考虑执行器故障的无人帆船事件触发控制

doi:10.12305/j.issn.1001-506X.2022.01.30

系统工程与电子技术 ›› 2022, Vol. 44 ›› Issue (1): 242-249.doi: 10.12305/j.issn.1001-506X.2022.01.30

考虑执行器故障的无人帆船事件触发控制

李纪强¹, 张国庆^1,*, 黄晨峰¹, 张卫东²

1. 大连海事大学航海学院, 辽宁大连 116026
2. 上海交通大学自动化系, 上海 200240

收稿日期:2021-01-11 出版日期:2022-01-01 发布日期:2022-01-19
通讯作者: 张国庆
作者简介:李纪强(1993—), 男, 博士研究生, 主要研究方向为帆船控制、自适应神经控制、事件触发控制|张国庆(1987—), 男, 副教授, 博士, 主要研究方向为神经网络控制、事件触发控制及在海洋工程领域的应用|黄晨峰(1992—), 男, 博士研究生, 主要研究方向为船舶运动控制、鲁棒自适应控制、复杂系统建模及仿真|张卫东(1967—), 男, 教授, 博士, 主要研究方向为过程控制、鲁棒控制及在海洋航行器中的应用
基金资助:
国家自然科学基金(51909018);国家自然科学基金(52171291);辽宁省百千万人才计划(2021BQWB64);大连市科技创新基金(2019J12GX026);大连市重点研究领域创新团队支持计划(2020RT08);中央高校基本科研业务费专项资金(3132021132);中央高校基本科研业务费专项资金(3132021340)

Event-triggered control for unmanned sailboat with actuator failures

Jiqiang LI¹, Guoqing ZHANG^1,*, Chenfeng HUANG¹, Weidong ZHANG²

1. Navigation College, Dalian Maritime University, Dalian 116026, China
2. Department of Automation, Shanghai Jiao Tong University, Shanghai 200240, China

Received:2021-01-11 Online:2022-01-01 Published:2022-01-19
Contact: Guoqing ZHANG

摘要/Abstract

摘要：

针对实际海洋环境下, 无人帆船在艏向跟踪控制任务中存在的模型参数未知、控制输入频繁抖振和执行器磨损等问题, 提出一种考虑执行器故障的无人帆船事件触发控制算法。首先, 采用径向基函数神经网络(radius based function neural networks, RBF-NNs)对系统的未知模型参数进行在线逼近。其次, 在无人帆船艏向数学模型中引入执行器故障模型, 并且在艏向控制器设计中考虑帆结构造成的转船力矩, 设计基于事件触发机制的艏向控制律来减少控制输入的频繁抖振和执行器磨损。最后, 通过李雅普诺夫稳定性判据证明了所提控制算法满足半全局一致有界(semi-global uniform ultimate bounded, SGUUB)稳定。数值仿真结果表明, 相比于传统的艏向控制算法, 所提算法能够在保证艏向控制性能的基础上, 极大地降低控制输入的频繁抖振和减少执行器的磨损。

关键词: 无人帆船, 径向基函数神经网络, 执行器故障, 事件触发控制

Abstract:

Aiming at the heading control problem for the unmanned sailboat with the unknown model parameters, the chattering frequently of control input and the actuator wear under the practical marine environment, an event-triggered control algorithm with the actuator failures is proposed. Firstly, the radius based function neural networks (RBF-NNs) is introduced to approximated online the unknown model parameters of the system. Secondly, the actuator failure model is introduced into the heading mathematical model of unmanned sailboat, and the turning torque caused by sail structure is considered in the design of heading controller. A heading control law based on event triggering mechanism is designed to reduce the frequent chattering of control input and actuator wear. Finally, through the Lyapunov stability criterion, it is proved that the proposed control algorithm satisfies semi-global uniform ultimate bounded (SGUUB) stability. Numerical simulation results show that compared with the traditional heading control algorithm, the proposed algorithm can greatly reduce the frequent chattering of control input and the wear of actuator on the basis of ensuring the heading control performance.

Key words: unmanned sailboat, radius based function neural networks (RBF-NNs), actuator failures, event-triggered control

中图分类号:

U664

李纪强, 张国庆, 黄晨峰, 张卫东. 考虑执行器故障的无人帆船事件触发控制[J]. 系统工程与电子技术, 2022, 44(1): 242-249.

Jiqiang LI, Guoqing ZHANG, Chenfeng HUANG, Weidong ZHANG. Event-triggered control for unmanned sailboat with actuator failures[J]. Systems Engineering and Electronics, 2022, 44(1): 242-249.

图/表 11

图1

图2

图3

图4

图5

表1

表2

图6

图7

图8

图9

参考文献 30

1	CARTER W E , CARTE M S . The age of sail: a time when the fortunes of nations and lives of seamen literally turned with the winds their ships encountered at sea[J]. Journal of Navigation, 2019, 63 (7): 717- 731.
2	ARREDONDO A , VIOLA I M . The leading-edge vortex of yacht sails[J]. Ocean Engineering, 2018, 159 (2): 552- 562.
3	TAGLIAFERRI F , VIOLA I M . A real-time strategy decision program for sailing yacht races[J]. Ocean Engineering, 2017, 134 (4): 129- 139.
4	ABRIL J , SALOM J , CALVO O . Fuzzy control of a sailboat[J]. International Journal of Approximate Reasoning, 1997, 16 (4): 359- 375.
5	WILLE K L, HASSANI V, SPRENGER F. Modeling and course control of sailboats[C]//Proc. of the 10th IFAC Conference on Control Applications in Marine Systems, 2016: 532-539.
6	ZHOU L, CHEN K, CHEN Z, et al. Course control of unmanned sailboat based on BAS-PID algorithm[C]//Proc. of the International Conference on System Science and Engineering, 2020.
7	XIAO L , JOUFFROY J . Modeling and nonlinear heading control of sailing yachts[J]. IEEE Journal of Oceanic Engineering, 2014, 39 (2): 256- 268. doi: 10.1109/JOE.2013.2247276
8	ZHENG Z W , FEROSKHAN M . Path following of a surface vessel with prescribed performance in the presence of input saturation and external disturbances[J]. IEEE Trans.on Mechatronics, 2017, 22 (6): 2564- 2575. doi: 10.1109/TMECH.2017.2756110
9	LI Y M , QU F , TONG S C . Observer-based fuzzy adaptive finite-time containment control of nonlinear multi-agent systems with input delay[J]. IEEE Trans.on Cybernetics, 2021, 56 (1): 126- 137.
10	贺宏伟, 邹早建, 曾智华. 欠驱动水面船舶的自适应神经网络-滑模路径跟随控制[J]. 上海交通大学学报, 2020, 54 (9): 890- 897.
	HE H W , ZOU Z J , ZENG Z H . Adaptive NN-SM control for path following of underactuated surface vessels[J]. Journal of Shanghai Jiao Tong University, 2020, 54 (9): 890- 897.
11	HE W , YIN Z , SUN C Y . Adaptive neural network control of a marine vessel with constraints using the asymmetric barrier Lyapunov function[J]. IEEE Trans.on Cybernetics, 2017, 47 (7): 1641- 1651. doi: 10.1109/TCYB.2016.2554621
12	ZHANG G Q , LI J Q , LI B , et al. Improved integral LOS guidance and path-following control for an unmanned robot sailboat via the robust neural damping technique[J]. The Journal of Navigation, 2019, 72 (6): 1378- 1398. doi: 10.1017/S0373463319000353
13	PLUMET F , PETRES C , ROMERO M , et al. Toward an autonomous sailing boat[J]. IEEE Journal of Oceanic Engineering, 2015, 40 (2): 397- 407. doi: 10.1109/JOE.2014.2321714
14	张国庆, 李纪强, 王文新, 等. 基于速度调节的无人帆船机器人自适应艏向保持控制[J]. 控制理论与应用, 2020, 37 (11): 2383- 2390. doi: 10.7641/CTA.2020.90700
	ZHANG G Q , LI J Q , WANG W X , et al. Adaptive course- keeping control for unmanned sailboat robot with the speed regu- lating mechanism[J]. Control Theory & Applications, 2020, 37 (11): 2383- 2390. doi: 10.7641/CTA.2020.90700
15	DENG Y , ZHANG X K , ZHANG G Q . Line-of-sight-based guidance and adaptive neural path-following control for sailboats[J]. IEEE Journal of Oceanic Engineering, 2020, 45 (4): 1177- 1189. doi: 10.1109/JOE.2019.2923502
16	WANG W , WEN C Y , HUANG J S , et al. Adaptive consensus of uncertain nonlinear systems with event triggered communication and intermittent actuator faults[J]. Automatica, 2019, 111, 108667.
17	HUANG J S , WANG W , WEN C Y , et al. Adaptive event-triggered control of nonlinear systems with controller and parameter estimator triggering[J]. IEEE Trans.on Automatic Control, 2020, 65 (1): 318- 324. doi: 10.1109/TAC.2019.2912517
18	ZHANG C H , YANG G H . Event-triggered adaptive output feedback control for a class of uncertain nonlinear systems with actuator failures[J]. IEEE Trans.on Cybernetics, 2018, 50 (1): 201- 210.
19	XING L T , WEN C Y , LIU Z T , et al. Adaptive compensation for actuator failures with event-triggered input[J]. Automatica, 2017, 85, 129- 136. doi: 10.1016/j.automatica.2017.07.061
20	ZHANG G Q , LI J Q , YU W , et al. Event-triggered robust neural control for unmanned sail-assisted vehicles subject to actuator failures[J]. Ocean Engineering, 2020, 216 (11): 107754.
21	DO K D . Practical control of underactuated ships[J]. Ocean Engineering, 2010, 37 (9): 1111- 1119.
22	XIANG X B , YU C , LAPIERRE L , et al. Survey on fuzzy-logic-based guidance and control of marine surface vehicles and underwater vehicles[J]. International Journal of Fuzzy Systems, 2018, 20 (20): 572- 586.
23	SUN Z J , ZHANG G Q , QIAO L , et al. Robust adaptive tra-jectory tracking control of underactuated surface vessel in fields of marine practice[J]. Journal of Marine Science and Technology, 2018, 23 (4): 950- 957. doi: 10.1007/s00773-017-0524-0
24	沈智鹏, 王茹. 基于DSC和MLP的欠驱动船舶自适应滑模轨迹跟踪控制[J]. 系统工程与电子技术, 2018, 40 (3): 643- 651.
	SHEN Z P , WANG R . Adaptive sliding mode trajectory tracking control of underactuated ship based on DSC and MLP[J]. Systems Engineering and Electronics, 2018, 40 (3): 643- 651.
25	YI X L , LIU K , DIMAROGONAS D V , et al. Dynamic event-triggered and self-triggered control for multi-agent systems[J]. IEEE Trans.on Automatic Control, 2019, 64 (8): 3300- 3307. doi: 10.1109/TAC.2018.2874703
26	YUAN Z Y , XIONG Y Y , SUN G H , et al. Event-triggered quantized communication-based consensus in multi-agent systems via sliding mode[J]. IEEE Trans.on Cybernetics, 2020, doi: 10.1109/TCYB.2020.3017550
27	MCCUE L . Handbook of marine craft hydrodynamics and motion control[J]. IEEE Control Systems, 2016, 36 (1): 78- 79. doi: 10.1109/MCS.2015.2495095
28	张国庆. 超恶劣海况下船舶运动简捷鲁棒自适应控制[D]. 大连: 大连海事大学, 2015.
	ZHANG G Q. Concise robust adaptive control for ships under phenomenal sea states[D]. Dalian: Dalian Maritime University, 2015.
29	HUANG C F , ZHANG X K , ZHANG G Q . Improved decentralized finite-time formation control of under-actuated USVs via a novel disturbance observer[J]. Oceanic Engineering, 2019, 174 (2): 117- 124.
30	ZHANG G Q , YAO M Q , XU J H , et al. Robust neural event-triggered control for dynamic positioning ships with actuator faults[J]. Oceanic Engineering, 2020, 207 (1): 107292.

指标	对象	本文算法	文献[7]算法	文献[12]算法
MATE	Ψ_e/(°)	1.064	1.538	3.936
MACI	δ_R/(°)	10.673	11.028	1.483
MCIV	δ_R/(°)	0.725	2.583	2.016

指标	本文算法	文献[7]算法	文献[12]算法
CM/kB	211 793	406 285	392 618
UP/%	14	31	30
TN	582	20 000	20 000
