基于半参数退化模型的长寿命产品可靠性评估

doi:10.12305/j.issn.1001-506X.2023.06.34

摘要/Abstract

摘要：

退化模型是评估长寿命产品可靠性的有效方法, 但已有参数退化模型忽略了退化量分布未知、最优退化量分布和退化量有界性等问题, 导致模型可靠性评估精度不足, 适用范围有限。针对已有方法的不足, 提出一种评估长寿命产品可靠性的半参数退化模型。首先, 通过考虑边界的非参数对数变换核密度估计方法拟合产品在各检测时刻的退化量分布; 然后, 基于退化量分布与寿命分布的关系, 利用最小二乘法与遗传算法估计产品寿命分布参数; 最后, GaAs激光器与合金钢的实例应用表明, 所构建模型能够更好地拟合退化数据, 可靠性评估精度更高。

关键词: 对数变换核密度估计, 半参数退化模型, 长寿命产品, 可靠性评估

Abstract:

The degradation model is an effective method to assess the reliability of long-life products, but the existing parametric degradation model ignores the problems of unknown distribution of degradation, the optimal distribution of degradation and the boundedness of degradation, which leads to low accuracy and limited applicability of the model for reliability assessment. To address the above shortcomings of the existing methods, a semi-parametric degradation model is proposed to evaluate the reliability of long-life products. Firstly, the product degradation distributions at each testing moment are fitted by the nonparametric log-transformed kernel density estimation method considering the boundary. Secondly, based on the relationship between the degradation distribution and the lifetime distribution, the least squares method and the genetic algorithm are used to estimate the product lifetime distribution parameters. Finally, the application of GaAs laser with alloy steel shows that the constructed model can fit the degradation data better with the reliability assessment which is more accurate.

Key words: log-transformed kernel density estimation, semi-parametric degradation model, long-life product, reliability assessment

中图分类号:

TB114.3

李犟, 吴和成, 朱晨. 基于半参数退化模型的长寿命产品可靠性评估[J]. 系统工程与电子技术, 2023, 45(6): 1893-1901.

Jiang LI, Hecheng WU, Chen ZHU. Reliability assessment of long-life products based on semi-parametric degradation model[J]. Systems Engineering and Electronics, 2023, 45(6): 1893-1901.

图/表 11

图1

图2

图3

图4

表1

图5

图6

图7

表2

图8

图9

参考文献 36

1	YANGC Q,GUX H,ZHAOF C.Reliability analysis of degrading systems based on time-varying copula[J].Microelectronics Reliability,2022,136,114628. doi: 10.1016/j.microrel.2022.114628
2	MEEKERW Q,ESCOBARL A.Statistical methods for reliability data[M].New York:John Wiley & Sons,1998.
3	SABERZADEHZ,RAZMKHAHM.Reliability of degrading complex systems with two dependent components per element[J].Reliability Engineering & System Safety,2022,222,108398.
4	CHENX Y,YANGQ Y,WUX.Nonlinear degradation model and reliability analysis by integrating image covariate[J].Reliability Engineering & System Safety,2022,225(4):108602.
5	毛泽龙,王治华,吴琼,等.双指标阶段性退化建模及可靠性分析[J].系统工程与电子技术,2021,43(12):3725-3731. doi: 10.12305/j.issn.1001-506X.2021.12.37
	MAOZ L,WANGZ H,WUQ,et al.Bivariate and two-stage degradation modeling and reliability analysis[J].Systems Engineering and Electronics,2021,43(12):3725-3731. doi: 10.12305/j.issn.1001-506X.2021.12.37
6	潘尔顺,陈震.高可靠性产品退化建模研究综述[J].工业工程与管理,2015,20(6):1-6.1-6, 13 doi: 10.3969/j.issn.1007-5429.2015.06.001
	PANE S,CHENZ.Review of degradation model for high reliability products[J].Industrial Engineering and Management,2015,20(6):1-6.1-6, 13 doi: 10.3969/j.issn.1007-5429.2015.06.001
7	LUC J,MEEKERW O.Using degradation measures to estimate a time-to-failure distribution[J].Technometrics,1993,35(2):161-174. doi: 10.1080/00401706.1993.10485038
8	FREITASM A,DE-TOLEDOM L G,COLOSIMOE A,et al.Using degradation data to assess reliability: a case study on train wheel degradation[J].Quality and Reliability Engineering International,2009,25(5):607-629. doi: 10.1002/qre.995
9	BIANL,GEBRAEELN.Stochastic framework for partially degradation systems with continuous component degradation-rate-interactions[J].Naval Research Logistics,2014,61(4):286-303. doi: 10.1002/nav.21583
10	BAES J,KVAMP H.A nonlinear random-coefficients model for degradation testing[J].Technometrics,2004,46(4):460-469. doi: 10.1198/004017004000000464
11	PANR,CRISPINT.A hierarchical modeling approach to accelerated degradation testing data analysis: a case study[J].Quality and Reliability Engineering International,2011,27(2):229-237. doi: 10.1002/qre.1100
12	XUZ B,HONGY L,JINR.Nonlinear general path models for degradation data with dynamic covariates[J].Applied Stochastic Models in Business and Industry,2016,32(2):153-167. doi: 10.1002/asmb.2129
13	KANGR,GONGW J,CHENY X.Model-driven degradation modeling approaches: investigation and review[J].Chinese Journal of Aeronautics,2020,33(4):1137-1153. doi: 10.1016/j.cja.2019.12.006
14	ZHANGZ H,LIUX,ZHANGY,et al.Time interval of multiple crossings of the Wiener process and a fixed threshold in engineering[J].Mechanical Systems and Signal Processing,2020,135,106389. doi: 10.1016/j.ymssp.2019.106389
15	SUNL,ZHAOF C,BALAKRISHNANN,et al.A nonlinear Wiener degradation model integrating degradation data under accelerated stresses and real operating environment[J].Proceedings of the Institution of Mechanical Engineers, Part O: Journal of Risk and Reliability,2021,235(3):356-373. doi: 10.1177/1748006X20978099
16	TANGS J,WANGF F,SUNX Y,et al.Unbiased parameters estimation and mis-specification analysis of Wiener process-based degradation model with random effects[J].Applied Mathematical Modelling,2022,109,134-160. doi: 10.1016/j.apm.2022.03.039
17	WUB,CUIL R,YINJ.Reliability and maintenance of systems subject to Gamma degradation and shocks in dynamic environments[J].Applied Mathematical Modelling,2021,96,367-381. doi: 10.1016/j.apm.2021.03.009
18	LINC P,LINGM H,CABRERAJ,et al.Prognostics for lithium-ion batteries using a two-phase gamma degradation process model[J].Reliability Engineering & System Safety,2021,214,107797.
19	WANGX F,WANGB X,HONGY L,et al.Degradation data analysis based on gamma process with random effects[J].European Journal of Operational Research,2021,292(3):1200-1208. doi: 10.1016/j.ejor.2020.11.036
20	JIANGP H,WANGB X,WANGX F,et al.Inverse Gaussian process based reliability analysis for constant-stress accele-rated degradation data[J].Applied Mathematical Modelling,2022,105,137-148. doi: 10.1016/j.apm.2021.12.003
21	FANGG Q,PANR,WANGY K.Inverse Gaussian processes with correlated random effects for multivariate degradation modeling[J].European Journal of Operational Research,2022,300(3):1177-1193. doi: 10.1016/j.ejor.2021.10.049
22	HAOS H,YANGJ,BERENGUERC.Degradation analysis based on an extended inverse Gaussian process model with skew-normal random effects and measurement errors[J].Reliability Engineering & System Safety,2019,189,261-270.
23	YEZ S,XIEM.Stochastic modelling and analysis of degradation for highly reliable products[J].Applied Stochastic Models in Business and Industry,2015,31(1):16-32. doi: 10.1002/asmb.2063
24	LINK S,WANGY T,CHENY X.A kernel-density based semi-parametric stochastic degradation model with dependent increments[J].Mechanical Systems and Signal Processing,2021,161,107978. doi: 10.1016/j.ymssp.2021.107978
25	邓爱民,陈循,张春华,等.基于性能退化数据的可靠性评估[J].宇航学报,2006,27(3):546-552. doi: 10.3321/j.issn:1000-1328.2006.03.044
	DENGA M,CHENX,ZHANGC H,et al.Reliability assessment based on performance degradation data[J].Journal of Astronautics,2006,27(3):546-552. doi: 10.3321/j.issn:1000-1328.2006.03.044
26	王浩伟,滕克难.基于加速退化数据的可靠性评估技术综述[J].系统工程与电子技术,2017,39(12):2877-2885. doi: 10.3969/j.issn.1001-506X.2017.12.35
	WANGH W,TENGK N.Review of reliability evaluation technology based on accelerated degradation data[J].Systems Engineering and Electronics,2017,39(12):2877-2885. doi: 10.3969/j.issn.1001-506X.2017.12.35
27	钟强晖,张志华,王磊.考虑模型选择的退化数据分析方法[J].系统工程,2009,27(11):111-114.
	ZHONGQ H,ZHANGZ H,WANGL.Approach about de-gradation data analysis considering model selection[J].Systems Engineering,2009,27(11):111-114.
28	张卫贞,石慧,曾建潮,等.基于核微分同胚变换的实时剩余寿命预测[J].计算机集成制造系统,2020,26(10):2781-2791. doi: 10.13196/j.cims.2020.10.018
	ZHANGW Z,SHIH,ZENGJ C,et al.Real-time residual life prediction based on kernel differential homeomorphic transformation[J].Computer Integrated Manufacturing Systems,2020,26(10):2781-2791. doi: 10.13196/j.cims.2020.10.018
29	SILVERMANB W.Density estimation for statistics and data analysis[M].London:Chapman and Hall,1986.
30	BAIX Y,JIANGH,LIC,et al.Joint probability distribution of coastal winds and waves using a log-transformed kernel density estimation and mixed copula approach[J].Ocean Engineering,2020,216,107937. doi: 10.1016/j.oceaneng.2020.107937
31	CHARPENTIERA,FLACHAIREE.Log-transform kernel density estimation of income distribution[J].Computer Science, Economics,2015,91(1/2):141-159.
32	SHEATHERS J,JONESM C.A reliable data-based bandwidth selection method for kernel density estimation[J].Journal of the Royal Statistical Society: Series B (Methodological),1991,53(3):683-690. doi: 10.1111/j.2517-6161.1991.tb01857.x
33	JIAX.Reliability analysis for Weibull distribution with homogeneous heavily censored data based on Bayesian and least-squares methods[J].Applied Mathematical Modelling,2020,83,169-188. doi: 10.1016/j.apm.2020.02.013
34	ZHUT F.Reliability estimation for two-parameter Weibull distribution under block censoring[J].Reliability Engineering & System Safety,2020,203,107071.
35	MONTOYAJ A,DIAZ-FRANCESE,FIGUEROAG.Estimation of the reliability parameter for three-parameter Weibull models[J].Applied Mathematical Modelling,2019,67,621-633. doi: 10.1016/j.apm.2018.11.043
36	杨雷,曹希雯.非交互个体的估计值分布研究及其在群体智慧中的应用[J].系统工程理论与实践,2021,41(10):2733-2747. doi: 10.12011/SETP2020-0404
	YANGL,CAOX W.Research on the distribution of non-interactive individual's estimates with applications in the wisdom of crowds[J].Systems Engineering-Theory & Practice,2021,41(10):2733-2747. doi: 10.12011/SETP2020-0404

t/h	logKDE	KDE	AKDE	正态分布	对数正态分布	威布尔分布	Gamma分布
250	0.344	0.587	0.504	0.515	0.392	0.557	0.409
500	0.273	0.469	0.456	0.435	0.288	0.453	0.340
750	0.336	0.459	0.432	0.488	0.355	0.524	0.397
1 000	0.436	0.619	0.564	0.746	0.615	0.772	0.659
1 250	0.325	0.500	0.490	0.486	0.354	0.525	0.395
1 500	0.375	0.489	0.479	0.585	0.482	0.610	0.526
1 750	0.344	0.546	0.539	0.525	0.403	0.571	0.443
2 000	0.360	0.490	0.455	0.558	0.435	0.589	0.477
2 250	0.268	0.448	0.427	0.437	0.375	0.418	0.415
2 500	0.269	0.426	0.405	0.539	0.438	0.547	0.481
2 750	0.327	0.500	0.443	0.634	0.526	0.656	0.567
3 000	0.344	0.515	0.460	0.648	0.538	0.671	0.580
3 250	0.341	0.525	0.478	0.681	0.575	0.701	0.617
3 500	0.257	0.501	0.479	0.597	0.480	0.622	0.522
3 750	0.316	0.502	0.463	0.650	0.541	0.668	0.583
4 000	0.370	0.580	0.504	0.728	0.608	0.755	0.649

旋转/次	logKDE	KDE	AKDE	正态分布	对数正态分布	威布尔分布	Gamma分布
1×10⁴	0.958	0.958	0.957	1.194	1.194	1.174	1.218
2×10⁴	0.532	0.548	0.529	0.576	0.596	0.599	0.614
3×10⁴	0.638	0.578	0.581	0.828	0.837	0.837	0.862
4×10⁴	0.398	0.502	0.493	0.491	0.459	0.541	0.496
5×10⁴	0.307	0.559	0.550	0.382	0.406	0.396	0.422
6×10⁴	0.311	0.565	0.554	0.322	0.340	0.361	0.358
7×10⁴	0.306	0.484	0.474	0.434	0.365	0.488	0.406
8×10⁴	0.241	0.505	0.494	0.393	0.344	0.440	0.363
9×10⁴	0.222	0.532	0.521	0.311	0.330	0.346	0.347
10×10⁴	0.209	0.538	0.527	0.343	0.291	0.383	0.333
11×10⁴	0.260	0.558	0.548	0.310	0.293	0.356	0.311
12×10⁴	0.234	0.518	0.508	0.387	0.288	0.413	0.340
