基于极化单脉冲雷达扩展目标角度估计方法

doi:10.12305/j.issn.1001-506X.2021.06.06

系统工程与电子技术 ›› 2021, Vol. 43 ›› Issue (6): 1497-1505.doi: 10.12305/j.issn.1001-506X.2021.06.06

基于极化单脉冲雷达扩展目标角度估计方法

刘业民, 李永祯*, 黄大通, 庞晨

国防科技大学电子科学学院, 湖南长沙 410073

收稿日期:2020-10-16 出版日期:2021-05-21 发布日期:2021-05-28
通讯作者: 李永祯
作者简介:刘业民(1982—), 男, 工程师, 博士, 主要研究方向为电子对抗与反对抗、雷达信号处理|李永祯(1976—), 男, 高级工程师, 博士研究生导师, 博士，主要研究方向为极化雷达信号处理以及雷达电子对抗|黄大通(1993—), 男, 博士研究生, 主要研究方向为合成孔径雷达信号处理与对抗|庞晨(1986—), 男, 副研究员, 博士，主要研究方向为相控阵雷达极化信息精确获取、极化抗干扰、极化特征提取与识别
基金资助:
国家自然科学基金(61971429);国家自然科学基金(61490692)

Angle estimation method of extended target based on polarization monopulse radar

Yemin LIU, Yongzhen LI*, Datong HUANG, Chen PANG

College of Electronic Science and Technology, National University of Defense Technology, Changsha 410073, China

Received:2020-10-16 Online:2021-05-21 Published:2021-05-28
Contact: Yongzhen LI

摘要/Abstract

摘要：

当单脉冲雷达受到箔条质心干扰时, 将视为波束内存在两个不可分辨的目标, 由于目标和箔条干扰回波混叠耦合, 导致单脉冲测角偏差, 最终致使目标跟踪丢失。对此, 利用宽带单脉冲雷达测角精度高的优点和极化信息, 提出一种基于极化单脉冲雷达的扩展目标角度估计方法。首先，分析宽带单脉冲雷达体制下箔条质心干扰的特点, 给出扩展目标双极化和差信号模型。然后, 根据和、差通道极化回波信号, 通过联立方程组, 估计出目标和箔条干扰的到达角(angle of arrival, AOA), 为后续利用目标角度信息跟踪目标提供条件。最后，通过蒙特卡罗仿真实验分析关键参数对目标角度估计性能的影响, 并与传统单脉冲雷达体制的测角方法进行比较。理论分析和仿真实验表明, 在质心干扰条件下, 宽带单脉冲雷达估计目标AOA的性能要优于传统单脉冲雷达。

关键词: 宽带单脉冲雷达, 极化, 到达角, 质心干扰

Abstract:

When the chaff centroid jamming in monopulse radar is presented, it will be considered that two indistinguishable targets are in the beam. Due to the aliasing and coupling between the target and the jamming echo, the angle measurement deviation will be caused, and finally target tracking will be lost. In view of this situation, this paper takes advantage of the high accuracy of wideband monopulse radar angle measurement and uses the polarization information to propose a method for estimating the angle of extended targets based on polarization monopulse radar. Firstly, the characteristics of chaff centroid jamming in wideband monopulse radar system are analyzed, and the dual polarization sum and difference signal model of the extended targets is given. And then, the angle of arrival (AOA) of target and chaff jamming is estimated according to the polarization echo signal of sum and difference channel through simultaneous equations, which provides conditions for tracking the target with the angle information of the target. Finally, the influence of some key parameters on the performance of target angle estimation is analyzed by the Monte Carlo simulation experiment, and compared with the traditional monopulse radar angle measurement method. Theoretical analysis and simulation results show that the performance of AOA estimation for wideband monopulse radar is better than that of traditional monopulse radar under chaff centroid jamming.

Key words: broadband monopulse radar, polarization, angle of arrival (AOA), centroid jamming

中图分类号:

TN95

刘业民, 李永祯, 黄大通, 庞晨. 基于极化单脉冲雷达扩展目标角度估计方法[J]. 系统工程与电子技术, 2021, 43(6): 1497-1505.

Yemin LIU, Yongzhen LI, Datong HUANG, Chen PANG. Angle estimation method of extended target based on polarization monopulse radar[J]. Systems Engineering and Electronics, 2021, 43(6): 1497-1505.

图/表 8

图1

图2

表1

图3

图4

图5

图6

图7

参考文献 23

1	孙胜, 王钦伟, 曹洁, 等. 反舰导弹研究现状与发展趋势综述[J]. 航天控制, 2017, (3): 80- 85.
	SUN S , WANG Q W , CAO J , et al. A survey on research status and development trend for anti-ship missile[J]. Aeospace Control, 2017, (3): 80- 85.
2	张军周, 杨格. 对抗新型反舰导弹箔条质心干扰作战方法研究[J]. 舰船电子工程, 2019, 39 (2): 80- 84. doi: 10.3969/j.issn.1672-9730.2019.02.020
	ZHANG J Z , YANG G . Research on combat method of chaff centroid jamming against new anti-ship missiles[J]. Ship Electronic Engineering, 2019, 39 (2): 80- 84. doi: 10.3969/j.issn.1672-9730.2019.02.020
3	刁桂杰, 许小剑, 倪虹, 等. 舰船目标宽带单脉冲雷达三维成像建模与仿真[J]. 系统仿真学报, 2018, 30 (7): 2515- 2524.
	DIAO G J , XU X J , NI H , et al. Three-dimensional imaging modeling and simulation of ships based on wide-band monopulse radar[J]. Journal of System Simulation, 2018, 30 (7): 2515- 2524.
4	GLASS J D , BLAIR W D . Detection of rayleigh targets using adjacent matched filter samples[J]. IEEE Trans.on Aerospace and Electronic Systems, 2015, 63 (24): 1927- 1941.
5	GLASS J D , BLAIR W D , LANTERMAN A D . Joint-bin monopulse processing of rayleigh targets[J]. IEEE Trans.on Signal Processing, 2015, 51 (3): 6673- 6683.
6	NICKEL U , CHAUMETTE E , LARZABAL P . Statistical perfor-mance prediction of generalized monopulse estimation[J]. IEEE Trans.on Aerospace and Electronic Systems, 2011, 47 (1): 381- 404. doi: 10.1109/TAES.2011.5705682
7	LI C W , WANG H Q , LI X , et al. Study on the detection of the multiple unresolved targets[J]. Systems Engineering and Electronics, 2005, 16 (2): 295- 300.
8	CHAUMETTE E , NICKEL U , LARZABAL P . Detection and parameter estimation of extended targets using the generalized monopulse estimator[J]. IEEE Trans.on Aerospace and Electronic Systems, 2011, 47 (1): 381- 404. doi: 10.1109/TAES.2011.5705682
9	GALY J , CHAUMETTE E , LARZABAL P . Joint detection estimation problem of monopulse angle measurement[J]. IEEE Trans.on Aerospace and Electronic Systems, 2010, 46 (1): 397- 412. doi: 10.1109/TAES.2010.5417170
10	MONAKOV A A . Maximum-likelihood estimation of parameters of an extended target in tracking monopulse radars[J]. IEEE Trans.on Aerospace and Electronic Systems, 2012, 48 (3): 2683- 2665.
11	NICKEL U , CHAUMETTE E , LARZABAL P . Estimation of extended targets using the generalized monopulse estimator: extension to a mixed target model[J]. IEEE Trans.on Aerospace and Electronic Systems, 2013, 49 (3): 2084- 2096. doi: 10.1109/TAES.2013.6558043
12	BLAIR W D, BRANDT-PEARCE M. Detection of multiple unresolved Rayleigh targets using quadrature monopulse mea-surements[C]//Proc. of the Symposium on System Theory, 1996: 34-45.
13	GLASS J D, BLAIR W D. Detection of unresolved Rayleigh targets using adjacent bins[C]//Proc. of the IEEE Aerospace Conference, 2016.
14	TSAI T Y , LIAO Z Q , DING Z Q , et al. Detection of unresolved targets for wideband monopulse radar[J]. Sensors, 2019, 19 (5): 1084- 1099. doi: 10.3390/s19051084
15	ZHANG X , WILLETT P , BAR-SHALOM Y . Detection and localization of multiple unresolved extended objects via monopulse radar signal processing[J]. Proceedings of SPIE, the International Society for Optical Engineering, 2005, 5913 (2): 455- 472.
16	WILLETT P K , BAR-SHALOM Y , ZHANG X . The multitarget monopulse CRLB for matched filter samples[J]. IEEE Trans.on Signal Processing, 55, 55 (8): 4183- 4197.
17	ISAAC A , WILLETT P K , BAR-SHALOM Y . MCMC methods for tracking two closely spaced targets using monopulse radar channel signals[J]. IET Radar, Sonar and Navigation, 2007, 1 (3): 71- 80.
18	刘业民, 邢世其, 李永祯, 等. 基于极化单脉冲雷达的角度估计方法[J]. 系统工程与电子技术, 2018, 40 (8): 1713- 1719.
	LIU Y M , XING S Q , LI Y Z , et al. A method for estimate the angle based on polarization monopulse radar[J]. Systems Engineering and Electronics, 2018, 40 (8): 1713- 1719.
19	ZHANG Y X , LIU Q F , HONG R J , et al. A novel monopulse angle estimation method for wideband LFM radars[J]. Sensors, 2016, 16 (6): 817- 823. doi: 10.3390/s16060817
20	刘业民. 箔条云极化雷达特性及抗干扰技术研究[D]. 长沙: 国防科技大学, 2019.
	LIU Y M. Study on polarization radar characteristics of chaff clouds and anti-jamming techniques[D]. Changsha: National University of Defense Technology, 2019.
21	YANG Y , FENG D J , ZHANG W M , et al. Detection of chaff centroid jamming aided by GPS/INS[J]. IET Radar Sonar & Navigation, 2013, 7 (2): 130- 142.
22	BLAIR W D , BRANDT-PEARCE M . Monopulse DOA estimation of two unresolved Rayleigh targets[J]. IEEE Trans.on Aerospace and Electronic Systems, 2001, 37 (2): 452- 469. doi: 10.1109/7.937461
23	LIU Y M , XIGN S Q , LIU Y C , et al. Maximum likelihood angle estimation of target in the presence of chaff centroid jamming[J]. IEEE Access, 2018, 6, 74416- 74428. doi: 10.1109/ACCESS.2018.2882579

参数	符号	取值
平台速度/(m/s)	v_a	400
信号载频/GHz	f_c	35
信号带宽/MHz	B	150
信号脉宽/μs	T_p	20
最近斜距/km	R₀	10
极化方式	(a, a_⊥)	±45°线极化
