimation is incorporated into the GAMP-SBL framework to jointly estimate the channel impulse response, IN and data symbols. Moreover, exploiting the prior information of the channel and IN attained during the data symbol initialization, redundant atoms are pruned from the dictionary matrix of the all subcarrier-based CS model to further decrease the computational complexity. Simulation results demonstrate that the proposed algorithms can effectively enhance the performance in terms of the channel estimation, IN estimation, and system bit error rate in comparison with the existing GAMP-SBL-based channel and IN estimation algorithms. And compared with the corresponding SBL-based counterparts, the proposed methods can maintain comparable system performance with lower complexity.

Key words: underwater acoustic communications, impulsive noise （IN）, orthogonal frequency division multiplexing （OFDM）, channel estimation, sparse Bayesian learning （SBL）

中图分类号:

TN 929.3

谭钢, 鄢社锋, 毛琳琳, 杨基睿. 稀疏贝叶斯学习水声OFDM系统信道与脉冲噪声联合估计[J]. 系统工程与电子技术, 2025, 47(10): 3482-3491.

Gang TAN, Shefeng YAN, Linlin MAO, Jirui YANG. Joint channel and impulsive noise estimation for underwater acoustic OFDM systems based on sparse Bayesian learning[J]. Systems Engineering and Electronics, 2025, 47(10): 3482-3491.

图/表 10

图1

图2

表1

表2

图3

图4

图5

图6

图7

图8

参考文献 30

1	BERGER C R, WANG Z H, HUANG J Z, et al. Application of compressive sensing to sparse channel estimation[J]. IEEE Communications Magazine, 2010, 48 (11): 164- 174. doi: 10.1109/MCOM.2010.5621984
2	WANG D Y, ZHANG Y L, TAI Y P, et al. Cluster-aware channel estimation with deep learning method in deep-water acoustic communications[J]. The Journal of the Acoustical Society of America, 2023, 154 (3): 1757- 1769. doi: 10.1121/10.0020861
3	CHEN W X, TAO J, MA L, et al. Vector-approximate-message-passing-based channel estimation for MIMO-OFDM underwater acoustic communications[J]. IEEE Journal of Oceanic Engineering, 2024, 49 (2): 496- 506. doi: 10.1109/JOE.2023.3337349
4	TIAN Y N, HAN X, YIN J W, et al. Group sparse underwater acoustic channel estimation with impulsive noise: simulation results based on Arctic ice cracking noise[J]. The Journal of the Acoustical Society of America, 2019, 146 (4): 2482- 2491. doi: 10.1121/1.5129056
5	TIAN Y N, HAN X, VOROBYOV S A, et al. Wideband signal detection in multipath environment affected by impulsive nois e[J]. The Journal of the Acoustical Society of America, 2022, 152 (1): 445- 455. doi: 10.1121/10.0012352
6	冯晓, 周明章, 张学波, 等. 浅海非高斯噪声下基于变分贝叶斯推断的波达角估计[J]. 电子与信息学报, 2022, 44 (6): 1887- 1896.
	FENG X, ZHOU M Z, ZHANG X B, et al. Variational Bayesian inference based direction of arrival estimation in presence of shallow water non-Gaussian noise[J]. Journal of Electronics & Information Technology, 2022, 44 (6): 1887- 1896.
7	BAI T, ZHANG H M, WANG J J, et al. Fifty years of noise modeling and mitigation in power-line communications[J]. IEEE Communications Surveys & Tutorials, 2021, 23 (1): 41- 69.
8	李冬霞, 刘国庆, 刘海涛. 基于MCMC的OFDM系统脉冲噪声检测与抑制方法[J]. 系统工程与电子技术, 2018, 40 (10): 2348- 2353.
	LI D X, LIU G Q, LIU H T. Impulsive noise detection and mitigation method based on MCMC in OFDM system[J]. Systems Engineering and Electronics, 2018, 40 (10): 2348- 2353.
9	HE Y, ZOU C, LI D J, et al. Adaptive impulsive noise suppression: a deep learning-based parameters estimation approach[J]. IEEE Trans. on Broadcasting, 2023, 69 (2): 505- 515. doi: 10.1109/TBC.2022.3224249
10	谭钢, 鄢社锋, 叶子豪, 等. OFDM系统迭代脉冲噪声抑制与信道估计方法[J]. 系统工程与电子技术, 2024, 46 (8): 2841- 2849.
	TAN G, YAN S F, YE Z H, et al. Iterative impulsive noise mitigation and channel estimation method for OFDM system[J]. Systems Engineering and Electronics, 2024, 46 (8): 2841- 2849.
11	LI Q Y, ZHANG J, EPPLE U. Design and EXIT chart analysis of a doubly iterative receiver for mitigating impulsive interference in OFDM systems[J]. IEEE Trans. on Communications, 2016, 64 (4): 1726- 1738. doi: 10.1109/TCOMM.2016.2535344
12	KUAI X Y, SUN H X, ZHOU S L, et al. Impulsive noise mitigation in underwater acoustic OFDM systems[J]. IEEE Trans. on Vehicular Technology, 2016, 65 (10): 8190- 8202. doi: 10.1109/TVT.2016.2516539
13	CHEN P, RONG Y, NORDHOLM S, et al. Joint channel estimation and impulsive noise mitigation in underwater acoustic OFDM communication systems[J]. IEEE Trans. on Wireless Communications, 2017, 16 (9): 6165- 6178. doi: 10.1109/TWC.2017.2720580
14	CHEN P, RONG Y, NORDHOLM S, et al. Joint channel and impulsive noise estimation in underwater acoustic OFDM systems[J]. IEEE Trans. on Vehicular Technology, 2017, 66 (11): 10567- 10571. doi: 10.1109/TVT.2017.2743220
15	DARSENA D, GELLI G, MELITO F, et al. ICI-free equalization in OFDM systems with blanking preprocessing at receiver for impulsive noise mitigation[J]. IEEE Signal Processing Letters, 2015, 22 (9): 1321- 1325. doi: 10.1109/LSP.2015.2398366
16	LI H, DONG Y Y, GONG C H, et al. A non-Gaussianity-aware receiver for impulsive noise mitigation in underwater communications[J]. IEEE Trans. on Vehicular Technology, 2021, 70 (6): 6018- 6028. doi: 10.1109/TVT.2021.3079469
17	SUN H X, XU X K, MA L, et al. Carrier frequency offset and impulse noise estimation for underwater acoustic orthogonal frequency division multiplexing[J]. Chinese Journal of Acoustics, 2014, 33 (3): 289- 298.
18	LIN J, NASSAR M, EVANS B L. Impulsive noise mitigation in powerline communications using sparse Bayesian learning[J]. IEEE Journal on Selected Areas in Communications, 2013, 31 (7): 1172- 1183. doi: 10.1109/JSAC.2013.130702
19	吕新荣. 低压电力线通信系统抗干扰理论与方法研究[D]. 宁波: 宁波大学, 2019.
	LYU X R. Interference mitigation methods for low voltage power line communication systems[D]. Ningbo: Ningbo University, 2019.
20	WANG S C, HE Z Q, NIU K, et al. New results on joint channel and impulsive noise estimation and tracking in underwater acoustic OFDM systems[J]. IEEE Trans. on Wireless Communications, 2020, 19 (4): 2601- 2612. doi: 10.1109/TWC.2020.2966622
21	AI-SHOUKAIRI M, SCHNITER P, RAO B D. A GAMP-based low complexity sparse Bayesian learning algorithm[J]. IEEE Trans. on Signal Processing, 2018, 66 (2): 294- 308. doi: 10.1109/TSP.2017.2764855
22	殷敬伟, 高新博, 韩笑, 等. 稀疏贝叶斯学习水声信道估计与脉冲噪声抑制方法[J]. 声学学报, 2021, 46 (6): 813- 824.
	YIN J W, GAO X B, HAN X, et al. Underwater acoustic channel estimation and impulsive noise mitigation based on sparse Bayesian learning[J]. Chinese Journal of Acoustics, 2021, 46 (6): 813- 824.
23	FENG X, WANG J F, KUAI X Y, et al. Message passing-based impulsive noise mitigation and channel estimation for underwater acoustic OFDM communications[J]. IEEE Trans. on Vehicular Technology, 2022, 71 (1): 611- 625. doi: 10.1109/TVT.2021.3130061
24	洪丹阳, 王巍, 尹力, 等. 改进的时序多重稀疏贝叶斯学习冰下水声信道估计方法[J]. 声学学报, 2022, 47 (5): 591- 602.
	HONG D Y, WANG W, YIN L, et al. An improved temporal multiple sparse Bayesian learning under-ice acoustic channel estimation method[J]. Chinese Journal of Acoustics, 2022, 47 (5): 591- 602.
25	WAN L, ZHU J, CHENG E, et al. Joint CFO, gridless channel estimation and data detection for underwater acoustic OFDM systems[J]. IEEE Journal of Oceanic Engineering, 2022, 47 (4): 1215- 1230. doi: 10.1109/JOE.2022.3162025
26	叶子豪, 鄢社锋, 杨斌斌. 基于子载波间干扰深度估计的MIMO-OFDM水声通信接收机[J]. 电子与信息学报, 2023, 45 (7): 2519- 2527.
	YE Z H, YAN S F, YANG B B. MIMO-OFDM underwater acoustic communication receiver based on intercarrier interfe-rence depth estimation[J]. Journal of Electronics & Information Technology, 2023, 45 (7): 2519- 2527.
27	YU H, LIANG Y K, MA H N, et al. Joint impulsive noise mitigation and sparse channel estimation for mobile underwater acoustic communication[J]. IEEE Wireless Communications Letters, 2024, 13 (8): 2095- 2099. doi: 10.1109/LWC.2024.3401695
28	PANAYIRCI E, ALTABBAA M T, UYSAL M, et al. Sparse channel estimation for OFDM-based underwater acoustic systems in Rician fading with a new OMP-MAP algorithm[J]. IEEE Trans. on Signal Processing, 2019, 67 (6): 1550- 1565. doi: 10.1109/TSP.2019.2893841
29	WANG J J, YAN Z Q, SHI W, et al. Underwater acoustic sparse channel estimation based on DW-SACoSaMP reconstruction algorithm[J]. IEEE Communications Letters, 2019, 23 (11): 1985- 1988. doi: 10.1109/LCOMM.2019.2933426
30	TADAYON A, STOJANOVIC M. Iterative sparse channel estimation and spatial correlation learning for multichannel acoustic OFDM systems[J]. IEEE Journal of Oceanic Engineering, 2019, 44 (4): 820- 836. doi: 10.1109/JOE.2019.2932662

估计算法		复杂度	文献
SBL类（-S）	SCIE-S	O（UK²+PL²）	[22]
	JCIE-S	O（PN²）	[20]
	JCIEA-S	O（PN²+KN²）	[19]
GAMP-SBL类（-GS）	SCIE-GS	O（UK+PL）	[22]
	JCIE-GS	O（PN）	[23]
	JCIEA-GS	O（PN+KN）	本文
	JCIEA-GSP	O（PN+KM）	本文

参数	值
带宽B/kHz	4
中心频率f_c/kHz	12
采样频率f_s/kHz	96
子载波数K	512
子载波间隔Δf/Hz	7.8
OFDM符号周期T/ms	128
循环前缀T_cp/ms	25
