基于子阵级处理的宽带非规则子阵相控阵鲁棒性干扰抑制

doi:10.12305/j.issn.1001-506X.2024.02.01

摘要/Abstract

摘要：

针对宽带非规则子阵相控阵在复杂干扰环境下性能变差的情况, 提出一种基于子阵级处理的鲁棒性干扰抑制方法。首先, 建立存在误差情况下的宽带阵列子阵级回波模型; 通过子阵级数字Stretch处理将宽带线性调频回波信号变为窄带信号, 降低处理的有效带宽; 然后, 进一步改进基于谱分离的干扰加噪声协方差矩阵重构方法, 利用测量的先验信息划分子区间, 减小重构区域, 降低运算量; 最后, 利用获得的最优权值加权各通道数据获得阵列输出。所提方法有效利用非规则子阵优势, 避免了规则子阵阵面方向图中存在栅瓣的情况, 能够在存在多种组合干扰和误差的情况下抑制干扰, 具有较强的鲁棒性。

关键词: 宽带, 子阵级处理, 鲁棒性, 干扰抑制

Abstract:

A robust interference suppression method based on subarray level processing is proposed for the poor performance of wideband irregular subarray phased arrays in complex interference environments. Firstly, the subarray level echo model of wideband array with errors is established. The wideband linear frequency modulation echo signal can be transformed into narrowband signal through the subarray digital Stretch processing and the effective bandwidth of processing can be reduced. Then, the method of interference and noise covariance matrix reconstruction based on spectral separation is further improved, and the measured prior information is used to divide the molecular interval to decrease the reconstruction area and reduce the amount of computation. Finally, the optimal weight is used to weight each channel data to obtain the array output. The proposed method makes good use of the advantages of irregular subarrays and avoids the presence of gate lobes in the pattern of regular subarrays. It can also suppress interference in the case of multiple combination interference and error, and has strong robustness.

Key words: wideband, subarray level processing, robustness, interference suppression

中图分类号:

TN958

陈吉源, 徐振海, 肖顺平. 基于子阵级处理的宽带非规则子阵相控阵鲁棒性干扰抑制[J]. 系统工程与电子技术, 2024, 46(2): 367-380.

Jiyuan CHEN, Zhenhai XU, Shunping XIAO. Robust interference suppression of wideband irregular subarrayed phased array based on subarray level processing[J]. Systems Engineering and Electronics, 2024, 46(2): 367-380.

图/表 21

图1

图2

图3

表1

表2

图4

图5

表3

图6

图7

图8

图9

图10

图11

图12

图13

图14

图15

图16

图17

图18

参考文献 31

1	张光义. 相控阵雷达原理[M]. 北京: 国防工业出版社, 2009.
	ZHANG G Y . Principles of phased array radar[M]. Beijing: National Defense Industry Press, 2009.
2	张光义, 赵玉洁. 相控阵雷达技术[M]. 北京: 电子工业出版社, 2006.
	ZHANG G Y , ZHAO Y J . Phased array radar technology[M]. Beijing: Publishing House of Electronics Industry, 2006.
3	吴曼青. 数字阵列雷达及其发展[J]. 中国电子科学研究院学报, 2006, 1 (1): 11- 16. doi: 10.3969/j.issn.1673-5692.2006.01.005
	WU M Q . Digital array radar and its development[J]. Journal of China Academy of Electronics Science, 2006, 1 (1): 11- 16. doi: 10.3969/j.issn.1673-5692.2006.01.005
4	徐振海, 熊子源, 董玮, 肖顺平. 阵列雷达最优子阵技术[M]. 北京: 科学出版社, 2021.
	XU Z H, XIONG Z Y, DONG W, et al. Optimal subarray technology of array radar[M]. Beijing: Science Press, 2021.
5	HERD J S, CONWAY M D. The evolution to modern phased array architectures[C]//Proc. of the IEEE, 2016, 104(3): 519-529.
6	MAILLOUX R J , SANTARELLI S G , ROBERTS T M , et al. Irregular polyomino-shaped subarrays for space-based active arrays[J]. International Journal of Antennas and Propagation, 2009, 2009, 956524.
7	熊子源. 阵列雷达最优子阵划分与处理研究[D]. 长沙: 国防科技大学, 2015.
	XIONG Z Y. Optimal subarray division and processing of array radar[D]. Changsha: National University of Defense Technology, 2015.
8	董玮. 阵列雷达非规则子阵设计与波束综合技术研究[D]. 长沙: 国防科技大学, 2020.
	DONG W. Irregular subarray design and beam synthesis technology of array radar[D]. Changsha: National University of Defense Technology, 2020.
9	ROCCA P , ANSELMI N , POLO A , et al. An irregular two-sizes square tiling method for the design of isophoric phased arrays[J]. IEEE Trans. on Antennas and Propagation, 2020, 68 (6): 4437- 4449. doi: 10.1109/TAP.2020.2970088
10	CHEN J Y , XU Z H , XIAO S . Irregular subarray design stra-tegy based on weighted L1 norm iterative convex optimization[J]. IEEE Antennas and Wireless Propagation Letters, 2022, 21 (2): 376- 380. doi: 10.1109/LAWP.2021.3132001
11	DU L , LIU H M , BAO Z . Radar HRRP statistical recognition: parametric model and model selection[J]. IEEE Trans. on Signal Processing, 2008, 56 (5): 1931- 1944. doi: 10.1109/TSP.2007.912283
12	NABUKI M , OKUMURA S , SATO T , et al. Ultrawideband radar imaging using adaptive array and Doppler separation[J]. IEEE Trans. on Aerospace and Electronic Systems, 2017, 53 (1): 190- 200. doi: 10.1109/TAES.2017.2649798
13	陈新竹. 多功能数字阵列雷达空域抗有源干扰方法研究[D]. 上海: 上海交通大学, 2020.
	CHEN X Z. Anti-active jamming method for multifunctional digital array radar in airspace[D]. Shanghai: Shanghai Jiao Tong University, 2020.
14	FENG D J , XU L T , PAN X Y , et al. Jamming wideband radar using interrupted-sampling repeater[J]. IEEE Trans. on Aerospace Electronic Systems, 2017, 53 (3): 1341- 1354. doi: 10.1109/TAES.2017.2670958
15	RAO B , GU Z , NIE Y . Deception approach to track-to-track radar fusion using noncoherent dual-source jamming[J]. IEEE Access, 2020, 8, 50843- 50858. doi: 10.1109/ACCESS.2020.2980010
16	FANTE R L . Cancellation of specular and diffuse jammer multipath using a hybrid adapative array[J]. IEEE Trans. on Aerospace Electronic Systems, 1991, 27 (5): 823- 837. doi: 10.1109/7.97327
17	ZHAO Y , LIU W , LANGLEY R J . Adaptive wideband beamforming with frequency invariance constraints[J]. IEEE Trans. on Antennas and Propagation, 2011, 59 (4): 1175- 2011. doi: 10.1109/TAP.2011.2110630
18	CHENG C H , LIOU L L , TSUI J B , et al. Chirp signal detection using FFT peak frequency difference[J]. IEEE Trans. on Aerospace Electronic Systems, 2016, 52 (3): 1449- 1453. doi: 10.1109/TAES.2016.140201
19	TORRES J A , DAVIS R , KRAMER J D R , et al. Effcient wideband jammer nulling when using stretch processing[J]. IEEE Trans. on Aerospace and Electronic Systems, 2000, 36 (4): 1167- 1178. doi: 10.1109/7.892666
20	LI H Y , ZHANG X H , HE Z S , et al. A wideband digital beamforming method based on stretch processing[J]. WSEAS Transactions on Signal Processing, 2009, 5 (7): 251- 260.
21	MOHAMED J. Performance analysis on wideband-interference cancellation base on detailed hardware design[C]//Proc. of the IEEE Aerospace Conference, 2013.
22	李卫星. 宽带数字阵列雷达误差校正及波束形成关键技术研究[D]. 长沙: 国防科技大学, 2016
	LI W X. Key technologies of wideband digital array radar error correction and beamforming[D]. Changsha: National University of Defense Technology, 2016.
23	CARLSON B D . Covariance matrix estimation errors and diagonal loading in adaptive arrays[J]. IEEE Trans. on Aerospace Electronic Systems, 1988, 24 (4): 397- 401. doi: 10.1109/7.7181
24	FELDMAN D D . An analysis of the projection method for robust adaptive beamforming[J]. IEEE Trans. on Antennas Propagation, 1996, 44 (7): 1023- 1030. doi: 10.1109/8.504311
25	VOROBYOV S A , GERSHMAN A B , LUO Z Q . Robust adaptive beamforming using worst-case performance optimization: a solution to the signal mismatch problem[J]. IEEE Trans. on Signal Processing, 2003, 51 (2): 313- 324. doi: 10.1109/TSP.2002.806865
26	GU Y J , AMIR L . Robust adaptive beamforming based on interference covariance matrix reconstruction and steering vector estimation[J]. IEEE Trans. on Signal Processing, 2012, 60 (7): 3881- 3885. doi: 10.1109/TSP.2012.2194289
27	SHEN F , CHEN F F , SONG J Y . Robust adaptive beamforming based on steering vector estimation and covariance matrix reconstruction[J]. IEEE Communication Letter, 2015, 19 (9): 1636- 1639. doi: 10.1109/LCOMM.2015.2455503
28	HUANG L , ZHANG J , XU X , et al. Robust adaptive beamforming with a novel interference-plus-noise covariance matrix reconstruction method[J]. IEEE Trans. on Signal Processing, 2015, 63 (7): 1643- 1650.
29	ZHENG Z , ZHENG Y , WANG W Q , et al. Covariance matrix reconstruction with interference steering vector and power estimation for robust adaptive beamforming[J]. IEEE Trans. on Vehical Technology, 2018, 67 (9): 8495- 8503. doi: 10.1109/TVT.2018.2849646
30	XIE Z , FAN C Y , ZHU J , et al. Robust beamforming for wideband array based on spectrum subspaces[J]. IET Radar, Sonar and Navigation, 2020, 14 (9): 1319- 1327. doi: 10.1049/iet-rsn.2019.0598
31	DONG W , XU Z H , LI X X , et al. Low cost subarrayed sensor array design strategy for IoT and future 6G applications[J]. IEEE Internet of Things Journal, 2020, 7 (6): 4816- 4826. doi: 10.1109/JIOT.2020.2969247

参数	取值	参数	取值
阵列规模	64×64	信号脉宽/μs	50
子阵大小	8单元	参考距离/km	50
LFM信号中心频率/GHz	10	目标相对参考位置的距离/m	10
信号带宽/GHz	1	SNR/dB	-5
距离窗/m	120	目标方位/(°)	(10, 10)

干扰	INR/dB	相对距离/m	来波方位/(°)
窄带干扰	40	-20	(-10, 10)
宽带噪声干扰	20	-10	(10, -5)

干扰	INR/dB	相对距离/m	来波方位/(°)
窄带干扰	40	-20	(-10, 10)
宽带干扰	20	-10	(10, -5)
