基于确信可靠性理论的蠕变寿命模型应用研究

doi:10.12305/j.issn.1001-506X.2022.03.38

Abstract

Abstract:

The evaluation of creep endurance life has always been studied and concerned in the field of theory and engineering. Based on the three scientific principles of reliability proposed by the new theory of reliability field, the confident reliability model of creep life is established, and the uncertainty theory is used to characterize the uncertainty of parameters. The uncertainty of model parameters is analyzed through case study, and the results are compared with the probability distribution modeling based on failure time data. The analysis shows that the creep life model based on the sure reliability theory is a new method for life evaluation in the absence of creep test data. Multiple different parameter uncertainties can be considered at the same time, and the uncertainty of creep stress index has a significant impact on the trend of creep reliability curve.

Key words: belief reliability, creep life model, uncertainty theory, uncertainty distribution

CLC Number:

TB114.3

Han YANG, Haowei WANG, Qingrong LI, Min CHEN, Bo PENG. Application research of creep life model based on belief reliability theory[J]. Systems Engineering and Electronics, 2022, 44(3): 1044-1051.

Figures/Tables 11

Fig.1

Table 1

Table 2

Table 3

Table 4

Fig.2

Fig.3

Table 5

Fig.4

Fig.5

Fig.6

References 32

1	SILVA V D . Mechanics and strength of materials[M]. Berlin: Springer, 2006.
2	ABE F , KERN T U , VISWANATHAN R . Creep-resistant steels[M]. Cambridge: Woodhead Publishing, 2008.
3	朱麟. 高铬耐热钢高温蠕变行为及寿命预测[D]. 西安: 西北大学, 2019.
	ZHU L. Creep behavior and life prediction of high chromium hear resistant steel atelevated temperature[D]. Xi'an: Northwestern University, 2019.
4	HOLZER I , KOZESCHNIK E , CERJAK H . New approach to predict the long-term creep behaviour and evolution of precipitate back-stress of 9%~12% chromium steels[J]. Transactions of the Indian Institute of Metals, 2010, 63 (3): 137- 143.
5	LAESON F R , MILLER J . A time-temperature relationship for rupture and creep stress[J]. Transactions of the ASM, 1952, 74 (5): 765- 775.
6	EVANS M . A new statistical framework for the determination of safe creep life using the theta projection technique[J]. Journal of Materials Science, 2012, 47 (6): 2770- 2781. doi: 10.1007/s10853-011-6106-3
7	EVANS M . Statistical properties of the failure time distribution for 12Cr12Mo14V steels[J]. Journal of Materials Processing Technology, 1995, 54 (4): 171- 180.
8	ZHAO J , XING L , HAI T M . Creep damage model based on Z-parameter and confidence level[J]. Journal of Dalian University of Technology, 2008, 48 (6): 825- 829.
9	KIM W G , PARK J Y , KIM S J , et al. Reliability assessment of creep rupture life for Gr.91 steel[J]. Materials and Design, 2013, 51, 1045- 1051. doi: 10.1016/j.matdes.2013.05.013
10	ZHANG C Y , WEI J S , WANG Z , et al. Creep-based reliability evaluation of turbine blade-tip clearance with novel neural network regression[J]. Materials, 2019, 12 (21): 3552- 3572. doi: 10.3390/ma12213552
11	JIANG C , BAI Y C , HAN X , et al. An efficient reliability-based optimization method for uncertain structures based on non-probability interval model[J]. Computers Materials & Continua, 2010, 18 (1): 21- 42.
12	LV H , YANG K , HUANG X T , et al. Design optimization of hybrid uncertain structures with fuzzy-boundary interval variables[J]. International Journal of Mechanics and Materials in Design, 2021, 17 (1): 201- 224. doi: 10.1007/s10999-020-09523-9
13	WANG W X , XUE H , GAO H S . An effective evidence theory-based reliability analysis algorithm for structures with epistemic uncertainty[J]. Quality and Reliability Engineering International, 2020, 37 (12): 841- 855.
14	SONG L F , QIU Z P . Non-probability reliability optimization design for structures with fuzzy and interval variables[J]. Engineering Mechanics, 2013, 30 (6): 36- 45.
15	YU H P , ZHAO Y , MO L . Fuzzy reliability assessment of safety instrumented systems accounting for common cause fai-lure[J]. IEEE Access, 2020, 8, 135371- 135382. doi: 10.1109/ACCESS.2020.3010878
16	LIU B D . Uncertainty theory[M]. 2nd ed Berlin: Springe, 2007.
17	GHAFFARI H A , LIO W C . Network data envelopment analy- sis in uncertain environment[J]. Computers & Industrial En-gineering, 2020, 148, 106657- 106667.
18	ZHANG B, SANG Z, XUE Y Q, et al. Research on optimization of customized bus routes based on uncertainty theory[EB/OL]. [2021-06-30]. https://doi.org/10.1155/2021/6691299.
19	LI X Y , CHEN W B , LI F R , et al. Reliability evaluation with limited and censored time-to-failure data based on uncertainty distributions[J]. Applied Mathematical Modelling, 2021, 94 (1): 2301- 2314.
20	KANG R , ZHANG Q Y , ZENG Z G , et al. Measuring reliability under epistemic uncertainty: review on non-probabilistic reliability metrics[J]. Chinese Journal of Aeronautics, 2016, 29 (3): 571- 579. doi: 10.1016/j.cja.2016.04.004
21	康锐. 确信可靠性理论与方法[M]. 北京: 国防工业出版社, 2020.
	KANG R . Belief reliability: theory and methodology[M]. Beijing: National Defense Industry Press, 2020.
22	ZENG Z G , KANG R . Uncertainty theory as a basis for belief reliability[J]. Information Sciences: An International Journal, 2018, 36 (12): 486- 502.
23	ZHANG Q Y , KANG R , WEN M L . Belief reliability for uncertain random systems[J]. IEEE Trans.on Fuzzy Systems, 2018, 26 (6): 3605- 3614. doi: 10.1109/TFUZZ.2018.2838560
24	于格, 康锐, 林焱辉, 等. 基于确信可靠度的齿轮可靠性建模与分析[J]. 系统工程与电子技术, 2019, 41 (10): 2385- 2391. doi: 10.3969/j.issn.1001-506X.2019.10.31
	YU G , KANG R , LIN Y H , et al. Reliability modeling and analysis of gear based on belief reliability[J]. Systems Engineering and Electronics, 2019, 41 (10): 2385- 2391. doi: 10.3969/j.issn.1001-506X.2019.10.31
25	王浩伟, 康锐. 基于不确定理论的退化数据分析方法[J]. 系统工程与电子技术, 2020, 42 (12): 2924- 2930. doi: 10.3969/j.issn.1001-506X.2020.12.31
	WANG H W , KANG R . Method of analyzing degradation data based on the uncertainty theory[J]. Systems Engineering and Electronics, 2020, 42 (12): 2924- 2930. doi: 10.3969/j.issn.1001-506X.2020.12.31
26	ZU T P , KANG R , WEN M L , et al. α -S-N curve: a novel S-N curve modeling method under small-sample test data using uncertainty theory[J]. International Journal of Fatigue, 2020, 139, 105725- 105735. doi: 10.1016/j.ijfatigue.2020.105725
27	LI X Y , TAO Z , WU J P , et al. Uncertainty theory based relia- bility modeling for fatigue[J]. Engineering Failure Analysis, 2021, 119, 104931- 104949. doi: 10.1016/j.engfailanal.2020.104931
28	LIU B D . Uncertainty theory: a branch of mathematics for mode-ling human uncertainty[M]. Berlin: Springer, 2010.
29	ZHANG J T , ZHANG Q Y , KANG R . Reliability is a science: a philosophical analysis of its validity[J]. Applied Stochastic Models in Business and Industry, 2019, 35 (2): 1654- 1663.
30	BETTEN J . Creep mechanics[M]. Berlin: Springer, 2002.
31	LIO W C , LIU B D . Uncertain maximum likelihood estimation with application to uncertain regression analysis[J]. Soft Computing, 2020, 24 (4): 322- 334. doi: 10.1007/s00500-020-04951-3
32	朱森第, 方向威, 吴民达, 等. 机械工程材料性能数据手册[M]. 北京: 机械工业出版社, 1995.
	ZHU S D , FANG X W , WU M D , et al. Mechanical enginee-ring material performance data manual[M]. Beijing: Machine Press, 1995.

参数	不确定性类型	满足分布	影响因素
外加应力σ/MPa	固有不确定性	${\mathcal{N}}\left( {e1, d1} \right)$	工况
温度T/K	固有不确定性	${\mathcal{N}}\left( {e2, d2} \right)$	环境
变形量失效阈值ε_th/%	固有不确定性	${\mathcal{N}}\left( {e3, d3} \right)$	材料、工况
常数A	认知不确定性	${\mathcal{N}}\left( {e4, d4} \right)$	材料、认知
蠕变应力指数n	认知不确定性	${\mathcal{N}}\left( {e5, d5} \right)$	蠕变机理、认知
蠕变激活能Q/(J/mol)	认知不确定性	${\mathcal{N}}\left( {e6, d6} \right)$	材料、认知
气体常数R_g/(J/(mol·K))	确定性	8.314	—

参数	应力/MPa
参数	170	196	216	235	255	274
蠕变速率(10^-5%/h)	0.75	1.2	2.6	3.4	4.4	9.5

参数	样本编号
参数	1	2	3	4	5
失效应变量/%	0.24	0.27	0.32	0.32	0.35

参数	e	d	参数获取方式
σ/MPa	173	5	工况、经验
ε_th/%	0.30	0.06	不确定极大似然估计
A′	10^-17	5×10^-19	手册数据拟合、经验
n	5.45	0.5	手册数据拟合、经验

参数	样本编号
参数	1	2	3	4	5	6	7	8
失效时间	79	95	123	134	160	196	250	300
