考虑力学形变的相控阵天线波束控制实现策略

doi:10.12305/j.issn.1001-506X.2025.08.01

摘要/Abstract

摘要：

针对相控阵天线在受载变形下的实时波束控制问题，提出一种基于神经网络等效的天线波束控制策略，其具有等效不同电控函数的能力，且适合于硬件编程实现。通过计算资源分配及并行化编程，形成了该策略的控制器，其对于不同形变具有适配性。相关研究对于实验室内天线阵面受载变形的波束控制有效性测评具有支撑作用。

关键词: 相控阵天线, 波束控制, 可编程逻辑器件, 神经网络, 力学形变

Abstract:

Aiming at the beam control problem of phased array antennas under mechanical deformations, this study presents a beam control strategy which utilizes the equivalent neural networks to fit the various electric control functions, making it highly compatible with hardware programming implementations. By appropriately allocating computational resource and employing parallel programming techniques, a controller of the proposed strategy is designed, which is feasible for various deformations. This work has the ability to support the effectiveness evaluating of the beam performance of phased array antennas within laboratory environments when the possible mechanical deformations are considered.

Key words: phased array, beam control, field-programmable gate array （FPGA）, neural network, mechanical deformation

中图分类号:

TN 957.51

王奇, 潘宇宁, 郑峻峰, 王力. 考虑力学形变的相控阵天线波束控制实现策略[J]. 系统工程与电子技术, 2025, 47(8): 2421-2428.

Qi WANG, Yuning PAN, Junfeng ZHENG, Li WANG. Implementation strategy of phased array beam control considering mechanical deformation[J]. Systems Engineering and Electronics, 2025, 47(8): 2421-2428.
