基于无监督学习的均匀圆阵二维测向方法

doi:10.12305/j.issn.1001-506X.2026.02.05

摘要/Abstract

摘要：

为解决均匀圆阵二维超分辨测向问题，提出一种基于无监督深度神经网络的测向框架。首先，将二维波达方向估计问题转化为稀疏功率谱重构，采用深度神经网络建立空域协方差向量到二维稀疏谱的端到端映射。进一步，通过构造稀疏特征约束的损失函数，实现无监督模式下二维稀疏谱的空间结构特征学习。网络训练完成后，通过对网络输出进行聚类后处理获得二维角度的准确估计。仿真表明，所提方法在二维方向上实现了准确的角度估计，对未知场景具有较好的泛化性和鲁棒性，并且在低信噪比和小快拍数的情况下具有较高的估计精度。

关键词: 均匀圆阵, 超分辨二维测向, 深度神经网络, 无监督学习

Abstract:

An direction finding framework based on unsupervised deep neural networks is proposed for the uniform circular array super-resolution direction finding problem. First, a two-dimensional direction of arrival （DOA） estimation problem is transformed into sparse power spectrum reconstruction, where a deep neural network establishes an end-to-end mapping from spatial covariance vectors to sparse spectrum. Furthermore, a loss function with sparse feature constraints is constructed to learn two-dimensional spatial structural features of sparse spectrum in an unsupervised manner. Upon the completion of network training, accurate two-dimensional angle estimates are obtained through clustering post-processing of network outputs. Simulation results demonstrate that the proposed method achieves accurate angle estimation in two dimensions, excellent generalization and robustness in unknown scenarios, achieving high estimation accuracy in low signal-to-noise ratio and limited snapshots.

Key words: uniform circular array, super-resolution two-dimensional direction finding, deep neural network, unsupervised learning

中图分类号:

TN 911.7

吴双, 蒲泓宇, 付泰, 罗太元. 基于无监督学习的均匀圆阵二维测向方法[J]. 系统工程与电子技术, 2026, 48(2): 422-429.

Shuang WU, Hongyu PU, Tai FU, Taiyuan LUO. 2D direction finding method with uniform circular array based on unsupervised learning[J]. Systems Engineering and Electronics, 2026, 48(2): 422-429.
