具有低误码平台系统LT码的设计与优化

doi:10.12305/j.issn.1001-506X.2026.10.38

摘要/Abstract

摘要：

卢比变换（Luby transform，LT）码是第一种实用的无速率码，其传输码率值可以根据信道状态自适应地进行调整。然而，LT码固有的误码平台现象限制其在实际传输场景中的应用。为了解决此问题，设计了一种系统无速率编码方案，以提高LT码在较宽范围信噪比（signal-to-noise ratio，SNR）内的误比特率（bit error rate，BER）性能。该方案通过优化编码结构与节点传输模式，实现高SNR区域快速收敛译码、低SNR区域无差错译码。此外，基于外信息传递图法分析了该编码方案在两种传输情况时的收敛性，在所需SNR范围内预设了若干期望值，并以此为核心约束条件优化了校验度分布设计模型；之后，设计了最优参数搜索算法，为度分布设计模型中关键参数的选取提供了经验依据。仿真结果表明，该方案的BER性能优于现有的改进方案，且节省的编码开销可达码长的10%。

关键词: 信道编码, 无速率码, 度分布, 误码平台

Abstract:

Luby transform （LT） codes are the first practical rateless codes whose transmission code rate can be adjusted adaptively according to the channel state. However, the inherent error floor phenomenon of LT code limits its application in practical transmission scenarios. To solve this problem, a systematic rateless coding scheme is designed to improve the bit error rate （BER） performance of LT codes in a wide range of signal-to-noise ratio （SNR）. By optimizing the coding structure and transmission mode of nodes, this scheme realizes fast convergence decoding in high SNR region and error-free decoding in low SNR region. In addition, the convergence of the encoding scheme in two transmission cases is analyzed based on the extrinsic information transfer chart method. Some expected values are preset within the desired SNR range, and the check degree distribution design model is optimized based on these core constraints. Then, the optimal parameter search algorithm is designed, which provides an empirical basis for selecting the key parameters in the degree distribution design model. Simulation results show that the BER performance of the proposed scheme outperforms the existing improved coding schemes, and the coding overhead can be saved up to 10% of the code length.

Key words: channel coding, rateless code, degree distribution, error floor

中图分类号:

TN 911.22

孙伟柏, 倪淑燕, 宋鑫, 雷拓峰. 具有低误码平台系统LT码的设计与优化[J]. 系统工程与电子技术, 2026, 48(10): 3683-3692.

Weibai Sun, Shuyan Ni, Xin Song, Tuofeng Lei. Design and optimization of LT codes with low error floor system[J]. Systems Engineering and Electronics, 2026, 48(10): 3683-3692.

图/表 14

图1

表1

图2

图3

图4

表2

图5

图6

图7

图8

图9

图10

表3

图11

参考文献 37

1	Byers J W, Luby M, Mitzenmacher M. A digital fountain approach to asynchronous reliable multicast[J]. IEEE Journal on Selected Areas in Communications, 2002, 20 (8): 1528.
2	Huang J X, Fei Z S, Cao C Z, et al. Reliable broadcast based on online fountain codes[J]. IEEE Communications Letters, 2021, 25 (2): 369.
3	He H, Su J, Chen Y R, et al. Reliable cross-technology communication with physical-layer acknowledgement[J]. IEEE Trans. on Communications, 2020, 68 (8): 5175.
4	Cai P X, Zhang Y, Wu Y C, et al. Feedback strategies for online fountain codes with limited feedback[J]. IEEE Communications Letters, 2020, 24 (9): 1870.
5	Wen J L, Shirvanimoghaddam M, Abbas R, et al. Analysis and design of analog fountain codes for short packet communications in IoT[J]. IEEE Trans. on Vehicular Technology, 2021, 70 (12): 12662.
6	Hu Y M, Liu R K, Kaushik A, et al. Performance analysis of NOMA multicast systems based on rateless codes with delay constraints[J]. IEEE Trans. on Wireless Communications, 2021, 20 (8): 5003.
7	Zhang K, Jiao J, Huang Z X, et al. Finite block-length analog fountain codes for ultra-reliable low latency communications[J]. IEEE Trans. on Communications, 2020, 68 (3): 1391.
8	Jain S, Bose R. Rateless-code-based secure cooperative transmission scheme for industrial IoT[J]. IEEE Internet of Things Journal, 2020, 7 (7): 6550.
9	Luo S X, Ma T, Shan W, et al. Efficient multisource data delivery in edge cloud with rateless parallel push[J]. IEEE Internet of Things Journal, 2020, 7 (10): 10495.
10	Schulz P, Trabl A, Barreto A N, et al. Efficient and reliable wireless communications via multi-connectivity using rateless codes in single- and multi-user scenarios[J]. IEEE Trans. on Wireless Communications, 2021, 20 (9): 5714.
11	Luby M. LT codes[C]// 43rd Annual IEEE Symposium on Foundations of Computer Science, 2002: 271.
12	Shokrollahi A. Raptor codes[J]. IEEE Trans. on Information Theory, 2006, 52 (6): 2551.
13	Zhang Y F, Hou W, Li Y, et al. Robust rateless spatially coupled repeat-accumulate-repeat multi-user codes on IDMA systems[J]. IEEE Trans. on Vehicular Technology, 2021, 70 (11): 11523.
14	Li A M, Wu S H, Jiao J, et al. Spinal codes over fading channel: error probability analysis and encoding structure improvement[J]. IEEE Trans. on Wireless Communications, 2021, 20 (12): 8288.
15	Xu X, Wu S H, Dong D, et al. High performance short polar codes: a concatenation scheme using spinal codes as the outer code[J]. IEEE Access, 2018, 6, 70644.
16	Hussain I, Xiao M, Rasmussen L K. Error floor analysis of LT codes over the additive white Gaussian noise channel[C]// IEEE Global Telecommunications Conference, 2011.
17	Hussain I, Xiao M, Rasmussen L K. Design of LT codes with equal and unequal erasure protection over binary erasure channels[J]. IEEE Communications Letters, 2013, 17 (2): 261.
18	Song X, Ni S Y, Zhang Z, et al. 面向不等差错保护的低误码平台LT编码算法[J]. 通信学报, 2022, 43 (6): 85.
19	Chang L J, Wang C H, Zao J K. An error-floor reduction technique for short-length LT codes[C]// International Symposium on Information Theory and its Applications, 2014: 279.
20	Nguyen T D, Yang L L, Hanzo L, et al. Systematic Luby transform codes and their soft decoding[C]// IEEE Workshop on Signal Processing Systems, 2007: 67.
21	Yuan X, Ping L. On systematic LT codes[J]. IEEE Communications Letters, 2008, 12 (9): 681.
22	Xu S K, Xu D Z. Optimization design and asymptotic analysis of systematic Luby transform codes over BIAWGN channels[J]. IEEE Trans. on Communications, 2016, 64 (8): 3160.
23	Dai J K, Chen X, Zhang F G, et al. Optimisation design of systematic fountain codes on fading channels[J]. IET Communications, 2019, 13 (20): 3369.
24	Dai J K, Zhang F G, Yang W K, et al. An efficient design of systematic rateless codes[J]. Wireless Communications and Mobile Computing, 2020, 2020, 8068414.
25	Kharel A, Cao L. On the performance of LT codes over BIAWGN channel[C]// International Conference on Computer, Information and Telecommunication Systems, 2016.
26	Zhang M X, Kim S. Efficient encoding scheme for LT codes with soft iterative decoding[J]. IET Communications, 2018, 12 (13): 1624.
27	Kharel A, Cao L. Improved fountain codes for BI-AWGN channels[C]// IEEE Wireless Communications and Networking Conference, 2017.
28	Brink S T. Convergence behavior of iteratively decoded parallel concatenated codes[J]. IEEE Trans. on Communications, 2001, 49 (10): 1727.
29	Etesami O, Shokrollahi A. Raptor codes on binary memoryless symmetric channels[J]. IEEE Trans. on Information Theory, 2006, 52 (5): 2033.
30	Kuo S H, Guan Y L, Lee S K, et al. A design of physical-layer raptor codes for wide SNR ranges[J]. IEEE Communications Letters, 2014, 18 (3): 491.
31	Shirvanimoghaddam M, Johnson S. Raptor codes in the low SNR regime[J]. IEEE Trans. on Communications, 2016, 64 (11): 4449.
32	Jayasooriya S, Shirvanimoghaddam M, Johnson S J. A design of reconfigurable raptor codes for wide SNR ranges using a multiple-edge framework[J]. IEEE Communications Letters, 2018, 22 (8): 1532.
33	Fadhel H, Kharel A, Cao L. Performance of raptor codes on the BIAWGN channel in the presence of SNR mismatch[C]// IEEE Wireless Communications and Networking Conference, 2020.
34	Lazaro F, Liva G, Bauch G. Inactivation decoding of LT and raptor codes: analysis and code design[J]. IEEE Trans. on Communications, 2017, 65 (10): 4114.
35	Song X, Cheng N P, Ni S Y, et al. An improved LT encoding algorithm based on reselecting check nodes[C]// 13th International Conference on Communication Software and Networks, 2021: 75.
36	Brink S T, Kramer G, Ashikhmin A. Design of low-density parity-check codes for modulation and detection[J]. IEEE Trans. on Communications, 2004, 52 (4): 670.
37	Wang C H, Li Y H, Chang L J. Performance analysis of improved LT codes with the removal of low degree input symbols[J]. IEEE Trans. on Vehicular Technology, 2020, 69 (2): 2296.

SNR/dB	${\sigma _n}$	${C_{{\sigma _n}}}$
−2.82	0.9783	0.5000
−1.53	0.8433	0.6005
−0.27	0.7294	0.7004
1,07	0.6252	0.7994
2.73	0.5164	0.9000

${\alpha _1}$	${\alpha _2}$	${\alpha _{{\text{sum}}}}$	${\alpha _1}$	${\alpha _2}$	${\alpha _{{\text{sum}}}}$
10.5	12.1	77.6411	10.8	12.1	79.1411
	12.2	77.8489		12.2	79.3489
	12.3	78.0567		12.3	79.5567
	12.4	78.2644		12.4	79.7644
10.6	12.1	78.1411	10.9	12.1	79.6411
	12.2	78.3489		12.2	79.8489
	12.3	78.5567		12.3	80.0567
	12.4	78.7644		12.4	80.2644
10.7	12.1	78.6411	11.0	12.1	80.1411
	12.2	78.8489		12.2	80.3489
	12.3	79.0567		12.3	80.5567
	12.4	79.2644		12.4	80.7644

$ {\alpha }_{1} $	$ \beta $	校验节点度分布
10.9	36.3333	$ \begin{array}{l} {\varOmega }_{1}\left(x\right)=0.134\;3{x}^{13}+0.806\;0{x}^{14}+0.003\;6{x}^{110}+\\ 0.003\;2{x}^{111}+0.053{x}^{300}\end{array} $
10.9	11.4444	$ \begin{array}{l}{\varOmega}_{2}\left(x\right)=0.062{x}^{4}+0.897\;9{x}^{5}+0.025{x}^{87}+\\ 0.015\;1{x}^{300}\end{array} $
8.9	29.6667	$ \begin{array}{l}{\varOmega }_{1}\left(x\right)=0.617\;4{x}^{14}+0.302\;5{x}^{15}+0.004\;2{x}^{89}+\\ \text{ }0.075\;9{x}^{300}\end{array} $
8.9	11.4444	$ \begin{array}{l}{\varOmega }_{2}\left(x\right)=0.006\;3{x}^{4}+0.953\;1{x}^{5}+0.008{x}^{87}+\\ \text{ }0.017\;9{x}^{88}+0.014\;6{x}^{300}\end{array} $
