联合多种资源协同干扰组网雷达系统的自适应调度方法

doi:10.12305/j.issn.1001-506X.2023.09.12

摘要/Abstract

摘要：

针对飞机编队协同干扰组网雷达系统的资源分配问题, 提出了一种联合目标选择与功率分配的自适应调度(adaptive scheduling method of joint target selection and power allocation, JTAPM)方法, 其核心是通过实时调度干扰机的波束和功率资源, 使得飞机编队对组网雷达系统的协同干扰效能始终保持最优。首先, 根据雷达网不同的工作状态和信息融合规则, 构建基于检测概率和瞄准概率的双因子干扰效能评估函数, 然后考虑干扰资源约束建立关于目标选择和功率分配的双变量非凸优化模型, 并基于此提出了一种结合改进布谷鸟搜索(improved cuckoo search, ICS)算法与KKT(Karush-Kuhn-Tucker, KKT)优化条件的求解方法。最后, 仿真结果证明了所提联合资源自适应调度策略的有效性。

关键词: 改进布谷鸟搜索算法, KKT条件, 雷达对抗, 资源分配, 组网雷达系统

Abstract:

To address the jamming resource allocation problem of the aircraft formation cooperatively jamming netted radar system, an adaptive scheduling method of joint target selection and power allocation (JTAPM) is proposed. The core of this method is to schedule the beam and power resources of jammers in real time to maintain the best jamming effectiveness against netted radar system. Firstly, considering the information fusion rules and different working modes of the netted radar system, a two-factor jamming effectiveness evaluation function based on detection probability and aiming probability is constructed. Then a bivariate nonconvex optimization model with respect to target selection and power allocation is established. Finally, a three-step solution method combining improved cuckoo search (ICS) algorithm and Karush-Kuhn-Tucker (KKT) optimization condition is proposed. Simulation results are provided to demonstrate the advantages of the proposed adaptive scheduling method and the effectiveness of the improved algorithm.

Key words: improved cuckoo search (ICS) algorithm, Karush-Kuhn-Tucker (KKT) condition, radar countermeasure, resource allocation, netted radar system

中图分类号:

TN974

陆德江, 王星, 陈游, 胡星. 联合多种资源协同干扰组网雷达系统的自适应调度方法[J]. 系统工程与电子技术, 2023, 45(9): 2744-2754.

Dejiang LU, Xing WANG, You CHEN, Xing HU. Adaptive scheduling method of joint multi-resource for cooperative interference of networked radar system[J]. Systems Engineering and Electronics, 2023, 45(9): 2744-2754.

图/表 19

图1

图2

图3

图4

表1

表2

表3

表4

表5

图5

图6

图7

图8

图9

图10

图11

图12

图13

图14

参考文献 31
