QR分解-凸集投影协同超分辨率重建

doi:10.12305/j.issn.1001-506X.2026.05.03

摘要/Abstract

摘要：

针对线阵推扫成像中因目标-平台相对运动导致的亚像素位移与过采样信息冗余问题，提出一种融合物理先验与数值优化的超分辨率重建方法。首先，基于目标运动速度与平台参数推导过采样比例及最优超分辨率倍数。其次，通过构造正则化增广矩阵的正则化QR分解实现病态方程组的稳定求解，抑制噪声放大与伪影生成。最后，结合凸集投影方法嵌入成像系统的时空耦合约束，实现细节增强与物理一致性重建。仿真实验表明，该方法在红外遥感影像中可将局部结构相似性指数提升至0.8402，光谱复原的相对均方根误差降低80.17%，优于传统广义逆与迭代插值算法，41个光谱通道的处理总耗时低于150 ms，验证了其在高光谱数据处理的工程实用价值。

关键词: 线推扫过采样, 超分辨率重建, 正则化QR分解, 凸集投影法

Abstract:

A super-resolution reconstruction method integrating physical priors and numerical optimization is proposed to address the sub-pixel displacement and oversampling information redundancy caused by target-platform relative motion in push-broom imaging. Firstly, the oversampling ratio and optimal super-resolution factor are derived based on target motion velocity and platform parameters. Secondly, stable solutions for ill-posed equations are achieved through regularized QR decomposition of regularized augmented matrices, suppressing noise amplification and artifact generation. Finally, spatiotemporal coupling constraints of imaging systems are embedded via the projection onto convex sets method, realizing detail enhancement and physically consistent reconstruction. Simulation experiments demonstrate that this method improves the local structural similarity index to 0.8402 in infrared remote sensing imagery, while reducing the relative root mean square error of spectral restoration by 80.17%, outperforming conventional generalized inverse and iterative interpolation algorithms. The total processing time for 41 spectral channels is better than 150 ms, demonstrating its engineering practical value in hyperspectral data processing.

Key words: linear push-broom oversampling, super-resolution reconstruction, regularized QR decomposition, projection onto convex sets （POCS） method

中图分类号:

TP 391.41

赵俊博, 毛宏霞, 赵慧洁, 张佑堃, 刘畅. QR分解-凸集投影协同超分辨率重建[J]. 系统工程与电子技术, 2026, 48(5): 1474-1480.

Junbo ZHAO, Hongxia MAO, Huijie ZHAO, Youkun ZHANG, Chang LIU. Synergistic super-resolution reconstruction via QR decomposition and POCS[J]. Systems Engineering and Electronics, 2026, 48(5): 1474-1480.

图/表 14

图1

图2

图3

表1

图4

图5

表2

表3

图6

图7

表4

图8

图9

表5

参考文献 29

1	JHA A K, FLEMING S, DESHLER N, et al. Multi-aperture telescopes at the quantum limit of superresolution imaging : detecting subRayleigh object near a star[J]. Acta Astronautica, 2025, 226 (1): 531- 541. doi: 10.1016/j.actaastro.2024.09.064
2	SEGUELA D, FRATTER C, MUNIER P. SPOT5 system[C]//Proc. of the SPIE’s International Symposium on Optical Science, Engineering, and Instrumentation, 1999: 212−220.
3	AOKI T, OHKA S, SHIOZAWA D, et al. Spatial and time-series 4D infrared gas cloud imaging reconstructed from infrared images measured in multiple optical paths[C]//Proc. of the 17th International Workshop on Advanced Infrared Technology and Applications, 2023.
4	ZHOU Q W, YANG C, LIN P C, et al. Far-field phase-shifting structured light illumination enabled by polarization multiplexing metasurface for super-resolution imaging[J]. Nano Letters, 2024, 24 (35): 11036- 11042. doi: 10.1021/acs.nanolett.4c03142
5	CUI B Q, ZHANG S H, WANG Y C, et al. Pose correction scheme for camera-scanning fourier ptychography based on camera calibration and homography transform[J]. Optics Express, 2022, 30 (12): 20697- 20711. doi: 10.1364/OE.459908
6	JIN J, DONG L L, JIANG Y H, et al. Image super resolution based on gradient constrained POCS method[J]. Journal of Physics:Conference Series, 2019, 1237 (3): 032033. doi: 10.1088/1742-6596/1237/3/032033
7	WANG X T, YU K, WU S X, et al. ESRGAN: enhanced super-resolution generative adversarial networks[C]//Proc. of the European Conference on Computer Vision, 2018: 63−79.
8	GOYAL B, DOGRA A, AGRAWAL S, et al. Image denoising review: from classical to state-of-the-art approaches[J]. Information Fusion, 2020, 55: 220−244.
9	BOPPUDI V, NANMARAN R. Design and development of contrast-limited adaptive histogram equalization technique for enhancing MRI images by improving PSNR, UIQI parameters in comparison with median filtering[J]. ECS Transactions, 2022, 107(1): 14819−14827.
10	XIE H, LUO X, XU X, et al. Automated subpixel surface water mapping from heterogeneous urban environments using Landsat 8 OLI imagery[J]. Remote Sensing, 2016, 8 (7): 584. doi: 10.3390/rs8070584
11	李亚鹏, 何斌. 采用CCD错位成像技术提高图像质量[J]. 光学学报, 2015, 35 (2): 116- 123.
	LI Y P, HE B. Improving image quality by using CCD subpixel imaging[J]. Acta Optica Sinica, 2015, 35 (2): 116- 123.
12	PANG B Y, LIU Y N. PRO-SSRGAN: stable super-resolution generative adversarial network based on parameter reconstructive optimization on Gaofen-5 remote-sensing images[J]. International Journal of Remote Sensing, 2024, 45 (9): 3022- 3053. doi: 10.1080/01431161.2024.2339205
13	BHARTI M, JAIN S, JINDAL H. Framework for image denoising employing different thresholding techniques[J]. International Journal of Sensors, Wireless Communications and Control, 2024, 14 (3): 185- 203. doi: 10.2174/0122103279288431240315044900
14	YAO G D, HUANG Z G, ZHOU H W, et al. Single satellite positioning method and error characteristic analysis of LEO navigation satellites[C]//Proc. of the China Satellite Navigation Conference Proc. Singapore: Springer Nature, 2024: 28−39.
15	HAN J L, YANG X B, YUE W, et al. Image motion of remote sensing camera with wide field of view over the antarctic and arctic[J]. IEEE Journal of Selected Topics in Applied Earth Observations and Remote Sensing, 2021, 14, 3475- 3484. doi: 10.1109/JSTARS.2021.3066626
16	HOU X, BAI Y P, LI Y, et al. High-resolution triplet network with dynamic multiscale feature for change detection on satellite images[J]. ISPRS Journal of Photogrammetry and Remote Sensing, 2021, 177, 103- 115. doi: 10.1016/j.isprsjprs.2021.05.001
17	刘其涛. 反演解析法提高CCD空间分辨率方法的修正及完善[J]. 电光与控制, 2006, 13 (3): 33- 35. doi: 10.3969/j.issn.1671-637X.2006.03.008
	LIU Q T. Modification of inversion analysis method for improving CCD imaging resolution[J]. Electronics Optics & Control, 2006, 13 (3): 33- 35. doi: 10.3969/j.issn.1671-637X.2006.03.008
18	XING J, YAN P Y, LI W C, et al. Generalized inverse matrix-long short-term memory neural network data processing algorithm for multi-wavelength pyrometry[J]. Optics Express, 2022, 30 (26): 46081- 46093. doi: 10.1364/OE.475680
19	CUI Q, PARK J C, IYER R R, et al. Development of a fast calibration method for image mapping spectrometry[J]. Applied Optics, 2020, 59 (20): 6062- 6069. doi: 10.1364/AO.395988
20	HU Z Q, CHEN Z Z, ZHAO C, et al. Deterministic sea wave reconstruction and prediction based on coherent s-band radar using condition number regularized least squares[J]. Remote Sensing, 2024, 16 (22): 4147. doi: 10.3390/rs16224147
21	MOSLEMI A, AHMADIAN A. Subspace learning for feature selection via rank revealing QR factorization: fast feature selection[J]. Expert Systems with Applications, 2024, 256, 124919. doi: 10.1016/j.eswa.2024.124919
22	CAO L Q, HE J N, GAO L Z, et al. LWIR hyperspectral image classification based on a temperature-emissivity residual network and conditional random field model[J]. International Journal of Remote Sensing, 2022, 43 (10): 3744- 3768. doi: 10.1080/01431161.2022.2105667
23	CHENG X J, LIAO M X, ZHANG S Y, et al. Optimization of grassland carrying capacity with grass quality indicators through GF5B hyperspectral images[J]. Remote Sensing, 2024, 16 (24): 4807. doi: 10.3390/rs16244807
24	AYDIN M K, GUO Q, ALEXANDER E. Hypercolorization: propagating spatially sparse noisy spectral clues for reconstructing hyperspectral images[J]. Optics Express, 2024, 32 (7): 10761- 10776. doi: 10.1364/OE.508017
25	JENEFA A, KURIAKOSE M B, NAVEEN E, et al. EDSR: empowering super-resolution algorithms with high-quality DIV2K images[J]. Intelligent Decision Technologies, 2023, 17 (4): 1249- 1263. doi: 10.3233/IDT-230218
26	SHAO L T, ZHANG H G, ZHANG G H. The improved hybrid MAP-POCS based algorithm for super-resolution image restoration research[J]. Applied Mechanics and Materials, 2014, 701-702, 373- 380.
27	FANG H L, ZHENG L L, XU W. Super-resolution reconstruction of remote sensing images using chaotic mapping to optimize sparse representation[J]. Sensors, 2024, 24 (21): 7030- 7052. doi: 10.3390/s24217030
28	ZHU J, LI P, ZEATHER J. Method for reconstructing seismic data using a projection onto a convex set and a complicated curvelet transform[J]. Arabian Journal of Geosciences, 2022, 15 (19): 1539- 1548. doi: 10.1007/s12517-022-10810-2
29	TSENG H W, VEDANTHAM S, KARELLAS A. Cone-beam breast computed tomography using ultra-fast image reconstruction with constrained, total-variation minimization for suppression of artifacts[J]. Physica Medica, 2020, 73, 117- 124. doi: 10.1016/j.ejmp.2020.04.020

方法	RRMSE/%	SSIM
插值采样方法	36.09	0.7250
广义逆矩阵方法	21.67	0.7566
完全QR分解方法	14.71	0.8076

方法	RRMSE/%	SSIM
插值采样方法	21.38	0.7924
广义逆矩阵方法	12.64	0.8240
完全QR分解方法	4.24	0.8402

目标过采样率	仿真图像分辨率/m	仿真图像尺寸/像素	重建图像分辨率/m	重建图像尺寸/像素
3	4	43×66	2.4	72×37
2	4	43×53	2.6	65×40
1.5	4	43×44	3.0	58×39

方法	RRMSE/%	SSIM
插值采样方法	32.40	0.7221
广义逆矩阵方法	20.66	0.7349
完全QR分解方法	7.05	0.8064

算法	RRMSE/%	SSIM
插值采样方法	38.14	0.6780
广义逆矩阵方法	30.79	0.6989
完全QR分解方法	10.43	0.7728
