基于深度强化学习算法的无人机智能规避决策

doi:10.12305/j.issn.1001-506X.2023.06.14

Abstract

Abstract:

In order to improve the survival rate of unmanned aerial vehicles (UAVs) in complex air combat scenarios, based on the open UAVs air intelligence game simulation platform, a reinforcement learning method is used to generate maneuver strategies. Based on the deep double Q network (DDQN) and deep deterministic policy gradient (DDPG) algorithms, an unit state sequence (USS) is proposed in this paper, and the gated recurrent unit (GRU) is used to fuse the situation features in USS, with the propose to increase the ability of state features recognition and algorithm convergence in complex air combat scenarios. The experimental results show that when faced with missile attacks using standard proportional guidance algorithm, the agent achieves a survival rate of 98% for missiles evading, and in complex scenarios where multiple missiles attack simultaneously, it can also achieve a survival rate of 88%. Compared with the traditional simple maneuvering modes, the survival rate of UAVs is significantly improved.

Key words: deep reinforcement learning (DRL), unmanned aerial vehicles (UAVs), unit state sequence (USS), gated recurrent unit (GRU)

CLC Number:

Fengguo WU, Wei TAO, Hui LI, Jianwei ZHANG, Chengchen ZHENG. UAV intelligent avoidance decisions based on deep reinforcement learning algorithm[J]. Systems Engineering and Electronics, 2023, 45(6): 1702-1711.
