基于数值仿真的X波段极化SAR海杂波统计建模与特性分析

doi:10.12305/j.issn.1001-506X.2021.10.06

摘要/Abstract

摘要：

针对3~5级海况下X波段极化合成孔径雷达(synthetic aperture radar, SAR)海杂波的仿真和统计建模, 首先利用Apel海浪谱模型和Monte Carlo方法仿真不同风速下的大尺寸二维粗糙海面, 进而分别利用物理光学模型和弹跳射线法两种高频电磁散射模型考虑海面的单次散射和多次散射, 实现大尺寸海面的极化SAR海杂波仿真, 并利用X波段地球物理模式函数和岸基实测海杂波对仿真海杂波的精度和统计分布进行验证。基于仿真海杂波数据, 利用典型的乘积模型和Mellin类统计量开展海杂波统计建模和特性分析。仿真结果表明, 在2 m×2 m的高分辨率条件下, X波段同极化海杂波并不服从适用于中低分辨率海杂波的K分布, 且在不同风速风向下呈现出不同的纹理特征; X波段交叉极化海杂波表现出较弱的纹理特征, 服从Wishart分布; 随着入射角和雷达视数的增大, 海杂波的纹理特征逐渐减弱。

关键词: 海杂波, 极化合成孔经雷达, 电磁散射仿真, Mellin类统计量

Abstract:

This paper focuses on the numerical simulation and statistical modeling of X-band polarimetric synthetic aperture radar (SAR) sea clutter under level 3~5 sea states. Firstly, by using Apel spectrum and Monte Carlo method, we generate large-scale two-dimensional rough ocean surfaces at various wind speeds. Then, the high-frequency electromagnetic scattering methods are employed simulate polarimetric SAR sea clutter. In particular, the physical optics method and the shooting and bouncing ray method are used to separately consider the single scattering and multiple scattering on sea surfaces. The accuracy and statistical distribution of simulated sea clutter are validated using X-band geophysical mode function and the shore-based measurement. Finally, based on the simulated sea clutter data, the statistical modeling and characteristic analyses of sea clutter are conducted using typical product models and Mellin-kind statistics. The simulation results indicate that, at the high resolution of 2 m×2 m, the X-band co-pol sea clutter does not obey the classic K distribution which performs well for low-to-moderate resolution sea clutter, and presents different texture properties at various wind speeds and wind directions. X-band cross-pol sea clutter shows weak texture characteristics and basically obeys the Wishart distribution. With the increase of incident angle and radar look number, the texture characteristics of sea clutter gradually weaken.

Key words: sea clutter, polarimetric synthetic aperture radar (SAR), electromagnetic scattering simulations, Mellin-kind statistics

中图分类号:

TN95

杜延磊, 高帆, 刘涛, 杨健. 基于数值仿真的X波段极化SAR海杂波统计建模与特性分析[J]. 系统工程与电子技术, 2021, 43(10): 2742-2755.

Yanlei DU, Fan GAO, Tao LIU, Jian YANG. Statistical modeling and characteristic analysis of polarimetric SAR sea clutter at X-band based on numerical simulations[J]. Systems Engineering and Electronics, 2021, 43(10): 2742-2755.

图/表 14

图1

图2

表1

海面棱边散射几何示意图及参数定义"

分布模型	纹理参数τ		散射向量k的PDF	极化协方差矩阵C的PDF	公式编号
分布模型	模型	PDF	散射向量k的PDF	极化协方差矩阵C的PDF	公式编号
K分布	γ分布	$ p(\tau ; \alpha)=\frac{\alpha^{\alpha}}{\Gamma(\alpha)} \tau^{\alpha-1} \exp (-\alpha \tau) $	$ \begin{array}{c}p_{k}(k ; \alpha, L, \boldsymbol{\Sigma})=\frac{2 L^{L d}\left(\boldsymbol{k}^{\mathrm{H}} \boldsymbol{k}\right)^{L-\frac{d}{2}}}{\Gamma_{d}(L)\|\boldsymbol{\Sigma}\|^{L}} \frac{2 \alpha{\frac{\alpha+Ld}{2} }}{\Gamma(\alpha)}\left(L \boldsymbol{k}^{\mathrm{H}} \boldsymbol{\Sigma}^{-1} \boldsymbol{k}\right) \frac{\alpha-L d}{2} \times \\K_{\alpha-L d}\left(2 \sqrt{L_{\alpha} \boldsymbol{k}^{\mathrm{H}} \boldsymbol{\Sigma}^{-1} \boldsymbol{k}}\right)\end{array} $	$ \begin{array}{c}p_{C}(\boldsymbol{C} ; \alpha, L, \boldsymbol{\Sigma})= \\\frac{L^{L d}}{\Gamma_{d}(L)} \frac{\|\boldsymbol{C}\|^{L-d}}{\|\boldsymbol{\Sigma}\|^{L}} \frac{2 \alpha{\frac{\alpha+L d}{2}}}{\Gamma(\alpha)}\left(L \operatorname{tr}\left(\boldsymbol{\Sigma}^{-1} \boldsymbol{C}\right)\right){\frac{\alpha-L d}{2}} \times \\K_{\alpha-L d}\left[2 \sqrt{\alpha L\operatorname{tr}\left(\boldsymbol{\Sigma}^{-1} \boldsymbol{C}\right)}\right]\end{array} $	(32)
G⁰分布	逆γ分布	$ p(\tau ; \lambda)=\frac{(\lambda-1)^{\lambda}}{\Gamma(\lambda)} \tau^{-\lambda-1} \exp \left(-\frac{\lambda-1}{\tau}\right) $	$ \begin{aligned}p_{k}(k ; \lambda, L, \boldsymbol{\Sigma}) &=\frac{2 L^{L d}\left(\boldsymbol{k}^{\mathrm{H}} \boldsymbol{k}\right)^{L-\frac{d}{2}}}{\Gamma_{d}(L)\|\boldsymbol{\Sigma}\|^{L}} \frac{\Gamma(\lambda+L d)(\lambda-1)^{\lambda}}{\Gamma(\lambda)} \times \\&\left(\lambda-1+L \boldsymbol{k}^{\mathrm{H}} \boldsymbol{\Sigma}^{-1} \boldsymbol{k}\right)^{-\lambda-L d}\end{aligned} $	$ \begin{array}{c}p_{C}(\boldsymbol{C} ; \lambda, L, \boldsymbol{\Sigma})=\frac{L^{L d}\|\boldsymbol{C}\|^{L-d}}{\Gamma_{d}(L)\|\boldsymbol{\Sigma}\|^{L}} \frac{\Gamma(\lambda+L d)(\lambda-1)^{\lambda}}{\Gamma(\lambda)} \times \\{\left[\lambda-1+L \operatorname{tr}\left(\boldsymbol{\Sigma}^{-1} \boldsymbol{C}\right)\right]^{-\lambda-L d}}\end{array} $	(33)
Kummer-U分布	Fisher分布	$ \begin{array}{l}p(\tau ; \xi, \zeta)=\frac{\Gamma(\xi+\zeta)}{\Gamma(\xi) \Gamma(\zeta)} \frac{\xi}{\zeta-1} \times \\\left(\frac{\xi}{\zeta-1} \tau\right)^{\xi-1}\left(\frac{\xi}{\zeta-1} \tau+1\right)^{-\xi-\zeta}\end{array} $	$ \begin{array}{c}p_{k}(k ; \xi, \zeta, L, \boldsymbol{\Sigma})= \\\frac{2 L^{L d}\left(\boldsymbol{k}^{\mathrm{H}} \boldsymbol{k}\right)^{L-\frac{d}{2}}}{\Gamma_{d}(L)\|\boldsymbol{\Sigma}\|^ L} \frac{\Gamma(\xi+\zeta) \Gamma(\zeta+L d)}{\Gamma(\xi) \Gamma(\zeta)}\left(\frac{\xi}{\zeta-1}\right)^{L d} \times \\\boldsymbol{U}\left(L d+\zeta, L d-\xi+1, \frac{\xi}{\zeta-1} L \boldsymbol{k}^{\mathrm{H}} \boldsymbol{\Sigma}^{-1} \boldsymbol{k}\right)\end{array} $	$ \begin{array}{c}p_{C}(\boldsymbol{C} ; \xi, \zeta, L, \boldsymbol{\Sigma})= \\\frac{L^{L d}\|\boldsymbol{C}\|^{L-d}}{\Gamma_{d}(L)\|\boldsymbol{\Sigma}\|^{L}} \frac{\Gamma(\xi+\boldsymbol{\zeta}) \Gamma(\zeta+L d)}{\Gamma(\xi) \Gamma(\zeta)}\left(\frac{\xi}{\zeta-1}\right)^{L d} \times \\\boldsymbol{U}\left(L d+\zeta, L d-\xi+1, \frac{\xi}{\zeta-1} L \operatorname{tr}\left(\boldsymbol{\Sigma}^{-1} \boldsymbol{C}\right)\right)\end{array} $	(34)
W分布	β分布	$ \begin{array}{c}p(\tau ; \xi, \zeta)=\frac{\Gamma(\zeta)}{\Gamma(\xi) \Gamma(\zeta-\xi)} \frac{\xi}{\zeta} \times \\\left(\frac{\xi}{\zeta} \tau\right)^{\xi-1}\left(1-\frac{\xi}{\zeta} \tau\right)^{\zeta-\xi-1} \\, \tau \in[0, \zeta / \xi]\end{array} $	$ \begin{array}{c}p_{k}(k ; \xi, \zeta, L, \boldsymbol{\Sigma})=\\\frac{2 L^{L d}\left(\boldsymbol{k}^{\mathrm{H}} \boldsymbol{k}\right)^{L-\frac{d}{2}}}{\Gamma_{d}(L)\|\boldsymbol{\Sigma}\|^{L}} \frac{\Gamma(\zeta)}{\Gamma(\xi)}\left(\frac{\xi}{\zeta}\right)^{\frac{\xi+L d-1}{2}}\left(L \boldsymbol{k}^{\mathrm{H}} \boldsymbol{\Sigma}^{-1} \boldsymbol{k}\right) \frac{{\xi}-L d-1}{2} \times\\\exp \left(-\frac{\xi}{2 \zeta} L \boldsymbol{k}^{\mathrm{H}} \boldsymbol{\Sigma}^{-1} \boldsymbol{k}\right) W \frac{L d+1+\xi-2 \xi}{2}, \frac{\xi-L d}{2}\left(\frac{\xi}{\zeta} L \boldsymbol{k}^{\mathrm{H}} \boldsymbol{\Sigma}^{-1} \boldsymbol{k}\right)\end{array} $	$ \begin{array}{c}p_{C}(\boldsymbol{C} ; \xi, \zeta, L, \boldsymbol{\Sigma})= \\\frac{L^{L d}\|\boldsymbol{C}\|^{L-d}}{\Gamma_{d}(L)\|\boldsymbol{\Sigma}\|^{L}} \frac{\Gamma(\zeta)}{\Gamma(\xi)}\left(\frac{\xi}{\zeta}\right)^{\frac{\xi+l d-1}{2}}\left[L\operatorname{tr}\left(\boldsymbol{\Sigma}^{-1} \boldsymbol{C}\right)\right]^{\frac{{\xi}{-} L d-1}{2}} \times \\\exp \left(-\frac{\xi}{2 \zeta} L \operatorname{tr}\left(\boldsymbol{\Sigma}^{-1} \boldsymbol{C}\right)\right) W \frac{L d+1+\xi-2 \zeta}{2}, \frac{\hat{s}-L d}{2}\left(\frac{\xi}{\zeta} L \operatorname{tr}\left(\boldsymbol{\Sigma}^{-1} \boldsymbol{C}\right)\right)\end{array} $	(35)
M分布	逆β分布	$ \begin{array}{c}p(\tau ; \xi, \zeta)=\frac{\Gamma(\zeta)}{\Gamma(\xi) \Gamma(\zeta-\xi)} \frac{\zeta-1}{\xi-1} \times \\\left(\frac{\zeta-1}{\xi-1} \tau\right)^{-\zeta}\left(\frac{\zeta-1}{\xi-1} \tau-1\right)^{\zeta-\xi-1} ,\\ \tau>\xi-1 / \zeta-1\end{array} $	$ \begin{array}{c}p_{k}(k ; \xi, \zeta, L, \boldsymbol{\Sigma})= \\\frac{2 L^{L d}\left(\boldsymbol{k}^{\mathrm{H}} \boldsymbol{k}\right)^{L-\frac{d}{2}}}{\Gamma_{d}(L)\|\boldsymbol{\Sigma}\|^{L}} \frac{\Gamma(\zeta) \Gamma(\xi+L d)}{\Gamma(\xi) \Gamma(\zeta+L d)}\left(\frac{\zeta-1}{\xi-1}\right)^{L d} \times \\M\left(\xi+L d, \zeta+L d,-\frac{\zeta-1}{\xi-1} L \boldsymbol{k}^{\mathrm{H}} \boldsymbol{\Sigma}^{-1} \boldsymbol{k}\right)\end{array} $	$ \begin{array}{c}p_{C}(\boldsymbol{C} ; \xi, \zeta, L, \boldsymbol{\Sigma})= \\\frac{L^{L d}\|\boldsymbol{C}\|^{L-d}}{\Gamma_{d}(L)\|\boldsymbol{\Sigma}\|^{L}} \frac{\Gamma(\zeta) \Gamma(\xi+L d)}{\Gamma(\xi) \Gamma(\zeta+L d)}\left(\frac{\zeta-1}{\xi-1}\right)^{L d} \times \\M\left(\xi+L d, \zeta+L d,-\frac{\zeta-1}{\xi-1} L \operatorname{tr}\left(\boldsymbol{\Sigma}^{-1} \boldsymbol{C}\right)\right)\end{array} $	(36)

表1

表2

图3

图4

图5

图6

图7

图8

图9

图10

图11

图12

参考文献 33

1	丁昊, 刘宁波, 董云龙, 等. 雷达海杂波测量试验回顾与展望[J]. 雷达学报, 2019, 8 (3): 281- 302.
	DING H , LIU N B , DONG Y L , et al. Overview and prospects of radar sea clutter measurement experiments[J]. Journal of Radars, 2019, 8 (3): 281- 302.
2	许述文, 白晓惠, 郭子薰, 等. 海杂波背景下雷达目标特征检测方法的现状与展望[J]. 雷达学报, 2020, 9 (4): 684- 714.
	XU S W , BAI X H , GUO Z X , et al. Status and prospects of feature-based detection methods for floating targets on the sea surface[J]. Journal of Radars, 2020, 9 (4): 684- 714.
3	刘宁波, 董云龙, 王国庆, 等. X波段雷达对海探测试验与数据获取[J]. 雷达学报, 2019, 8 (5): 656- 667.
	LIU N B , DONG Y L , WANG G Q , et al. Sea-detecting X-band radar and data acquisition program[J]. Journal of Radars, 2019, 8 (5): 656- 667.
4	丁昊, 董云龙, 刘宁波, 等. 海杂波特性认知研究进展与展望[J]. 雷达学报, 2016, 5 (5): 499- 516.
	DING H , DONG Y L , LIU N B , et al. Overview and prospects of research on sea clutter property cognition[J]. Journal of Radars, 2016, 5 (5): 499- 516.
5	TSANG L , KONG J A , SHIN R T . Scattering of electromagnetic waves: numerical simulations[M]. New York: Wiley, 2000, 2nd ed
6	ULABY F T , LONG D G . Microwave radar and radiometric remote sensing[M]. Ann Arbor: University of Michigan Press, 2015.
7	FUNG A K . Microwave scattering and emission models and their applications[M]. Boston: Artech House, 1994.
8	杨健, 殷君君. 极化雷达理论与遥感应用[M]. 北京: 科学出版社, 2020.
	YANG J , YIN J J . Polarimetric radar theory and remote sensing application[M]. Beijing: Science Press, 2020.
9	LIU T , ZHANG J F , GAO G , et al. CFAR ship detection in polarimetric synthetic aperture radar images based on whitening filter[J]. IEEE Trans.on Geoscience and Remote Sensing, 2020, 58 (1): 58- 81. doi: 10.1109/TGRS.2019.2931353
10	DENG X P , LOPEZ-MARTINEZ C , CHEN J S , et al. Statistical modeling of polarimetric sar data: a survey and challenges[J]. Remote Sensing, 2017, 9 (4): 25817172.
11	郭立新, 王蕊, 吴振森. 随机粗糙面散射的基本理论与方法[M]. 北京: 科学出版社, 2010.
	GUO L X , WANG R , WU Z S . Basic theory and method of random rough surface scattering[M]. Beijing: Science Press, 2010.
12	石志广, 周剑雄, 付强. K分布海杂波参数估计方法研究[J]. 信号处理, 2007, (3): 420- 424. doi: 10.3969/j.issn.1003-0530.2007.03.023
	SHI Z G , ZHOU J X , FU Q . Parameter estimation study of K distributed sea clutter[J]. Signal Processing, 2007, (3): 420- 424. doi: 10.3969/j.issn.1003-0530.2007.03.023
13	吴振森, 衣方磊. 一维动态海面的电磁散射杂波模拟和参数估计[J]. 电波科学学报, 2003, (2): 132- 137. doi: 10.3969/j.issn.1005-0388.2003.02.003
	WU Z S , YI F L . Numerical simulation and parameters estimation of scattering clutter from 1-D time-varying sea surface[J]. Chinese Journal of Radio Science, 2003, (2): 132- 137. doi: 10.3969/j.issn.1005-0388.2003.02.003
14	NICOLAS J M . Introduction to second kind statistics: application of Log-moments and Log-cumulants to SAR image law analysis[J]. Traitement du Signal, 2002, 19 (3): 139- 167.
15	ANFINSEN S N , ELTOFT T . Application of the matrix-variate mellin transform to analysis of polarimetric radar images[J]. IEEE Trans.on Geoscience and Remote Sensing, 2011, 49 (6): 2281- 2295. doi: 10.1109/TGRS.2010.2103945
16	杜延磊. 随机粗糙海面微波散射/辐射的仿真与分析: 解析近似模型和数值方法[D]. 北京: 中国科学院遥感与数字地球研究所, 2019.
	DU Y L. Simulations and analyses of microwave scattering and emission from randomly rough ocean surfaces: analytic approximate models and numerical methods[D]. Beijing: Institute of Remote Sensing and Digital Earth, Chinese Academy of Sciences, 2019.
17	DU Y L , YIN J J , TAN S R . A numerical study of roughness scale effects on ocean radar scattering using the second-order SSA and the moment method[J]. IEEE Trans.on Geoscience and Remote Sensing, 2020, 58 (10): 6874- 6887. doi: 10.1109/TGRS.2020.2977368
18	QIAO T , DU Y L , TSANG L , et al. Radar scattering of ocean surface with anisotropic ocean spectrum using NMM3D simulations[M]. Boca Raton: CRC Press, 2018.
19	APEL J R . An improved model of the ocean surface-wave vector spectrum and its effects on radar backscatter[J]. Geophys Res-Oceans, 1994, 9 (8): 16269- 16291.
20	DU Y L , YANG X F , CHEN K S , et al. An improved spectrum model for sea surface radar backscattering at L-band[J]. Remote Sensing, 2017, 9 (8): 25251- 25267.
21	QIAO T , DU Y L , TSANG L . Electromagnetic scattering and emission by ocean surfaces based on neighborhood impedance boundary condition (NIBC) with dense grid: accurate emissivity and sensitivity to salinity[J]. Progress in Electromagnetics Research B, 2018, 81, 141- 162. doi: 10.2528/PIERB18050706
22	HASTINGS F D , SCHNEIDER J B , BROSCHAT S , et al. An FDTD method for analysis of scattering from rough fluid-fluid interfaces[J]. IEEE Journal of Oceanic Eng, 2001, 26 (1): 94- 101. doi: 10.1109/48.917937
23	LOU S H , TSANG L , CHAN C H , et al. Application of the finite-element method to Monte-Carlo simulations of scattering of waves by random rough surfaces with the periodic boundary-condition[J]. Electromagnet Wave, 1991, 5 (8): 835- 855. doi: 10.1163/156939391X00275
24	DU Y L . Electromagnetic scattering and emission from large rough surfaces with multiple elevations using the MLSD-SMCG method[J]. IEEE Trans.on Geoscience and Remote Sensing, 2021, 59 (7): 5393- 5406. doi: 10.1109/TGRS.2020.3016997
25	YANG J S, DU Y, SHI J C. Polarimetric simulations of bistatic scattering from perfectly conducting ocean surfaces with 3 m/s wind speed at L-band[J]. IEEE Journal of STARS, 9(3): 1176-1186.
26	GORDON W B . Far-field approximations to the Kirchoff-Helmholtz representations of scattered fields[J]. IEEE Trans.on Antennas and Propagation, 1975, 23 (4): 590- 592. doi: 10.1109/TAP.1975.1141105
27	LING H , CHOU R C , LEE S W . Shooting and bouncing rays-calculating the RCS of an arbitrarily shaped cavity[J]. IEEE Trans.on Antenn Propag, 1989, 37 (2): 194- 205. doi: 10.1109/8.18706
28	ANFINSEN S N , DOULGERIS A P , ELTOFT T . Goodness-of-fit tests for multilook polarimetric radar data based on the mellin transform[J]. IEEE Trans.on Geoscience and Remote Sensing, 2011, 49 (7): 2764- 2781. doi: 10.1109/TGRS.2010.2104158
29	JOHNSON W P . The curious history of Faa di Bruno's formula[J]. Am Math Mon, 2002, 109 (3): 217- 234.
30	NIRCHIO F , VENAFRA S . XMOD2—An improved geophysical model function to retrieve sea surface wind fields from Cosmo-Sky Med X-band data[J]. European Journal of Remote Sensing, 2013, 46 (1): 583- 595. doi: 10.5721/EuJRS20134634
31	VORONOVICH A G , ZAVOROTNY V U . Full-polarization modeling of monostatic and bistatic radar scattering from a rough sea surface[J]. IEEE Trans.on Antenn Propag, 2014, 62 (3): 1362- 1371. doi: 10.1109/TAP.2013.2295235
32	VORONOVICH A G, ZAVOROTNY V U. Depolarization of microwave backscattering from a rough sea surface: modeling with small-slope approximation[C]//Proc. of the IEEE International Geoscience and Remote Sensing Symposium, 2011: 2033-2036.
33	刘宁波, 丁昊, 黄勇, 等. X波段雷达对海探测试验与数据获取年度进展[J]. 雷达学报, 2021, 10 (1): 173- 182.
	LIU N B , DING H , HUANG Y , et al. Annual progress of the sea-detecting X-band radar and data acquisition program[J]. Journal of Radars, 2021, 10 (1): 173- 182.

纹理模型	对数累积量υ_v{τ}
γ分布	$ \left\{\begin{array}{l}v_{1}=\psi^{(0)}(\alpha)-\ln (\alpha) \\v_{v}=\psi(v-1)(\alpha), v>1\end{array}\right. $
逆γ分布	$ \left\{\begin{array}{l}v_{1}=-\psi^{(0)}(\lambda)+\ln (\lambda-1) \\v_{v}=(-1)^{v} \psi(v-1)(\lambda), v>1\end{array}\right. $
Fisher分布	$ \left\{\begin{array}{l}v_{1}=\psi(0)(\xi)-\psi(0)(\zeta)+\ln \left(\frac{\zeta-1}{\xi}\right) \\v_{v}=\psi(v-1)(\xi)+(-1)^{v} \psi(v-1)(\zeta), v>1\end{array}\right. $
β分布	$ \left\{\begin{array}{l}v_{1}=\psi(0)(\xi)-\psi(0)(\xi+\zeta)+\ln \left(\frac{\xi+\zeta}{\xi}\right) \\v_{v}=\psi(v-1)(\xi)-\psi(v-1)(\xi+\zeta), v>1\end{array}\right. $
逆β分布	$ \left\{\begin{array}{l}v_{1}=-\psi(0)(\xi)+\psi(0)(\xi+\zeta)+\ln \left(\frac{\zeta-1}{\xi+\zeta-1}\right) \\v_{v}=(-1)^{v}[\psi(v-1)(\xi)-\psi(v-1)(\xi+\zeta)], v>1\end{array}\right. $
