互耦及脉冲噪声下基于稀疏重构的鲁棒DOA估计算法

doi:10.12305/j.issn.1001-506X.2025.08.03

摘要/Abstract

摘要：

针对互耦效应和脉冲噪声并存环境下的波达方向（direction of arrival，DOA）估计问题，提出一种结合M估计与稀疏重构的算法。首先，为了消除互耦效应的影响，依据互耦矩阵的托普利兹结构进行恒等变形，得到了不含未知互耦系数的字典。随后，为了使算法能适应高斯噪声和不同强度的脉冲噪声，将位置得分函数表示为高斯位置得分函数和一系列非线性函数的线性组合，利用噪声样本估计线性组合系数从而建立损失函数。最后，采用迭代硬阈值算法进行稀疏重构，并通过改进信号更新策略提高正确收敛的概率。仿真结果表明，所提算法能有效抑制互耦效应和脉冲（高斯）噪声的干扰，同时相较已有算法在低信噪比、强脉冲特性下的性能有显著提升。

关键词: 波达方向估计, 互耦, 脉冲噪声, 稀疏重构, M估计, 迭代硬阈值

Abstract:

To deal with the problem of direction of arrival （DOA） estimation in the presence of mutual coupling and impulsive noise, an algorithm that combines M-estimate and sparse reconstruction is proposed. Firstly, a dictionary without unknown mutual coupling coefficients is obtained through identical deformation based on the Toeplitz structure of the mutual coupling matrix to eliminate the influence of mutual coupling effect. Subsequently, in order to enable the algorithm to adapt to Gaussian noise and impulsive noise of different intensities, the location score function is expressed as a linear combination of Gaussian location score function and a series of nonlinear functions, and the loss function is established with an estimate of linear combination coefficients with noise samples. Finally, the iterative hard thresholding algorithm is utilized for sparse reconstruction, and an improved strategy for signal update is employed to increase the probability of correct convergence. Simulation results show that the proposed method can effectively suppress mutual coupling effect and impulsive （Gaussian） noise, and it outperforms the existing algorithms at low signal to noise ratios and strong impulse characteristics.

Key words: direction of arrival （DOA） estimation, mutual coupling, impulsive noise, sparse reconstruction, M-estimate, iterative hard thresholding

中图分类号:

TN 911.23

何从, 刘帅, 闫锋刚, 金铭. 互耦及脉冲噪声下基于稀疏重构的鲁棒DOA估计算法[J]. 系统工程与电子技术, 2025, 47(8): 2444-2453.

Cong HE, Shuai LIU, Fenggang YAN, Ming JIN. Robust DOA estimation algorithm in the presence of mutual coupling and impulsive noise based on sparse reconstruction[J]. Systems Engineering and Electronics, 2025, 47(8): 2444-2453.

图/表 13

图1

图2

图3

图4

图5

图6

图7

图8

图9

图10

图11

图12

图13

参考文献 37

20	李欣然, 李春国, 明钰婷, 等. 脉冲噪声环境下的调制识别算法[J]. 信号处理, 2023, 45 (2): 352- 359.
	LI X R, LI C G, MING Y T, et al. Modulation recognition algorithm in impulsive noise environments[J]. Journal of Signal Processing, 2023, 45 (2): 352- 359.
21	WANG H W, WANG B, LI Y B. IAFNet: few-shot learning for modulation recognition in underwater impulsive noise[J]. IEEE Communications Letters, 2022, 26 (5): 1047- 1051. doi: 10.1109/LCOMM.2022.3151790
22	CÂMARA T V R O, LIMA A D L, LIMA B M M, et al. Automatic modulation classification architectures based on cyclostationary features in impulsive environments[J]. IEEE Access, 2019, 7, 138512- 138527. doi: 10.1109/ACCESS.2019.2943300
23	CHEN J, GUAN S. Correntropy-based DOA estimation algorithm under impulsive noise environments[J]. EURASIP Journal on Wireless Communications and Networking, 2020, 2020, 154- 167. doi: 10.1186/s13638-019-1618-7
24	TSAKALIDES P, NIKIAS C L. The robust covariation-based MUSIC （ROC-MUSIC） algorithm for bearing estimation in impulsive noise environments[J]. IEEE Trans. on Signal Processing, 1996, 44 (7): 1623- 1633. doi: 10.1109/78.510611
25	BEN-HAIM Z, ELDAR Y C. The Cramér-Rao bound for estimating a sparse parameter vector[J]. IEEE Trans. on Signal Processing, 2010, 58 (6): 3384- 3389. doi: 10.1109/TSP.2010.2045423
26	ZHANG J C, QIU T S, LUAN S Y. Robust sparse representation for DOA estimation with unknown mutual coupling under impulsive noise[J]. IEEE Communications Letters, 2020, 24 (7): 1455- 1458. doi: 10.1109/LCOMM.2020.2983038
27	OLLILA E, KIM H J, KOIVUNEN V. Robust iterative hard thresholding for compressed sensing [C]//Proc. of the 6th International Symposium on Communications, Control and Signal Processing, 2014: 226−229.
28	HUBER P J. Robust estimation of a location parameter[J]. The Annals of Mathematical Statistics, 1964, 35 (1): 73- 101.
29	HU R, FU Y L, CHEN Z, et al. Robust sparse signal recovery in the presence of the SαS noise[J]. IEEE Signal Processing Letters, 2016, 23 (11): 1687- 1691. doi: 10.1109/LSP.2016.2614983
30	SONG S S, LIN Y Y, ZHOU Y. A general M-estimation theory in semi-supervised framework[J]. Journal of the American Statistical Association, 2024, 119 (546): 1065- 1075. doi: 10.1080/01621459.2023.2169699
1	王宁, 吕晓德, 李苗苗. 低信噪比下非冗余阵列的无网格DOA估计[J]. 系统工程与电子技术, 2023, 45 (2): 352- 359.
	WANG N, LYU X D, LI M M. Gridless DOA estimation for non-redundant array at low SNR[J]. Systems Engineering and Electronics, 2023, 45 (2): 352- 359.
2	王宁, 贺鹏超, 卢景月, 等. 基于DOA估计的前视多通道SAR成像方法[J]. 系统工程与电子技术, 2023, 45 (8): 2471- 2478.
	WANG N, HE P C, LU J Y, et al. DOA estimation based imaging method for multi-channel forward-looking SAR[J]. Systems Engineering and Electronics, 2023, 45 (8): 2471- 2478.
3	XU K, XIA X C, LI C G, et al. Spatial structure matching-based DOA estimation and tracking for integrated sensing and communication massive MIMO OFDM system[J]. IEEE Trans. on Cognitive Communications and Networking, 2024, 10 (2): 526- 540. doi: 10.1109/TCCN.2023.3335378
4	SAUCAN A A, CHONAVEL T, SINTES C, et al. CPHD-DOA tracking of multiple extended sonar targets in impulsive environments[J]. IEEE Trans. on Signal Processing, 2015, 64 (5): 1147- 1160.
5	KRIM H, VIBERG M. Two decades of array signal processing research: the parametric approach[J]. IEEE Signal Processing Magazine, 1996, 13 (4): 67- 94. doi: 10.1109/79.526899
6	FRIEDLANDER B, WEISS A J. Direction finding in the presence of mutual coupling[J]. IEEE Trans. on Antennas and Propagation, 1991, 39 (3): 273- 284. doi: 10.1109/8.76322
7	DANDEKAR K, LING H, XU G. Effect of mutual coupling on direction finding in smart antenna applications[J]. Electronics Letters, 2000, 36 (22): 1889- 1891. doi: 10.1049/el:20001309
8	LIAO B, ZHANG Z G, CHAN S C. DOA estimation and tracking of ULAs with mutual coupling[J]. IEEE Trans. on Aerospace and Electronic Systems, 2012, 48 (1): 891- 905. doi: 10.1109/TAES.2012.6129676
9	TIAN Y, WANG R, CHEN H, et al. Real-valued doa estimation utilizing enhanced covariance matrix with unknown mutual coupling[J]. IEEE Communications Letters, 2022, 26 (4): 912- 916. doi: 10.1109/LCOMM.2022.3148260
10	MALIOUTOV D, CETIN M, WILLSKY A S. A sparse signal reconstruction perspective for source localization with sensor arrays[J]. IEEE Trans. on Signal Processing, 2005, 53 (8): 3010- 3022. doi: 10.1109/TSP.2005.850882
11	ZHANG X W, JIANG T, LI Y S, et al. An off-grid doa estimation method using proximal splitting and successive nonconvex sparsity approximation[J]. IEEE Access, 2019, 7, 66764- 66773. doi: 10.1109/ACCESS.2019.2917309
12	OLIVERI G, MASSA A. Bayesian compressive sampling for pattern synthesis with maximally sparse non-uniform linear arrays[J]. IEEE Trans. on Antennas and Propagation, 2011, 59 (2): 467- 481. doi: 10.1109/TAP.2010.2096400
13	YANG Z, XIE L H, ZHANG C S. Off-grid direction of arrival estimation using sparse bayesian inference[J]. IEEE Trans. on Signal Processing, 2013, 61 (1): 38- 43. doi: 10.1109/TSP.2012.2222378
14	TANG G, BHASKAR B N, SHAH P, et al. Compressed sensing off the grid[J]. IEEE Trans. on Information Theory, 2013, 59 (11): 7465- 7490. doi: 10.1109/TIT.2013.2277451
15	BHASKAR B N, TANG G, RECHT B. Atomic norm denoising with applications to line spectral estimation[J]. IEEE Trans. on Signal Processing, 2013, 61 (23): 5987- 5999. doi: 10.1109/TSP.2013.2273443
16	PAN Y, YAO M, LUO G Q, et al. Underdetermined direction-of-arrival estimation with coprime array via atomic norm minimization[J]. Radioengineering, 2020, 29 (2): 405- 413. doi: 10.13164/re.2020.0405
17	JIA T Y, LIU H W, GAO C, et al. Bayesian direction of arrival estimation using atomic norm minimization with prior knowledge [J]. IEEE Trans. on Aerospace and Electronic Systems, 2024, 60(5): 5742−5755.
18	DAI J S, ZHAO D A, JI X F. A sparse representation method for DOA estimation with unknown mutual coupling[J]. IEEE Antennas and Wireless Propagation Letters, 2012, 11, 1210- 1213. doi: 10.1109/LAWP.2012.2223651
19	WANG Q, DOU T D, CHEN H, et al. Effective block sparse representation algorithm for DOA estimation with unknown mutual coupling[J]. IEEE Communications Letters, 2017, 21 (12): 2622- 2625. doi: 10.1109/LCOMM.2017.2747547
31	YUEXIAN Z, SHING C C, TUNG S N. Least mean M-estimate algorithms for robust adaptive filtering in impulse noise[J]. IEEE Trans. on Circuits and Systems II: Analog and Digital Signal Processing, 2000, 47 (12): 1564- 1569. doi: 10.1109/82.899657
32	LV S H, ZHAO H Q, ZHOU L J. Robust proportionate normalized least mean M-estimate algorithm for block-sparse system identification[J]. IEEE Trans. on Circuits and Systems II: Express Briefs, 2022, 69 (1): 234- 238.
33	王鹏, 邱天爽, 任福全, 等. 对称稳定分布噪声下基于广义相关熵的DOA估计新方法[J]. 电子与信息学报, 2016, 38 (8): 2007- 2013.
	WANG P, QIU T S, REN F Q, et al. A novel generalized correntropy based method for direction of arrival estimation in symmetric alpha stable noise environments[J]. Journal of Electronics & Information Technology, 2016, 38 (8): 2007- 2013.
34	BRCICH R F, ZOUBIR A M. Robust estimation with parametric score function estimation [C]//Proc. of the IEEE International Conference on Acoustics, Speech, and Signal Processing, 2002: 1149−1152.
35	BLUMENSATH T, DAVIES M E. Iterative thresholding for sparse approximations[J]. Journal of Fourier Analysis and Applications, 2008, 14, 629- 654. doi: 10.1007/s00041-008-9035-z
36	李苗苗, 司伟建, 颜卫忠. 脉冲噪声环境下的二维DOA估计[J]. 空天防御, 2022, 5 (2): 94- 100. doi: 10.3969/j.issn.2096-4641.2022.02.012
	LI M M, SI W J, YAN W Z. Two-dimensional DOA estimation in impulsive noise environment[J]. Air & Space Defense, 2022, 5 (2): 94- 100. doi: 10.3969/j.issn.2096-4641.2022.02.012
37	HU R, FU Y L, CHEN Z, et al. Robust DOA estimation via sparse signal reconstruction with impulsive noise[J]. IEEE Communications Letters, 2017, 21 (6): 1333- 1336. doi: 10.1109/LCOMM.2017.2675407
