机载多载频频控阵非均匀距离模糊杂波抑制方法

doi:10.12305/j.issn.1001-506X.2024.02.10

摘要/Abstract

摘要：

机载雷达下视工作面临严重的地海杂波, 雷达平台运动造成杂波多普勒频率严重扩散, 将微弱目标完全淹没。空时自适应处理(space time adaptive processing, STAP)技术通过联合多天线脉冲的接收信号, 能够有效地抑制杂波, 实现运动目标检测。对于非正侧视阵列高速平台雷达, 杂波距离依赖和距离模糊严重制约着目标检测性能。基于多载频频控阵, 通过发射一组载频不同的正交信号, 在杂波回波中, 获得新的发射维自由度, 并根据不同模糊在发射维的差异分离各模糊区域。此外, 通过进一步对分离后的近程进行杂波补偿, 利用降维STAP实现杂波抑制。仿真结果验证了所提方法的有效性。

关键词: 空时自适应处理, 距离模糊, 多载频频控阵, 非均匀杂波

Abstract:

The looking-down mode of the airborne radar faces serious low-sea clutter, and the Doppler frequency of clutter spreads seriously due to the movement of radar platform, which will completely submerge the weak target. Space-time adaptive processing (STAP) technology can effectively suppress clutter and realize moving target detection by combining the received signals of multi-antenna pulses. For non-side-looking array high-speed platform radar, clutter range dependence and range ambiguity seriously restrict the performance of target detection. In this paper, based on the multi-carrier frequency control array, by transmitting a group of orthogonal signals with different carrier frequencies, a new degree of freedom of the transmit dimension is obtained in the clutter echo, and the range-ambiguous regions are separated according to the difference of distinct ambiguities in the transmit dimension. In addition, by further compensating the short-range clutter after separation, a reduced-dimensional STAP is used to mitigate the clutter. Simulation results verify the effectiveness of the proposed method.

Key words: space-time adaptive processing (STAP), range ambiguity, multi-carrier frequency control array, inhomogeneous clutter

中图分类号:

TN958.5

刘成, 王华柯, 全英汇, 廖桂生. 机载多载频频控阵非均匀距离模糊杂波抑制方法[J]. 系统工程与电子技术, 2024, 46(2): 459-469.

Cheng LIU, Huake WANG, Yinghui QUAN, Guisheng LIAO. Non-uniform distance ambiguity clutter suppression method for airborne multi-carrier frequency control array[J]. Systems Engineering and Electronics, 2024, 46(2): 459-469.
