基于广义逆高斯纹理结构的目标检测算法

doi:10.12305/j.issn.1001-506X.2024.12.10

摘要/Abstract

摘要：

针对海杂波模型选择失配现象以及由假定海杂波纹理结构完全非均匀导致的相干检测器性能损失问题, 提出基于广义逆高斯(generalized inverse Gaussian, GIG)纹理结构空间相关性的目标检测算法。首先, 分析相关杂波背景下的目标检测模型, 引入海杂波纹理结构的空间相关性并将其作为先验信息；随后，基于两步广义似然比检测(generalized likelihood ratio test, GLRT)准则推导相关GIG纹理背景下的相干检测器。最后，通过理论证明所提检测器对散斑协方差矩阵和目标多普勒导向矢量具有恒虚警特性。基于仿真测试的实验结果和实测数据表明, 所提检测器在均匀和部分均匀杂波背景下均提升了对海面目标的检测性能。

关键词: 海杂波, 广义逆高斯纹理, 纹理空间相关性, 相干检测

Abstract:

A target detection algorithm based on generalized inverse Gaussian (GIG) texture structure spatial correlation is proposed to address the performance loss of coherent detectors caused by mismatched selection of sea clutter models and the assumption of completely non-uniform of sea clutter texture structures. Firstly, the target detection model under correlated clutter background is analyzed, and the spatial correlation of sea clutter texture structure is introduced as prior information. Then, based on the two-step generalized likelihood ratio test (GLRT) criterion, the coherent detector under correlated GIG texture background is derived. Finally, it is theoretically proved that the proposed detector has constant false alarm characteristics for speckle covariance matrix and target Doppler guidance vector. The experimental results based on simulation test and measured data show that the proposed detector improves the detection performance of sea surface targets in both uniform and partially uniform clutter backgrounds.

Key words: sea clutter, generalized inverse Gaussian (GIG) texture, texture spatial correlation, coherent detection

中图分类号:

TN911.23

陈铎, 范一飞, 粟嘉, 郭子薰, 陶明亮. 基于广义逆高斯纹理结构的目标检测算法[J]. 系统工程与电子技术, 2024, 46(12): 4018-4025.

Duo CHEN, Yifei FAN, Jia SU, Zixun GUO, Mingliang TAO. Target detection algorithm based on generalized inverse Gaussian texture structure[J]. Systems Engineering and Electronics, 2024, 46(12): 4018-4025.

图/表 11

图1

图2

图3

图4

图5

表1

图6

图7

图8

图9

图10

参考文献 30

1	许述文, 白晓惠, 郭子薰, 等. 海杂波背景下雷达目标特征检测方法的现状与展望[J]. 雷达学报, 2020, 9 (4): 684- 714.
	XU S W , BAI X H , GUO Z X , et al. Status and prospects of feature-based detection methods for floating targets on the sea surface[J]. Journal of Radars, 2020, 9 (4): 684- 714.
2	WANG Z H , HE Z S , QIN H , et al. Adaptive CFAR detectors for mismatched signal in compound Gaussian sea clutter with inverse Gaussian texture[J]. IEEE Geoscience and Remote Sensing Letters, 2022, 19, 3502705.
3	KAMMOUN A , COUILLET R , PASCAL F , et al. Optimal design of the adaptive normalized matched filter detector using regularized Tyler estimators[J]. IEEE Trans. on Aerospace and Electronic Systems, 2018, 54 (2): 755- 769. doi: 10.1109/TAES.2017.2766538
4	FAN Y F , TAO M L , SU J , et al. Analysis of goodness-of-fit method based on local property of statistical model for airborne sea clutter data[J]. Digital Signal Processing, 2020, 99, 102653. doi: 10.1016/j.dsp.2019.102653
5	XIN Z H , LIAO G S , YANG Z W , et al. Analysis of distribution using graphical goodness of fit for airborne SAR sea-clutter data[J]. IEEE Trans. on Geoscience and Remote Sensing, 2017, 55 (10): 5719- 5728. doi: 10.1109/TGRS.2017.2712700
6	YU H , SHUI P L , ZENG W L , et al. Outlier-robust tri-percentile parameter estimation of K-distributions[J]. Signal Processing, 2021, 181, 107906. doi: 10.1016/j.sigpro.2020.107906
7	YANG Y , FENG D J , ZHANG W M , et al. Modelling and simulation of spatial-temporal correlated K-distributed clutter for coherent radar seeker[J]. IET Radar, Sonar & Navigation, 2014, 8 (1): 1- 8.
8	DONG Y . Optimal coherent radar detection in a K-distributed clutter environment[J]. IET Radar, Sonar & Navigation, 2012, 6 (5): 283- 292.
9	SHI S N , SHUI P L . Optimum coherent detection in homogenous K-distributed clutter[J]. IET Radar, Sonar & Navigation, 2016, 10 (8): 1477- 1484.
10	YU H , SHUI P L , ZENG W L , et al. Bipercentile parameter estimators of bias reduction generalised Pareto clutter model[J]. IET Radar, Sonar & Navigation, 2020, 14 (7): 1105- 1112.
11	LIANG X , YU H , ZOU P J , et al. Multiscan recursive Bayesian parameter estimation of large-scene spatial-temporally varying generalized Pareto distribution model of sea clutter[J]. IEEE Trans. on Geoscience and Remote Sensing, 2020, 60, 5115416.
12	SANGSTON K J , GINI F , GRECO M V . Coherent radar target detection in heavy-tailed compound-Gaussian clutter[J]. IEEE Trans. on Aerospace and Electronic Systems, 2012, 48 (1): 64- 77.
13	SHUI P L , SHI L X , YU H , et al. Iterative maximum likelihood and outlier-robust bipercentile estimation of parameters of compound-Gaussian clutter with inverse Gaussian texture[J]. IEEE Signal Processing Letters, 2016, 23 (11): 1572- 1576.
14	水鹏朗, 田超, 封天. 逆高斯纹理复合高斯杂波对异常样本稳健的三分位点估计方法[J]. 电子与信息学报, 2023, 45 (2): 542- 549.
	SHUI P L , TIAN C , FENG T . Outlier-robust tri-percentile parameter estimation method of compound-Gaussian clutter with inverse Gaussian textures[J]. Journal of Electronics and Information Technology, 2023, 45 (2): 542- 549.
15	XUE J, XU S H. Parameters estimation based on moments and Nelder-Mead algorithm for compound-Gaussian clutter with inverse Gaussian texture[C]//Proc. of the IEEE International Conference on Signal Processing Communications and Computing, 2016.
16	CHEN S J , KONG L J , YANG J Y . Adaptive detection in compound Gaussian clutter with inverse Gaussian texture[J]. Progress in Electromagnetics Research M, 2013, 28, 157- 167.
17	施赛楠, 水鹏朗, 杨春娇, 等. 基于逆高斯纹理空间相关性的雷达目标检测[J]. 系统工程与电子技术, 2017, 39 (10): 2215- 2220. doi: 10.3969/j.issn.1001-506X.2017.10.09
	SHI S N , SHUI P L , YANG C J , et al. Radar target detection based on spatial correlation of inverse-Gaussian texture[J]. Systems Engineering and Electronics, 2017, 39 (10): 2215- 2220. doi: 10.3969/j.issn.1001-506X.2017.10.09
18	LIU J , SUN S Y , LIU W J . One-step persymmetric GLRT for subspace signals[J]. IEEE Trans. on Signal Processing, 2019, 67 (14): 3639- 3648.
19	WANG Z H , HE Z S , QIN H , et al. Persymmetric range-spread targets detection in compound Gaussian sea clutter with inverse Gaussian texture[J]. IEEE Geoscience and Remote Sensing Letters, 2022, 19, 1- 5.
20	WANG Z H , HE Z S , QIN H , et al. Persymmetric adaptive target detection with dual-polarization in compound Gaussian sea clutter with inverse Gamma texture[J]. IEEE Trans. on Geoscience and Remote Sensing, 2022, 60, 1- 17.
21	XUE J , XU S W , SHUI P L . Knowledge-based target detection in compound Gaussian clutter with inverse Gaussian texture[J]. Digital Signal Processing, 2019, 95, 102590.
22	XUE J , XU S W , LIU J , et al. Bayesian detection for radar targets in compound-Gaussian sea clutter[J]. IEEE Geoscience and Remote Sensing Letters, 2022, 19, 4020805.
23	薛健, 朱圆玲, 潘美艳. 基于海杂波先验知识的雷达目标自适应Rao检测[J]. 电子与信息学报, 2023, 45 (11): 3839- 3847.
	XUE J , ZHU Y L , PAN M Y . Adaptive Rao detection of radar targets based on the priori-knowledge of sea clutter[J]. Journal of Electronics and Information Technology, 2023, 45 (11): 3839- 3847.
24	时艳玲, 林毓峰, 宛汀. 部分均匀海杂波中雷达目标的平滑自适应检测[J]. 系统工程与电子技术, 2016, 38 (12): 2745- 2751.
	SHI Y L , LIN Y F , WAN T . Smooth adaptive detector for radar target in partially homogeneous sea clutter environment[J]. Systems Engineering and Electronics, 2016, 38 (12): 2745- 2751.
25	XUE J , XU S W , LIU J , et al. Model for non-Gaussian sea clutter amplitudes using generalized inverse Gaussian texture[J]. IEEE Geoscience and Remote Sensing Letters, 2019, 16 (6): 892- 896.
26	薛健. 复合高斯海杂波背景雷达目标检测算法[D]. 西安: 西安电子科技大学, 2020.
	XUE J. Radar target detection methods in compound-Gaussian sea clutter[D]. Xi'an: Xidian University, 2020.
27	XU S W , WANG Z X , BAI X H , et al. Optimum and near- optimum coherent CFAR detection of radar targets in compound- Gaussian clutter with generalized inverse Gaussian texture[J]. IEEE Trans. on Aerospace and Electronic Systems, 2022, 58 (3): 1692- 1706.
28	PASCAL F , FORSTER P , OVARLEZ J , et al. Performance analysis of covariance matrix estimates in impulsive noise[J]. IEEE Trans. on Signal Processing, 2008, 56 (6): 2206- 2217.
29	HAYKIN S. The IPIX radar database[EB/OL]. [2023-10-20]. http://soma.ece.mcmaster.ca/ipix/.
30	刘宁波, 丁昊, 黄勇, 等. X波段雷达对海探测试验与数据获取年度进展[J]. 雷达学报, 2021, 10 (1): 173- 182.
	LIU N B , DING H , HUANG Y , et al. Annual progress of the sea-detecting X-band radar and data acquisition program[J]. Journal of Radars, 2021, 10 (1): 173- 182.

参数	数据1	数据2
脉冲重复频率/Hz	1 000	1 697
距离分辨率/m	30	6
极化方式	HH/HV/VH/VV	HH
海况	3~4	-
