小型化宽带侦察干扰一体化系统的设计与验证

doi:10.12305/j.issn.1001-506X.2025.01.03

摘要/Abstract

摘要：

针对侦察干扰一体化系统面向无人平台小型化载荷应用的场景, 提出一种基于射频片上系统(radio frequency system on chip, RFSoC)的宽带侦察干扰一体化、小型化系统的设计与实现方法。重点攻克并行实时大带宽侦察干扰技术以及小型化、大带宽侦察干扰一体化软硬件系统构建, 并改善和差波束比相测角算法在宽带测角时的测角精度以及间歇采样转发干扰算法的欺骗干扰效果。最后, 基于该软硬件系统完成侦察干扰算法实现, 验证系统具有优越的侦察定位精度与干扰性能。

关键词: 射频片上系统, 侦察干扰一体, 小型化, 大带宽

Abstract:

In response to the miniaturized payload application scenario of reconnaissance and jamming integrated system for unmanned platforms, a design and implementation method for a miniaturized, wideband reconnaissance and jamming integrated system based on radio frequency system on chip (RFSoC) is proposed. The paper focuses on overcoming challenges in parallel real-time large bandwidth reconnaissance and jamming techniques, as well as the construction of miniaturized, large bandwidth reconnaissance and jamming integrated software and hardware systems. In addition, improvements are made to the accuracy of angle measurement using the angle-of-arrival algorithm based on the sum-difference beamforming ratio for broadband direction finding, as well as the effectiveness of intermittent sampling relay jamming algorithm for deceptive jamming. Finally, the reconnaissance and jamming algorithms are implemented based on the software and hardware system, verifying its superior reconnaissance positioning accuracy and jamming performance.

Key words: radio frequency system on chip (RFSoC), integrate reconnaissance and jamming, miniaturiza-tion, large bandwidth

中图分类号:

TN957.52

肖凯, 肖国尧, 孙宗正, 王铎鹏, 全英汇. 小型化宽带侦察干扰一体化系统的设计与验证[J]. 系统工程与电子技术, 2025, 47(1): 22-33.

Kai XIAO, Guoyao XIAO, Zongzheng SUN, Duopeng WANG, Yinghui QUAN. Design and verification of miniaturized broadband reconnaissance and jamming integrated system[J]. Systems Engineering and Electronics, 2025, 47(1): 22-33.
