基于Vondrak-Cepek组合滤波和注意力机制加权的时间比对融合算法

doi:10.12305/j.issn.1001-506X.2025.02.34

摘要/Abstract

摘要：

针对卫星双向时间频率传递(two-way satellite time and frequency transfer, TWSTFT)存在周日效应、短期稳定度不高的问题, 通过引入基于注意力机制的Transformer权值矩阵, 利用Vondrak-Cepek组合滤波的方法将中国科学院国家授时中心(National Time Service Center, NTSC)、德国物理技术研究院(Physikalisch-Technische Bundesanstalt, PTB)之间的TWSTFT和全球定位系统(Global Positioning System, GPS)P3码共视法的时间比对链路进行融合, 分析融合前后链路的性能指标并与没有周日效应、短期稳定度高的GPS精密单点定位(GPS precise point positioning, GPS PPP)时间比对参考链路进行比较。结果表明, 引入注意力机制权值的Vondrak-Cepek组合滤波融合方法与参考链路GPS PPP的标准差为0.310 9 ns, 具有改善TWSTFT周日效应、提升链路整体稳定性的作用。

关键词: Vondrak-Cepek组合滤波, 注意力机制, 时间比对, 数据融合

Abstract:

To solve the problems of the diurnal and low short-term stability in two-way satellite time and frequency transfer (TWSTFT), a Transformer weight matrix based on the attention mechanism is introduced. The Vondrak-Cepek combined filtering method is applied to fuse the TWSTFT and Global Positioning System (GPS) P3 code common view method time alignment links between the National Time Service Center (NTSC) and Physikalisch-Technische Bundesanstalt(PTB). The performance indicators of the links before and after fusion are analyzed and compared with the GPS precise point positioning (GPS PPP) time alignment reference links with no diurnal and high short-term stability. The results show that the standard deviation of Vondrak-Cepek combined filtering fusion method with the attention mechanism weight is 0.310 9 ns comparing with the reference link GPS PPP, which can reduce the diurnal of TWSTFT and enhance the overall stability of the link.

Key words: Vondrak-Cepek combined filtering, attention mechanism, time alignment, data fusion

中图分类号:

P127.1
TN713

刘强, 孙浩冉, 胡邓华, 张爽. 基于Vondrak-Cepek组合滤波和注意力机制加权的时间比对融合算法[J]. 系统工程与电子技术, 2025, 47(2): 673-679.

Qiang LIU, Haoran SUN, Denghua HU, Shuang ZHANG. Time alignment fusion algorithm based on Vondrak-Cepek combined filtering and attention mechanism weighting[J]. Systems Engineering and Electronics, 2025, 47(2): 673-679.

图/表 11

图1

图2

图3

表1

图4

图5

图6

图7

图8

表2

表3

参考文献 16
