卫星导航时域自适应抗干扰技术综述

doi:10.12305/j.issn.1001-506X.2023.04.25

系统工程与电子技术 ›› 2023, Vol. 45 ›› Issue (4): 1164-1176.doi: 10.12305/j.issn.1001-506X.2023.04.25

• 制导、导航与控制 • 上一篇

卫星导航时域自适应抗干扰技术综述

宋捷¹, 鲁祖坤¹^,*, 刘哲¹, 肖志斌¹, 党超², 王芝应³, 孙广富¹

1. 国防科技大学电子科学学院, 湖南长沙 410073
2. 西安空间无线电技术研究所, 陕西西安 710000
3. 北京卫星导航中心, 北京 100085

收稿日期:2022-01-20 出版日期:2023-03-29 发布日期:2023-03-28
通讯作者: 鲁祖坤
作者简介:宋捷(1998—), 女, 硕士研究生, 主要研究方向为星基导航与定位技术、卫星导航抗干扰技术
鲁祖坤(1989—), 男, 讲师, 博士, 主要研究方向为星基导航与定位技术、卫星导航抗干扰技术
刘哲(1987—), 男, 讲师, 博士, 主要研究方向为星基导航与定位技术
肖志斌(1986—), 男, 讲师, 博士, 主要研究方向为星基导航与定位技术
党超(1988—), 男, 工程师, 硕士, 主要研究方向为导航信号接收与抗干扰技术
王芝应(1987—), 男, 工程师, 硕士, 主要研究方向为卫星导航应用技术
孙广富(1970—), 男, 研究员, 博士研究生导师, 博士, 主要研究方向为卫星导航信号处理技术

Review on the time-domain interference suppression of navigation receiver

Jie SONG¹, Zukun LU¹^,*, Zhe LIU¹, Zhibin XIAO¹, Chao DANG², Zhiying WANG³, Guangfu SUN¹

1. College of Electronic Science and Technology, National University of Defense Technology, Changsha 410073, China
2. Xi'an Institute of Space Radio Technology, Xi'an 710000, China
3. Beijing Satellite Navigation Center, Beijing 100085, China

Received:2022-01-20 Online:2023-03-29 Published:2023-03-28
Contact: Zukun LU

摘要/Abstract

摘要：

时域自适应抗干扰是导航对抗领域最常规的抗干扰技术之一, 可以通过自适应算法生成时域滤波器, 在不需要先验信息的前提下应对复杂多变的窄带干扰。随着干扰环境复杂化、干扰手段扩大化, 给传统时域抗干扰带来了高抗干扰性能不足、复杂度过高、测距稳健性不足的难题, 时域抗干扰技术也在导航对抗升级的同时不断改进和发展。介绍了时域抗干扰的基本概念以及经典算法, 对近年来时域抗干扰研究面临的主要问题进行了归纳总结, 并分别从提高算法收敛性、降低硬件复杂度以及提高测距精度3个方面给出了技术发展概述。最后, 根据对已有技术的总结和面临的工程问题, 对未来时域抗干扰技术的发展方向做出了展望。

关键词: 卫星导航接收机, 时域抗干扰, 算法收敛性, 硬件复杂度, 测距精度

Abstract:

Time-domain adaptive anti-jamming is the most conventional anti-jamming technology in the field of navigation countermeasures. Time-domain anti-jamming technology can suppress changeable narrow-band interference without prior information through adaptive algorithm. With the complexity of the interference environment and the expansion of interference methods, traditional time-domain anti-jamming has brought high anti-jamming performance, insufficient performance, and high complexity. The problem of insufficient ranging robustness, time-domain anti-jamming technology is constantly improving and developing while navigation countermeasures are being upgraded. The basic concepts and classic algorithms of time-domain anti-jamming are introduced, and the main problems faced by time-domain anti-jamming research in recent years are summarized. It also focuses on improving algorithm convergence, reducing hardware complexity, and improving ranging accuracy. The aspect gives an overview of technological development. Finally, based on the summary of the existing technology and the engineering problems faced, a prospect for the future development direction of anti-jamming technology in the time domain is made.

Key words: satellite navigation receivers, time-domain anti-jamming, algorithm convergence, hardware complexity, ranging accuracy

中图分类号:

TN967.1

宋捷, 鲁祖坤, 刘哲, 肖志斌, 党超, 王芝应, 孙广富. 卫星导航时域自适应抗干扰技术综述[J]. 系统工程与电子技术, 2023, 45(4): 1164-1176.

Jie SONG, Zukun LU, Zhe LIU, Zhibin XIAO, Chao DANG, Zhiying WANG, Guangfu SUN. Review on the time-domain interference suppression of navigation receiver[J]. Systems Engineering and Electronics, 2023, 45(4): 1164-1176.

图/表 11

图1

表1

图2

图3

图4

表2

图5

图6

表3

图7

图8

参考文献 92

1	LYU Q S , QIN H L . A general method to mitigate the continuous wave interference and narrowband interference for GNSS receivers[J]. IET Radar, Sonar & Navigation, 2020, 14 (9): 1430- 1435.
2	HUANG L , LU Z K , XIAO Z , et al. Suppression of jammer multipath in GNSS antenna array receiver[J]. Remote Sensing, 2022, 14 (2): 350. doi: 10.3390/rs14020350
3	YASYUKEVICH Y V , YASYUKEVICH A S , ASTAFYEVA E I . How modernized and strengthened GPS signals enhance the system performance during solar radio bursts[J]. GPS Solutions, 2021, 25, 46. doi: 10.1007/s10291-021-01091-5
4	HWANG S S. Adaptive algorithms for a GPS interference suppression receiver and a sparse reconfigurable adaptive filter[D]. Santa Barbara: University of California, 2006.
5	FANTE R L , VACCARO J J . Wideband cancellation of interference in a GPS receive array[J]. IEEE Trans.on Aerospace & Electronic Systems, 2000, 36 (2): 549- 564.
6	MA W W , GAO J X , YUAN Y N , et al. Suppression of continuous wave interference in loran-C signal based on sparse optimization using tunable Q-factor wavelet transform and discrete cosine transform[J]. Sensors, 2021, 21 (21): 7153. doi: 10.3390/s21217153
7	ISSAM S M, ADNANE A, MADIABDESSALAM A. Anti-jamming techniques for aviation GNSS-based navigation systems: survey[C]//Proc. of the IEEE 2nd International Conference on Electronics, Control, Optimization and Computer Science, 2020.
8	HAO Z H , ZHAO H Z , SHAO S H , et al. Suppression of time-varying multi-tone interference based on frequency domain interference detection[J]. Wireless Personal Communications, 2014, 75 (2): 1051- 1060. doi: 10.1007/s11277-013-1407-2
9	WANG J D, PENG J W, XU X M, et al. A single-input narrow-band interference suppression and smoothing algorithm based on LMS filter[C]//Proc. of the IEEE 2nd International Conference on Electronic Information and Communication Technology, 2019: 192-198.
10	QIU T S, WANG X Y, TIAN Y S, et al. A system design of real-time narrowband rfi detection and mitigation for Gnss-R receiver[C]//Proc. of the IEEE International Geoscience and Remote Sensing Symposium, 2019: 5167-5170.
11	EDDINE D D, MOHAMED D, ABDDELMALIK T A. An optimal method using wavelet packet denoising for a GPS of an observation satellite[C]//Proc. of the Saudi International Electronics, Communications and Photonics Conference, 2013.
12	CHIEN Y, HUANG Y, YANG D, et al. A novel continuous wave interference detectable adaptive notch filter for GPS receivers[C]//Proc. of the IEEE Global Telecommunications Conference GLOBECOM, 2010.
13	KETCHUM J , PROAKIS J . Adaptive algorithms for estimating and suppressing narrow-band interference in PN spread-spectrum systems[J]. IEEE Trans.on Communications, 1982, 30 (5): 913- 924. doi: 10.1109/TCOM.1982.1095542
14	VIJAYAN R , POOR H V . Nonlinear techniques for interference suppression in spread-spectrum systems[J]. IEEE Trans.on Communications, 1990, 38 (7): 1060- 1065. doi: 10.1109/26.57504
15	LI H, HUO Q, ZHENG X, et al. High dynamic GNSS anti-jamming algorithms based on nulling widening and deepening[C]//Proc. of the IEEE 4th Information Technology, Networking, Electronic and Automation Control Conference, 2020: 1562-1568.
16	YANG X , LIU W X , CHEN F Q , et al. Analysis of the effects power-inversion (PI) adaptive algorithm have on GNSS received pseudorange measurement[J]. IEEE Access, 2022, 10, 70242- 70251. doi: 10.1109/ACCESS.2019.2952886
17	FAN G T , ZHANG F , RAN D C . An unbiased carrier-phase anti-interference filter based on mirror frequency amplitude compensation[J]. Advances in Space Research, 2021, 67 (2): 806- 811. doi: 10.1016/j.asr.2020.10.027
18	LU Z K , NIE J W , WAN Y D , et al. Optimal reference element for interference suppression in GNSS antenna arrays under channel mismatch[J]. IET Radar, Sonar & Navigation, 2017, 11 (7): 1161- 1169.
19	JING Z Q . A new method for digital all-pass filter design[J]. IEEE Trans.on Acoustics, Speech, and Signal Processing, 1987, 35 (11): 1557- 1564. doi: 10.1109/TASSP.1987.1165067
20	POWELL S R , CHAU P M . A technique for realizing linear phase ⅡR filters[J]. IEEE Trans.on Signal Processing, 1991, 39 (11): 2425- 2435. doi: 10.1109/78.97998
21	肖承山. 线性相位ⅡR滤波器的逼近[J]. 电子学报, 1993, 7, 46- 53.
	XIAO C S . Approxomation of linear phase digital filters[J]. Acta Electronica Sinca, 1993, 7, 46- 53.
22	ZHONG W. Linear phase FIR digital filter design using differential evolution algorithms[D]. Canada: University of Windsor, 2017.
23	DENG N , SHAO S H , GU G X . Design of linear phase ⅡR filters via optimal Hankel-norm approximation[J]. Control Theory & Applications, 2007, 24 (2): 200- 204.
24	RAMANATHAN R , KP S , VIDYAPEETHAM A , et al. A novel methodology for designing linear phase ⅡR filters[J]. International Journal of Recent Trends in Engineering, 2009, 1 (3): 218- 222.
25	KONOPACKI J , MOSCIRISKA K . A procedure for quasi-equiripple linear-phase ⅡR filters design[J]. International Journal of Electronics & Telecommunications, 2010, 56 (4): 393- 398.
26	AGRAWAL N , KUMAR A , BAJAJ V . A new design approach for nearly linear phase stable ⅡR filter using fractional derivative[J]. IEEE/CAA Journal of Automatica Sinica, 2020, 7 (2): 527- 538. doi: 10.1109/JAS.2020.1003054
27	STANCIC G , DURIC M , JOVANOVIC B , et al. A complexity analysis of ⅡR filters with an approximately linear phase[J]. Radioengineering, 2019, 29 (2): 430- 438.
28	WIDROW B , MCCOOL J M , LARIMORE M G , et al. Stationary and nonstationary learning characteristics of the LMS adaptive filter[J]. Proceedings of the IEEE, 1976, 64 (8): 1151- 1162. doi: 10.1109/PROC.1976.10286
29	CHERN S, SUN C. Linearly constrained RLS algorithm with variable forgetting factor for DS-CDMA system[C]//Proc. of the International Symposium on Intelligent Signal Processing and Communication Systems, 2014: 261-264.
30	LEE L M , WANG H C . An extended Levinson-Durbin algorithm for the analysis of noisy autoregressive process[J]. IEEE Signal Processing Letters, 1996, 3 (1): 13- 15. doi: 10.1109/97.475824
31	BURG J P. Maximum entropy spectral analysis[D]. San Francisco: Stanford University, 1975.
32	DONG H , CHI X F , QU L D , et al. Anti-interference performance of TDCS based on Levinson algorithm of cross spectrum AR model parameter estimation[J]. Journal of Jilin University, 2014, 44 (3): 812- 817.
33	MAMMELA A. The performance of adaptive interference suppression filters used in PN spread-spectrum systems[C]//Proc. of the 8th European Conference on Electrotechnics, Conference Proceedings on Area Communication, 1988: 126-129.
34	AZMI P , TAVAKKOLI N . Narrow-band interference suppression in CDMA spread-spectrum communication systems using pre-processing based techniques in transform-domain[J]. IEICE Transactions on Communications, 2008, 85 (1): 239- 246.
35	KIM D K , PARK P G . Adaptive self-orthogonalizing per-tone decision feedback equalizer for single carrier modulations[J]. IEEE Signal Processing Letters, 2005, 13 (1): 21- 24.
36	HUI S, LIM Y. A block adaptive approach for clutter suppression[C]//Proc. of the ICASSP IEEE International Conference on Acoustics, Speech, and Signal Processing, 1985: 1368-1371.
37	HAN M X , SHI T X , CHEN Y . Digital-assisted photonic analog wideband multipath self-interference cancellation[J]. IEEE Photonics Technology Letters, 2022, 34 (5): 299- 302. doi: 10.1109/LPT.2022.3153336
38	JI J , LIU Y T , CHEN W , et al. A novel signal design and performance analysis in navcom based on LEO constellation[J]. Sensors, 2021, 21 (24): 8235. doi: 10.3390/s21248235
39	CHEN F Q, LU Z K, LIU Z, et al. Tracking bias of navigation signal on performance of post-correlation MMSE anti-jamming algorithm[C]//Proc. of the China Satellite Navigation Conference, 2020: 646-655.
40	LI X H, CHEN F Q, LU Z K, et al. Overview of anti-jamming technology based on GNSS single-antenna receiver[C]//Proc. of the 3rd International Conference on Geoinformatics and Data Analysis, 2020: 96-104.
41	DOUGLAS S C , MENG T H Y . Normalized data nonlinearities for LMS adaptation[J]. IEEE Trans.on Signal Processing, 1994, 42 (6): 1352- 1365. doi: 10.1109/78.286952
42	LOH-MING L , MILSTEIN L . Rejection of narrow-band interference in PN spread-spectrum systems using transversal filters[J]. IEEE Trans.on Communications, 1982, 30 (5): 925- 928. doi: 10.1109/TCOM.1982.1095543
43	MASRY E . Closed-form analytical results for the rejection of narrow-band interference in PN spread-spectrum systems-Part Ⅱ: linear interpolation filters[J]. IEEE Trans.on Communications, 1985, 33 (1): 10- 19. doi: 10.1109/TCOM.1985.1096204
44	郭向飞. 直扩系统中低复杂度窄带干扰抑制技术研究[D]. 西安: 西安电子科技大学, 2014.
	GUO X F. Research on low-complexity narrow-band interference suppression techniques in direct expansion systems[D]. Xi'an: Xidian University, 2014.
45	LU Z K , CHEN F Q , XIE Y C , et al. High precision pseudo-range measurement in GNSS anti-jamming antenna array processing[J]. Electronics, 2020, 9 (3): 412. doi: 10.3390/electronics9030412
46	KWONG R H , JOHNSTON E W . A variable step size LMS algorithm[J]. IEEE Trans.on Signal Processing, 1992, 40 (7): 1633- 1642. doi: 10.1109/78.143435
47	PAZAITIS D I , CONSTANTINIDES A G . A novel kurtosis driven variable step-size adaptive algorithm[J]. IEEE Trans.on Signal Processing, 1999, 47 (3): 864- 872. doi: 10.1109/78.747793
48	ABOULNASR T , MAYYAS K . A robust variable step-size LMS-type algorithm: analysis and simulations[J]. IEEE Trans.on Signal Processing, 1997, 45 (3): 631- 639. doi: 10.1109/78.558478
49	覃景繁, 韦岗. 基于S型函数的变步长LMS自适应滤波算法[J]. 无线电工程, 1996, (4): 44- 47.
	QIN J F , WEI G . Variable-step LMS adaptive filtering algorithm based on sigmoid function[J]. Radio Engineering, 1996, (4): 44- 47.
50	罗小东, 贾振红, 王强. 一种新的变步长LMS自适应滤波算法[J]. 电子学报, 2006, (6): 1123- 1126.
	LUO X D , JIA Z H , WANG Q . A new variable step-size LMS adaptive filtering algorithm[J]. Acta Electronica Sinca, 2006, (6): 1123- 1126.
51	刘宪爽, 吴华明, 肖文波, 等. 改进的双Sigmoid函数变步长自适应算法及在OCT中的应用[J]. 电子学报, 2019, 47 (1): 234- 240.
	LIU X S , WU H M , XIAO W B , et al. An improved double sigmoid function variable step adaptive algorithm and its application in OCT[J]. Acta Electronica Sinca, 2019, 47 (1): 234- 240.
52	邓江波, 侯新国, 吴正国. 基于箕舌线的变步长LMS自适应算法[J]. 数据采集与处理, 2004, 3, 282- 285.
	DENG J B , HOU X G , WU Z G . Variable-step LMS adaptive algorithm based on Kei Tong line[J]. Journal of Data Acquisition and Processing, 2004, 3, 282- 285.
53	张中华, 张端金. 一种新的变步长LMS自适应滤波算法及性能分析[J]. 系统工程与电子技术, 2009, 31 (9): 2238- 2241. doi: 10.3321/j.issn:1001-506X.2009.09.046
	ZHANG Z H , ZHANG R J . A new variable-step LMS adaptive filtering algorithm and performance analysis[J]. Systems Engineering and Electronics, 2009, 31 (9): 2238- 2241. doi: 10.3321/j.issn:1001-506X.2009.09.046
54	胡春娇, 杨顺. 基于箕舌线变步长LMS算法的分析与改进[J]. 计算机仿真, 2010, 27 (11): 359- 362. doi: 10.3969/j.issn.1006-9348.2010.11.090
	HU C J , YANG S . Analysis and improvement of variable step LMS algorithm based on Kei Tong line[J]. Computer Simulation, 2010, 27 (11): 359- 362. doi: 10.3969/j.issn.1006-9348.2010.11.090
55	路翠华, 王瑛, 徐君明. 基于零均值特性的箕舌线变步长LMS算法[J]. 海军航空工程学院学报, 2013, 28 (5): 485- 488.
	LU C H , WANG Y , XU J M . Variable-step LMS algorithm based on zero mean characteristic for Kei Tong line[J]. Journal of Naval Aeronautical Engineering Institute, 2013, 28 (5): 485- 488.
56	路翠华, 李国林, 周洪庆, 等. 基于相关特性的改进箕舌线变步长LMS算法[J]. 数据采集与处理, 2015, 30 (4): 896- 901.
	LU C H , LI G L , ZHOU H Q , et al. An improved LMS algorithm based on correlation characteristics with variable step size for Kei Tong line[J]. Data Acquisition and Processing, 2015, 30 (4): 896- 901.
57	章坚武, 余皓, 章谦骅. 改进的双曲正切函数的变步长LMS算法[J]. 通信学报, 2020, 41 (11): 116- 123.
	ZHANG J W , YU H , ZHANG Q H . Improved variable-step LMS algorithm for hyperbolic tangent function[J]. Journal on Communications, 2020, 41 (11): 116- 123.
58	ANG W P , FARHANG-BOROUJENY B . A new class of gradient adaptive step-size LMS algorithms[J]. IEEE Trans.on Signal Processing, 2001, 49 (4): 805- 810. doi: 10.1109/78.912925
59	ZHANG Y G, LI N, CHAMBERS J A. New gradient based variable step-size LMS algorithm[C]//Proc. of the International Conference on Signal Processing, 2006: 415-418.
60	高丽, 韩彦博. 基于加权平均梯度的变步长LMS算法[J]. 吉林师范大学学报(自然科学版), 2018, 39 (2): 83- 88.
	GAO L , HAN Y B . Variable-step LMS algorithm based on weighted average gradient[J]. Journal of Jilin Normal University (Natural Science Edition), 2018, 39 (2): 83- 88.
61	MADER A , PUDER H , SCHMIDT G U . Step-size control for acoustic echo cancellation filter—an overview[J]. Signal Process, 2000, 80 (9): 1697- 1719. doi: 10.1016/S0165-1684(00)00082-7
62	SHIN H C , SAYED A H , SONG W J . Variable step-size NLMS and affine projection algorithms[J]. IEEE Signal Processing Letters, 2004, 11 (2): 132- 135. doi: 10.1109/LSP.2003.821722
63	李宁. LMS自适应滤波算法的收敛性能研究与应用[D]. 哈尔滨: 哈尔滨工程大学, 2009.
	LI N. Research and application of convergence performance of LMS adaptive filtering algorithm[D]. Harbin: Harbin Engineering University, 2009.
64	LU Z K , SONG J , HUANG L , et al. Distortionless 1/2 overlap windowing in frequency domain anti-jamming of satellite navigation receivers[J]. Remote Sensing, 2022, 14 (8): 1801. doi: 10.3390/rs14081801
65	LU Z K , NIE J W , CHEN F Q , et al. Adaptive time taps of STAP under channel mismatch for GNSS antenna arrays[J]. IEEE Trans.on Instrumentation and Measurement, 2017, 66 (11): 2813- 2824. doi: 10.1109/TIM.2017.2728420
66	李安宇. 低复杂度的线性相位FIR多频陷波滤波器的研究与设计[D]. 天津: 天津工业大学, 2019.
	LI A Y. Research and design of low-complexity linear-phase FIR multi-frequency notch filter[D]. Tianjin: Tianjin Polytechnic University, 2019.
67	李阜东, 石光明, 焦李成. 无乘法的线性相位滤波器组的优化设计[J]. 电波科学学报, 2003, 2, 178- 183.
	LI F D , SHI G M , JIAO L C . Optimal design of linear phase filter bank without multiplication[J]. Chinese Journal of Radio Science, 2003, 2, 178- 183.
68	黄仰博. 基于FPGA的数字滤波器实现技术研究[D]. 长沙: 国防科学技术大学, 2004.
	HUANG Y B. Research on the realization technology of digital filter based on FPGA[D]. Changsha: National University of Defense Technology, 2004.
69	GU Y T , TANG K , CUI H J . LMS algorithm with gradient descent filter length[J]. IEEE Signal Processing Letters, 2004, 11 (3): 305- 307.
70	GONG Y , COWAN C F N . An LMS style variable tap-length algorithm for structure adaptation[J]. IEEE Trans.on Signal Processing, 2005, 53 (7): 2400- 2407.
71	ZHANG Y , LI N , CHAMBERS J A , et al. Steady-state performance analysis of a variable tap-length LMS algorithm[J]. IEEE Trans.on Signal Processing, 2008, 56 (2): 839- 845.
72	ZHANG Y , CHAMBERS J A . Convex combination of adaptive filters for a variable tap-length LMS algorithm[J]. IEEE Signal Processing Letters, 2006, 13 (10): 628- 631.
73	KOZAT S S , ERDOGAN A T , SINGER A C , et al. Steady-state MSE performance analysis of mixture approaches to adaptive filtering[J]. IEEE Trans.on Signal Processing, 2010, 58 (8): 4050- 4063.
74	芮国胜, 苗俊, 张洋, 等. 变宽度凸组合变阶数LMS自适应滤波算法[J]. 系统工程与电子技术, 2012, 34 (3): 451- 456.
	RUI G S , MIAO J , ZHANG Y , et al. Variable-width convex combination variable-order LMS adaptive filtering algorithm[J]. Systems Engineering and Electronics, 2012, 34 (3): 451- 456.
75	WEI Y , YAN Z B . Variable tap-length LMS algorithm with adaptive step size[J]. Circuits, Systems, and Signal Processing, 2017, 36 (7): 2815- 2827.
76	AKHTAR M T, AHMED S. A robust normalized variable tap-length normalized fractional LMS algorithm[C]//Proc. of the IEEE 59th International Midwest Symposium on Circuits and Systems, 2016.
77	WU H L, WANG Y W, LI Z K, et al. A novel variable tap-length digital self-interference cancellation algorithm for full-duplex system[C]//Proc. of the IEEE 2nd International Conference on Automation, Electronics and Electrical Engineering, 2019: 424-427.
78	ALSAID S, ABDEL-RAHEEM E, MAYYAS K. New constant modulus blind equalizer with optimum tap-length for QAM signals[C]//Proc. of the IEEE International Symposium on Signal Processing and Information Technology, 2019.
79	HUO S M , NIE J W , TANG X M , et al. Minimum energy block technique against pulsed and narrowband mixed interferers for single antenna GNSS receivers[J]. IEEE Communications Letters, 2015, 19 (11): 1933- 1936.
80	LU Z K , CHEN F Q , NIE J W , et al. Impact on antijamming performance of channel mismatch in GNSS antenna arrays receivers[J]. International Journal of Antennas & Propagation, 2016, 2016, 1909708.
81	OBRIEN A J , GUPTA I J . Mitigation of adaptive antenna induced bias errors in GNSS receivers[J]. IEEE Trans.on Aerospace & Electronic Systems, 2011, 47 (1): 524- 538.
82	SAEED D , ALI J , ALI B , et al. GNSS space-time interference mitigation and attitude determination in the presence of interference signals[J]. Sensors, 2015, 15 (6): 12180- 12204.
83	李双勋, 程翥, 王展, 等. 空时处理信号失真的一种补偿方法[J]. 信号处理, 2008, 24 (2): 223- 226.
	LI S X , CHENG Z , WANG Z , et al. A compensation method for signal distortion in space-time processing[J]. Signal Processing, 2008, 24 (2): 223- 226.
84	范广腾. 非理想信道下抗干扰接收机高精度测距技术研究[D]. 长沙: 国防科技大学, 2016.
	FAN G T. Research on high precision ranging technology of anti-jamming receiver under non-ideal channel[D]. Changsha: National University of Defense Technology, 2016.
85	MCGRAW G A, MCDOWELL C, YOUNG R S Y, et al. Assessment of GPS anti-jam system pseudorange and carrier phase measurement error effects[C]//Proc. of the 18th International Technical Meeting of the Satellite Division of the Institute of Navigation, 2005: 603-607.
86	王峰, 傅有光, 孟兵, 等. 基于傅里叶变换的雷达通道均衡算法性能分析及改进[J]. 电子学报, 2006, 9, 1677- 1680.
	WANG F , FU Y G , MENG B , et al. Performance analysis and improvement of radar channel equalization algorithm based on Fourier transform[J]. Acta Electronica Sinca, 2006, 9, 1677- 1680.
87	李柏渝. 高性能卫星导航接收机模拟信道关键技术研究[D]. 长沙: 国防科技大学, 2011.
	LI B Y. Research on key technology of high-performance satellite navigation receiver analog channel[D]. Changsha: National University of Defense Technology, 2011.
88	CAO L, AN X P, HONG G, et al. Analysis of measurement biases induced by adaptive antenna arrays for GNSS receivers[C]//Proc. of the 12th International Conference on Natural Computation, Fuzzy Systems and Knowledge Discovery, 2016: 1863-1867.
89	FAN G T , TANG X M , NIE J W , et al. A zero bias frequency-domain interference suppressor for GNSS receivers[J]. IEICE Trans.on Communications, 2016, 99 (9): 2081- 2086.
90	范广腾, 倪少杰, 唐小妹, 等. 非理想信道下测量零值无偏干扰抑制滤波器设计[J]. 国防科技大学学报, 2016, 38 (2): 123- 127.
	FAN G T , NI S J , TANG X M , et al. Design of measurement zero-value unbiased interference suppression filter in non-ideal channel[J]. Journal of National University of Defense Technology, 2016, 38 (2): 123- 127.
91	SONG J , LU Z K , XIAO Z B , et al. Optimal order of time-domain adaptive filter for anti-jamming navigation receiver[J]. Remote Sensing, 2022, 14 (1): 48.
92	鲁祖坤, 陈飞强, 孙一凡, 等. 导航信号功率增强对阵列接收机的影响分析[J]. 系统工程与电子技术, 2021, 43 (9): 2581- 2587.
	LU Z K , CHEN F Q , SUN Y F , et al. Analysis of influence of navigation signal power enhancement on array receivers[J]. Systems Engineering and Electronics, 2021, 43 (9): 2581- 2587.

算法	关键步骤	优点	缺点
Levinson-Durbin	$\begin{aligned}\hat{\rho}(n) & =\sum_{n=0}^{M+1-k} r(n) r(n+k) \\k & =0, 1, \cdots, M+1\end{aligned}$	可取代矩阵求逆中的大容量计算, 在任何域上都成立	参数误差受限于采样间隔; 需要更多样本进行预测; 功率谱受相关函数估计的影响
Burg	$\begin{gathered}a=\frac{2 \sum_{i=M+2}^N f_M(i) b_M(i-1)}{\sum_{i=M+2}^N\left[f_M^2(i)+b_M^2(i-1)\right]}, \\M \geqslant 0\end{gathered}, $	频率分辨率高; 模型稳定; 计算效率高	不适用于高信噪比和高阶模型
LMS	$\boldsymbol{W}_M^{l+1}=\boldsymbol{W}_M^l+2 \mu e^*[n] \boldsymbol{x}[n]$	计算简单, 易于实用	收敛速度和稳态失调不可兼容
RLS	$\begin{gathered}k(n)=\frac{\lambda^{-1} \boldsymbol{P}(n-1) \boldsymbol{x}[n]}{1+\lambda^{-1} \boldsymbol{x}^{\mathrm{H}}[n] \boldsymbol{P}(n-1) \boldsymbol{x}[n]} \\P(n)=\lambda^{-1} \boldsymbol{P}(n-1)-\lambda^{-1} k(n) \boldsymbol{x}^{\mathrm{H}}[n] \boldsymbol{P}(n-1)\end{gathered}$	与输入统计特性无关; 收敛速度快; 跟踪性能好	运算量大; 稳定性差

参数/性能	算法
参数/性能	Kwong(VSS-LMS)	Aboulnasr(RVS-LMS)	Karni	SVSLMS	NVLMS
参数	μ_max=3×10^－6	μ₀=10^－6	μ_max=4×10^－5	α=0.005	μ=3×10^－6
	μ_max=10^－6	α=0.995	α=5×10^－7	β=6×10^－5
	α=0.97	β=0.99
	β=0.6	γ=0.02
载噪比/(dB·Hz)	43.542 9	42.683 3(剔除抗干扰失败数据)	44.679 6	43.699 9	43.448 5

算法	可变参数	优点	缺点
SF-LMS	5	阶数快速收敛达到稳态	控制滤波器结构不实用
GD-LMS	3	易于应用	受到整数阶数的限制
FTLMS	5	提高了灵活性, 降低了算法误差	最佳参数获取需要大量经验
