基于自适应免疫算法的欺骗信号检测方法

doi:10.12305/j.issn.1001-506X.2022.08.05

Abstract

Abstract:

Aiming at the problems of complex ambiguity resolution and limited application scenarios in carrier phase difference detection method, an spoofing signal detection method based on adaptive immune algorithm is proposed. Based on the carrier phase double difference detection, two detection modes of normal signal and deception signal are constructed; Then the immune algorithm is used to obtain the affinity index between the data to be detected and the monitor, and the monitors that meet the threshold requirements are selected, so as to calculate the probability that the data to be detected belongs to each detection mode. In order to solve the problem of false alarm in the actual detection process, an adaptive algorithm is introduced to adjust the crossover probability and mutation probability nonlinearly, which improves the accuracy of the detection results. The experimental results show that the accuracy of the proposed method for deception signal detection can reach 98.8%, and the deception interference signal detection is effectively realized.

Key words: forward spoofing, carrier phase double difference observation value, immune algorithm, deception detection, adaptive algorithm

CLC Number:

U666.1

Haowei CHANG, Chunlei PANG, Zehui GUO, Liang ZAHNG, Minmin LYU, Chuang ZHANG. Spoofing signal detection method based on adaptive immunity algorithm[J]. Systems Engineering and Electronics, 2022, 44(8): 2419-2426.

Figures/Tables 18

Fig.1

Fig.2

Fig.3

Fig.4

Fig.5

Fig.6

Fig.7

Fig.8

Table 1

Table 2

Fig.9

Table 3

Fig.10

Fig.11

Table 4

Fig.12

Table 5

Fig.13

References 21

1	卢丹, 白天霖. 利用信号重构的全球导航卫星系统欺骗干扰抑制方法[J]. 电子与信息学报, 2020, 42 (5): 1268- 1273.
	LU D , BAI T L . Global navigation satellite system spoofing mitigation method by utilizing signal reconstruction[J]. Journal of Electronics & Information Technology, 2020, 42 (5): 1268- 1273.
2	刘科, 何磊. GNSS欺骗与抗欺骗技术研究进展[J]. 江苏海洋大学学报(自然科学版), 2020, 29 (4): 77- 85.
	LIU K , HE L . Research status and prospect of GNSS spoofing and anti-spoofing technology[J]. Journal of Jiangsu Ocean University (Natural Science Edition), 2020, 29 (4): 77- 85.
3	FORMAGGIOF, TOMASIN S, CAPARRAG, et al. Authentication of Galileo GNSS signal by super-imposed signature with artificial noise[C]//Proc. of the 26th European Signal Processing Conference, 2018: 2573-2577.
4	LI J Z , ZHU X W , OUYANG M J , et al. Research on multi-peak detection of small delay spoofing signal[J]. IEEE Access, 2020, 8, 151777- 151787. doi: 10.1109/ACCESS.2020.3016971
5	MIRALLS D , BORNOT A , ROUQUETTE P , et al. An assessment of GPS spoofing detection via radio power and signal quality monitoring for aviation safety operations[J]. IEEE Intelligent Transportation Systems Magazine, 2020, 12 (3): 136- 146. doi: 10.1109/MITS.2020.2994117
6	TAO H Q , WU H L , LI H , et al. GNSS spoofing detection based on consistency check of velocities[J]. Chinese Journal of Electronics, 2019, 28 (2): 437- 444. doi: 10.1049/cje.2019.01.006
7	GROSS J N , KILIC C , HUMPHREYS T E . Maximum-likelihood power-distortion monitoring for GNSS signal authentication[J]. IEEE Trans.on Aerospace and Electronic Systems, 2018, 54 (2): 469- 475.
8	ZHAO Y Q , SHEN F , XU G H , et al. A Spatial-Temporal approach based on antenna array for GNSS anti-spoofing[J]. Sensors, 2021, doi: 10.3390/S21030929
9	张鑫, 庞晶, 苏映雪, 等. 天线阵载波相位双差的欺骗干扰检测技术[J]. 国防科技大学学报, 2014, 36 (4): 55- 60.
	ZHANG X , PANG J , SU Y X , et al. Spoofing detection technique on antenna array carrier phase double difference[J]. Journal of National University of Defense Technology, 2014, 36 (4): 55- 60.
10	黄龙, 雍玲, 徐博, 等. 采用双天线载波相位差技术的卫星导航接收机抗欺骗方法[J]. 国防科技大学学报, 2016, 38 (4): 103- 106.
	HUANG L , YONG L , XU B , et al. Analysis of carry phase difference detection for satellite navigation receivers anti-spoofing[J]. Journal of National University of Defense technology, 2016, 38 (4): 103- 106.
11	耿正霖, 聂俊伟, 李柏渝, 等. 多方位测量的相位双差GNSS欺骗干扰检测算法[J]. 国防科技大学学报, 2016, 38 (3): 32- 38.
	GENG Z , NIE J W , LI B Y , et al. Carrier phase double diffe-rence GNSS spoofing detection technique based on multi-direction measurements[J]. Journal of National University of Defense technology, 2016, 38 (3): 32- 38.
12	张鑫, 陈华明, 黄仰博, 等. 利用旋转天线载波相位双差进行欺骗干扰检测技术[J]. 武汉大学学报(信息科学版), 2016, 41 (4): 529- 534.
	ZHANG X , CHEN H M , HUANG Y B , et al. Deception interference detection technology using rotating antenna carrier phase double difference[J]. Journal of Wuhan University(Information Science Edition), 2016, 41 (4): 529- 534.
13	崔建华, 程乃平, 倪淑燕. 阵列天线抑制欺骗式导航干扰信号方法研究[J]. 电子学报, 2018, 46 (2): 365- 371. doi: 10.3969/j.issn.0372-2112.2018.02.015
	CUI J H , CHENG N P , NI S Y . Research on spoofing suppressing method using antenna array for navigation signal[J]. Acta Electronica Sinica, 2018, 46 (2): 365- 371. doi: 10.3969/j.issn.0372-2112.2018.02.015
14	GAO M , CHEN M X , LIU A , et al. Optimization of microservice composition based on artificial immune algorithm considering fuzziness and user preference[J]. IEEE Access, 2020, 8, 26385- 26404. doi: 10.1109/ACCESS.2020.2971379
15	ZHANG H L , XIAO H H , LIU S L , et al. A relation B-cell network used for data identification and fault diagnosis[J]. Applied Soft Computing, 2021, 113, 107921. doi: 10.1016/j.asoc.2021.107921
16	ZHENG Y H , LI B H , ZHANG S M . Improved fault diagnosis algorithm based on artificial immune network model and neighbourhood rough set theory[J]. Cognitive Computation and Systems, 2021,
17	LIANG M , ZHAO J S . Feature selection for chemical process fault diagnosis by artificial immune systems[J]. Chinese Journal of Chemical Engineering, 2018, 26 (8): 1599- 1604. doi: 10.1016/j.cjche.2017.09.023
18	YAO F , WANG F , ZHANG M J . Weak thruster fault detection for autonomous underwater vehicle based on artificial immune and signal pre-processing[J]. Advances in Mechanical Engineering, 2018, 10 (2): 1- 13.
19	TIAN Y L , LIU X Y . A deep adaptive learning method for rolling bearing fault diagnosis using immunity[J]. Tsinghua Science and Technology, 2019, 24 (6): 750- 762. doi: 10.26599/TST.2018.9010144
20	LIN Q Z , LIU Z W , YAN Q , et al. Adaptive composite operator selection and parameter control for multi-objective evolutionary algorithm[J]. Information Sciences, 2016, 339, 332- 352. doi: 10.1016/j.ins.2015.12.022
21	温正, 孙华克. Matlab智能算法[M]. 北京: 清华大学出版社, 2017: 283- 290.
	WEN Z , SUN H K . Matlab intelligent algorithm[M]. Beijing: Tsinghua University Press, 2017: 283- 290.

仿真参数	数值
进化代数/代	200
群体大小/个	150
个体染色体段数/段	10
变异概率	0.3
二进制编码位数/位	10
个体长度/位	10×10
交叉概率	0.7

实验组数	正常信号概率	欺骗信号概率	检测错误率n
a	80.23	8.43	4.46
b	82.67	4.37	4.73
c	89.34	11.23	5.40

实验组数	正常信号概率	欺骗信号概率	检测错误率n
d	38.67	97.33	6.20
e	29.33	96.21	7.13
f	26.21	89.31	7.60

状态	实验组数	正常信号概率	欺骗信号概率	检测错误率n
改进前	a	80.23	8.43	4.46
	b	82.67	4.37	4.73
	c	89.34	11.23	5.40
改进后	a₁	89.53	5.26	0.93
	b₁	90.26	3.37	0.73
	c₁	91.25	2.68	0.46

状态	实验组数	正常信号概率	欺骗信号概率	检测错误率n
改进前	d	38.67	97.33	6.2
	e	29.33	96.21	7.13
	f	26.21	89.31	7.6
改进后	d₁	15.78	93.12	1.4
	e₁	13.25	97.26	1.06
	f₁	11.68	98.45	1.13
